Product Overview
The GE Fanuc IC693PRG300 is a handheld programmer designed for use with the Series 90-30 programmable logic controllers (PLCs). This rugged, portable device provides field technicians and automation engineers with the ability to monitor, configure, and troubleshoot PLC systems directly on-site without requiring a PC or laptop. The IC693PRG300 offers a user-friendly interface via an alphanumeric LCD display and a tactile keypad, supporting offline and online programming, diagnostics, and real-time monitoring of control logic.
Ideal for industrial environments where mobility and accessibility are essential, the IC693PRG300 enhances maintenance efficiency and supports faster response times to system issues, making it a valuable tool in manufacturing, utilities, and process automation.
Key Features
-
Portable and Lightweight: Designed for handheld use in field environments
-
Alphanumeric LCD Display: Clear visual interface for data entry and status monitoring
-
Programmable Functionality: Allows for online/offline program editing and logic control
-
Real-Time Diagnostics: Enables immediate identification of faults and performance metrics
-
Battery-Powered Operation: Provides mobility and independence from fixed power sources
-
Rugged Design: Withstands harsh industrial conditions
-
Interface Compatibility: Works with Series 90-30 PLCs via direct connection
-
Menu-Driven Navigation: Simplifies configuration tasks and program execution
-
EEPROM Support: Reads from and writes to memory modules for backup and transfer
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IC693PRG300 |
| Product Type | Handheld Programmer |
| Display Type | Alphanumeric LCD |
| Keyboard Type | Tactile membrane keys |
| Supported PLCs | GE Fanuc Series 90-30 |
| Communication Interface | Direct interface port (serial connection) |
| Power Supply | Internal battery powered (rechargeable or replaceable) |
| Program Storage | EEPROM support |
| Programming Modes | Online and offline |
| Diagnostic Capabilities | Yes (status monitoring, fault indication) |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 180 x 110 x 30 mm |
| Weight | 0.5 kg |
| Compliance | CE, UL, CSA |
Industry Applications
-
Manufacturing: Field programming and diagnostics for assembly line automation
-
Utilities: Maintenance of water treatment and power distribution PLCs
-
Oil & Gas: Real-time configuration and fault diagnosis in remote or hazardous locations
-
Automotive: Program adjustments and troubleshooting on the factory floor
-
Food & Beverage: Ensures continuous operation and fast system tuning
-
Building Automation: Supports setup and maintenance of HVAC and lighting control systems
Product Advantages
-
Mobility in the Field: Offers unmatched convenience for on-site programming
-
Reduced Downtime: Enables immediate troubleshooting and recovery
-
Ease of Use: Intuitive interface with simple navigation for both new and experienced users
-
Reliable Performance: Built for continuous operation in tough industrial settings
-
No PC Required: Operates independently, saving space and setup time in the field
-
Comprehensive Control: Full access to PLC logic, memory, and configuration options
-
Efficient Maintenance Tool: Ideal for technicians performing regular system audits or modifications
Frequently Asked Questions (FAQ)
-
Q: What PLC series is the IC693PRG300 compatible with?
A: It is designed specifically for GE Fanuc Series 90-30 PLCs. -
Q: Does the programmer require external power?
A: No, it operates using internal batteries, making it fully portable. -
Q: Can I upload/download programs using the IC693PRG300?
A: Yes, it supports uploading, downloading, and editing programs both online and offline. -
Q: Does it display live PLC data?
A: Yes, it provides real-time monitoring and diagnostic readouts via the LCD screen. -
Q: Is the display backlit for low-light environments?
A: The model includes a high-contrast LCD, but backlight availability may vary. -
Q: Can this device replace a PC-based programmer?
A: It can handle most on-site programming and maintenance tasks, but complex programming is better handled via PC software. -
Q: Is EEPROM support included?
A: Yes, the unit can read/write to EEPROMs for program backup and restoration. -
Q: What are its durability features?
A: It is housed in a rugged casing suitable for industrial field use. -
Q: Can the programmer be connected while the PLC is running?
A: Yes, it supports online programming, allowing changes without halting operations. -
Q: Is training required to operate the IC693PRG300?
A: Minimal training is required due to its intuitive, menu-driven interface.
