Product Overview
The ABB 3HNM09846-1 Clear Sensor is a high-performance optical sensor designed for precise object detection and positioning in automated systems. Its advanced sensing technology is specifically developed for use in industrial automation and robotics, offering exceptional reliability, accuracy, and fast response times. The clear sensor is used for detecting transparent or clear objects that are typically difficult to sense with traditional sensors, making it highly effective in applications requiring high sensitivity and precision.
This sensor is commonly integrated into material handling systems, packaging lines, and robotic arms, where detecting objects of various materials, including glass, plastic, and other transparent items, is critical. With features such as adjustable sensitivity and easy installation, the 3HNM09846-1 ensures high uptime and minimal maintenance in industrial environments.
Key Features
-
High precision and sensitivity to clear or transparent objects
-
Fast response time for high-speed automation systems
-
Adjustable sensitivity to optimize detection range
-
Compact and easy to integrate into existing systems
-
Built-in diagnostics for real-time performance monitoring
-
Robust design for harsh industrial environments
-
CE, RoHS, and UL certifications for global use
-
Reliable operation in various lighting conditions
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 3HNM09846-1 |
| Product Type | Optical Clear Sensor |
| Sensing Method | Optical (Reflective) |
| Detection Range | Up to 200 mm (depending on object size) |
| Operating Voltage | 24 V DC |
| Output Type | PNP or NPN (selectable) |
| Response Time | ≤ 2 ms |
| Operating Temperature | -25°C to +55°C |
| Protection Class | IP67 (dustproof and water-resistant) |
| Mounting Type | Panel Mount or Bracket Mount |
| Dimensions | 120 x 80 x 40 mm |
| Weight | 0.5 kg |
| Certifications | CE, RoHS, UL |
| Cable Length | 2 meters |
| Light Source | Red LED |
Industry Applications
-
Robotics and Automation: Object detection in robotic arms for sorting and picking operations
-
Packaging Lines: Detecting clear bottles, glass, or plastic containers on conveyors
-
Material Handling Systems: Detection of transparent materials in transport systems
-
Quality Control Systems: Inspection of transparent packaging for defects
-
Automated Warehouses: Detecting clear or transparent storage containers
-
Pharmaceuticals: Monitoring clear vials, ampoules, or blister packs in production lines
-
Food and Beverage Industry: Detecting clear packaging or bottles in automated packaging systems
-
Glass and Plastics Manufacturing: Detecting clear products or materials for sorting and quality checks
Product Advantages
-
High Sensitivity: Capable of detecting clear and transparent objects that are often challenging for other sensors.
-
Fast Response Time: Ensures rapid detection and system reaction, ideal for high-speed applications.
-
Reliable in Various Lighting Conditions: Works efficiently in environments with fluctuating or low light levels.
-
Compact and Space-Efficient: Its small size allows easy integration into tight spaces and complex systems.
-
Adjustable Sensitivity: Fine-tune the sensor’s response to different types of objects or materials.
-
Durability: IP67-rated for protection against dust and water, making it suitable for harsh industrial environments.
-
Cost-Efficient: Provides a reliable and affordable solution for transparent object detection.
-
Easy Installation: Simple mounting and easy setup reduce downtime and improve system performance.
-
Diagnostic Functions: Built-in diagnostics help quickly identify operational issues and reduce troubleshooting time.
-
Long Lifespan: Low maintenance needs and high reliability ensure reduced downtime and long operational life.
Frequently Asked Questions (FAQ)
-
What is the purpose of the ABB 3HNM09846-1 Clear Sensor?
It is designed to detect clear or transparent objects in automated systems, which are typically hard to detect using conventional sensors. -
What is the sensing method used by the sensor?
It uses an optical reflective sensing method, where the sensor emits a light beam and detects the reflected light from an object. -
What is the detection range of this sensor?
The detection range is up to 200 mm, depending on the object size and its material. -
Can the output type be configured?
Yes, the output can be configured for either PNP or NPN, based on your system requirements. -
What is the response time of the sensor?
The sensor has a response time of less than 2 milliseconds, making it suitable for high-speed applications. -
What is the operating voltage for this sensor?
The sensor operates at a 24 V DC voltage. -
What is the protection rating of this sensor?
It has an IP67 rating, ensuring it is dustproof and resistant to water splashes. -
Can the sensor detect objects other than clear materials?
While the sensor is optimized for transparent objects, it may also detect opaque materials depending on their reflective properties. -
How is the sensor mounted?
The sensor can be mounted using a panel or bracket mount, offering flexibility in installation. -
Is this sensor suitable for use in hazardous environments?
Yes, it is designed for use in industrial environments, but it should be evaluated for specific hazardous conditions based on local regulations.
