ABB AI820 3BSE008544R1 Analog Input Module

ABB/

ABB AI820 3BSE008544R1 Analog Input Module

Manufacturer:ABB

Product Number:AI820 3BSE008544R1

Product Type:Analog Input Module

Origin:Sweden

Dimensions:45 x 102 x 119 mm

Weight:0.2 kg

Views:40

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24


  • Product Details
  • FAQs
  • Related
  • Contact Us
  • Packing & Delivery
Company Information
E-mail sales@xmjzjsgs.com
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview

The ABB AI820 3BSE008544R1 Analog Input Module is a high-performance input module designed for use in ABB’s AC 800M control system. This module provides 8 differential analog input channels, supporting high-precision data acquisition in industrial automation applications. With a robust design and excellent signal isolation, the AI820 ensures accurate and reliable analog signal processing while minimizing interference and noise.

The AI820 supports a wide range of input signal types, including 0-10V, ±10V, and 0-20mA, making it ideal for a variety of process control applications. It also features 16-bit resolution, providing high accuracy and stability for industrial measurement and control systems. With a compact and rugged design, it is well-suited for harsh environments and integrates seamlessly with ABB’s 800xA and Freelance DCS systems.

Product Specifications

The following table presents the key specifications of the ABB AI820 3BSE008544R1:

Specification Details
Product Type Analog Input Module
Part Number AI820 3BSE008544R1
Number of Channels 8 differential inputs
Input Signal Range 0-10V, ±10V, 0-20mA
Resolution 16-bit ADC
Input Impedance >10MΩ (voltage input), 250Ω (current input)
Isolation 1500 V AC between field and system
Scan Rate 10 ms per channel
Communication Interface PROFIBUS DP, Modbus RTU
Power Consumption 3.5 W
Operating Voltage 24V DC
Operating Temperature -25°C to +70°C
Humidity Tolerance 5% to 95% non-condensing
Certifications CE, UL, CSA, ATEX
Dimensions 45 x 102 x 119 mm
Weight 0.2 kg

Product Applications

The ABB AI820 Analog Input Module is widely used in industries that require precise and reliable analog signal processing. Some of the main application areas include:

  • Power Plants & Energy Management: Used for monitoring voltage, current, and temperature in power generation facilities.
  • Oil & Gas Industry: Helps in monitoring pipeline pressures, fluid levels, and gas flow rates for efficient operations.
  • Chemical & Pharmaceutical Industries: Ideal for monitoring chemical composition, reaction temperatures, and production parameters.
  • Water & Wastewater Treatment: Used in real-time monitoring of water quality, pH levels, and flow rates.
  • Manufacturing & Process Automation: Ensures accurate control of industrial processes by monitoring pressure, temperature, and humidity.

Product Advantages

The ABB AI820 module offers several benefits, making it a preferred choice in industrial automation:

High-Resolution Data Acquisition – With 16-bit resolution, it provides precise signal processing.
Versatile Input Range – Supports 0-10V, ±10V, and 0-20mA, making it flexible for various applications.
High Electrical Isolation1500V AC isolation ensures protection against electrical interference.
Fast Response Time – Provides 10 ms scan rate per channel, enabling real-time monitoring.
Robust Design – Designed to operate in extreme temperatures from -25°C to +70°C.
Efficient Power Consumption – Consumes only 3.5W, ensuring energy efficiency.
Compatible with ABB’s AC 800M Controller – Seamless integration with ABB’s 800xA and Freelance DCS systems.
Reliable Communication Interfaces – Supports PROFIBUS DP and Modbus RTU for flexible system integration.
