Product Overview
The ABB 1SAY130010R0010 is a robust and high-performance PLC (Programmable Logic Controller) module designed for use in ABB’s industrial automation systems. This module is part of the AC500 series and serves as a digital expansion module, enabling users to scale and extend the control capabilities of their automation infrastructure.
Engineered for reliability, this module provides seamless integration with AC500 CPUs and other I/O modules, ensuring consistent communication and process control in demanding environments such as manufacturing, energy, and utilities.
Key Features
-
Compatible with ABB AC500 PLC series
-
Expandable digital I/O functionality
-
DIN rail mountable for easy installation
-
Designed for industrial-grade reliability
-
CE and RoHS compliant
-
Plug-and-play capability with ABB I/O bus system
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Digital I/O Module |
| Model Number | 1SAY130010R0010 |
| PLC Series | AC500 |
| Number of Inputs | 8 digital inputs |
| Input Type | 24 V DC, sink/source |
| Input Delay | 3 ms (typical) |
| Number of Outputs | 8 digital outputs |
| Output Type | Transistor, sourcing |
| Output Voltage | 24 V DC |
| Output Current | 0.5 A per channel |
| Mounting Method | DIN rail |
| Communication Interface | I/O bus for connection to AC500 CPU and I/O modules |
| Protection Class | IP20 |
| Power Supply | Supplied via backplane or external 24 V DC |
| Operating Temperature | –25°C to +60°C |
| Storage Temperature | –40°C to +70°C |
| Dimensions | Approx. 100 mm × 80 mm × 70 mm |
| Weight | 0.25 kg |
| Certifications | CE, RoHS, UL (depending on region) |
Industry Applications
-
Factory Automation – Control of conveyors, sensors, and actuators
-
Utilities and Energy – Monitoring and control of grid systems
-
HVAC and Building Automation – Efficient building management control
-
Water and Wastewater – Pump and valve automation
-
Renewable Energy – Wind turbine and solar inverter control
-
Oil & Gas – Monitoring and control of distributed field assets
Advantages
-
Modular Design: Enables easy system expansion
-
High-Speed Processing: Fast response time for digital signals
-
System Integration: Fully compatible with AC500 CPUs and engineering tools
-
Reliability: Proven performance in critical industrial environments
-
Space-Saving: Compact form factor for control panels
-
Low Maintenance: Designed for long service life and minimal downtime
Frequently Asked Questions (FAQ)
-
What is the main function of the 1SAY130010R0010 module?
It expands the digital I/O capacity of ABB AC500 PLC systems. -
Can it be used with other ABB PLC families?
It is specifically designed for the AC500 series. -
Is the module plug-and-play?
Yes, it connects directly via the I/O bus without external wiring. -
What type of outputs does it provide?
It has 8 digital sourcing transistor outputs (24 V DC). -
Does it require separate power input?
It can draw power from the I/O backplane or use external 24 V DC supply. -
What is the maximum current per output channel?
Each output can deliver up to 0.5 A. -
Is it suitable for outdoor environments?
It is rated for IP20, so it should be installed in protective enclosures. -
Does it support hot-swapping?
No, the system should be powered down before replacing the module. -
What software is used to program it?
ABB’s Control Builder Plus or Automation Builder software. -
Is it certified for international use?
Yes, it holds CE, RoHS, and other relevant certifications.
