Product Introduction
The ABB HA C807 A01 3BHE028767R0101 Printed Circuit Board (PCB) is a highly reliable electronic control component designed for industrial automation systems, power control modules, and process control applications. It plays a vital role in managing signals, ensuring proper electrical connections, and supporting control logic in ABB’s advanced drive and control systems. Built with high-quality materials and precision engineering, this PCB guarantees durability, electrical stability, and integration with complex automation environments.
This board is specifically developed to meet the demanding needs of industries such as energy, manufacturing, and heavy process automation. Its design ensures long-term operational stability, reduced downtime, and seamless compatibility with ABB’s control architecture.
Product Parameters
| Parameter | Description |
|---|---|
| Product Model | HA C807 A01 |
| Part Number | 3BHE028767R0101 |
| Manufacturer | ABB |
| Product Type | Printed Circuit Board (PCB) |
| Dimensions | 240 × 150 × 25 mm |
| Weight | 0.45 kg |
| Operating Voltage | 24 V DC (control logic) |
| Signal Compatibility | Analog and Digital I/O |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5–95% (non-condensing) |
| Mounting Method | Rack/Chassis Mount |
| Compliance | CE, RoHS, IEC Standards |
Product Applications
-
Industrial Automation Systems: Control and monitoring of motors, actuators, and robotic systems.
-
Process Control: Applied in oil & gas, chemical, and power plants for precise operational regulation.
-
Drive Systems: Ensures stable signal flow and protection in ABB drive modules.
-
Energy Sector: Utilized in substations and renewable energy control panels.
-
Manufacturing Equipment: Supports PLCs and distributed control systems for heavy machinery.
-
Safety and Redundancy Systems: Critical in applications requiring reliable fault monitoring and quick response.
Product Advantages
-
High Reliability: Built with robust components for stable long-term performance.
-
Compatibility: Seamlessly integrates with ABB automation and control systems.
-
Signal Accuracy: Ensures precise signal processing for improved system efficiency.
-
Thermal Stability: Designed to perform under harsh temperature conditions.
-
Durable Build: Withstands industrial vibration and electromagnetic interference.
-
Easy Maintenance: Modular design allows straightforward replacement and servicing.
-
Safety Compliance: Meets international industrial safety and quality standards.
-
Flexibility: Supports both analog and digital input/output configurations.
FAQ
Q1: What type of signals does the ABB HA C807 A01 PCB support?
A1: It supports both analog and digital signals, enabling versatile use in automation systems.
Q2: Can this PCB be integrated into non-ABB systems?
A2: While optimized for ABB systems, it may be integrated with third-party equipment if voltage and signal standards are compatible.
Q3: How does the board handle electromagnetic interference (EMI)?
A3: It is designed with shielding and robust circuit protection to minimize EMI impacts.
Q4: What protection features are built into the PCB?
A4: The board includes short-circuit protection, over-voltage safeguards, and thermal stability features.
Q5: Is firmware required for operation?
A5: In most cases, the board works as a hardware interface, but in certain configurations, firmware updates may be necessary.
Q6: How does the PCB contribute to system redundancy?
A6: It can be configured in redundant setups to ensure uninterrupted control in case of component failure.
Q7: What is the maximum input signal frequency supported?
A7: The PCB typically supports input signal frequencies up to several hundred kHz, depending on the module configuration.
Q8: Does the board have diagnostic capabilities?
A8: Yes, it features onboard diagnostic circuits for fault detection and system health monitoring.
Q9: Can the PCB be hot-swapped during operation?
A9: Hot-swapping is not recommended; the system should be powered down before replacing the PCB.
Q10: How does the PCB ensure long-term reliability?
A10: It uses industrial-grade capacitors, resistors, and multilayer board designs that ensure durability under continuous operation.
Related Models
| Model Number | Description |
|---|---|
| HA C807 A02 3BHE028768R0101 | Variant PCB for extended I/O support |
| HA C809 A01 3BHE029000R0101 | Control board with enhanced processing |
| HA C810 A01 3BHE029200R0101 | High-performance PCB for drives |
| HA C805 A01 3BHE028700R0101 | Signal processing PCB |
| HA C811 A01 3BHE029250R0101 | PCB for advanced automation systems |
| HA C813 A01 3BHE029350R0101 | PCB optimized for redundancy systems |
Popular ABB Models
| Model Number | Product Type | Key Features |
|---|---|---|
| DSAI130A 3BSE018292R1 | Analog Input Board | High-precision analog data acquisition |
| DSQC679 3HAC028357-001 | Robot Controller Module | Advanced robotic motion control |
| PM861AK01 3BSE018157R1 | Processor Module | High-speed CPU for automation |
| SDCS-CON-4 3ADT309600R1001 | Control Board | Drive control and monitoring |
| 5SHY3545L0010 3BHB013088R0001 | Printed Circuit Board | Power electronics integration |
| 5STP1752H000 3BHL000986P3016 | Thyristor Power Module | High-power switching |
| UAC389 AE02 HIEE300888R0002 | Control Processor Module | Redundant automation processor |
| 2VAA007835R1000 | Communication Interface Module | Industrial communication networking |
