Product Introduction
The ABB 87TSO11-E (GJR2368900R2340) Coupler Module is an essential component designed for industrial automation networks. It functions as a reliable interface between communication buses and various automation devices, facilitating data transfer and signal conditioning. This module is particularly suited for modular control systems, ensuring seamless data exchange across distributed control architectures.
Built with ABB’s high standards of quality and durability, the 87TSO11-E offers stable and interference-free communication in harsh industrial environments. Its compact design and user-friendly installation make it an ideal choice for upgrading or expanding existing automation systems.
Product Specifications
| Parameter | Value |
|---|---|
| Product Name | Coupler Module |
| Model Number | 87TSO11-E |
| Ordering Code | GJR2368900R2340 |
| Communication Interface | Fieldbus Coupler |
| Data Transmission Rate | Up to 12 Mbps |
| Power Supply Voltage | 24 V DC ± 10% |
| Power Consumption | Approx. 2.8 W |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Protection Class | IP20 |
| Dimensions (W × H × D) | 38 x 254 x 203 mm |
| Weight | 0.5 kg |
| Mounting Type | DIN Rail |
| Standards Compliance | CE, UL, RoHS |
Product Applications
The ABB 87TSO11-E Coupler Module is commonly used in:
-
Distributed Control Systems (DCS) for data communication between control units and field devices
-
Programmable Logic Controller (PLC) Systems for network integration
-
Process Automation in chemical, oil & gas, and pharmaceutical industries
-
Power Generation and Distribution for control system communication
-
Building Automation for linking subsystems such as HVAC, lighting, and security
-
Manufacturing Automation including assembly lines and robotics
Product Advantages
-
Reliable Communication: Ensures stable data exchange across complex automation networks.
-
High Data Rate Support: Handles up to 12 Mbps for fast, real-time information flow.
-
Compact Design: Saves space in control cabinets and allows for flexible system design.
-
Wide Operating Range: Works effectively in temperatures from -20°C to +60°C.
-
Energy Efficient: Low power consumption reduces operational costs.
-
Easy Installation: Designed for quick DIN rail mounting and wiring.
-
Strong Environmental Resistance: Performs reliably under high humidity and industrial conditions.
-
Compliance with Safety Standards: Certified to meet CE, UL, and RoHS directives.
-
Improved System Scalability: Facilitates modular expansions without disrupting existing setups.
Frequently Asked Questions (FAQ)
1. What is the main function of the ABB 87TSO11-E Coupler Module?
It acts as an interface to connect different communication buses in automation systems, enabling smooth data transfer.
2. Which communication protocols does this coupler support?
It supports common industrial fieldbus protocols, ensuring broad compatibility.
3. What is the maximum data transmission rate?
The module supports data rates up to 12 Mbps.
4. Can this module operate in humid or harsh industrial environments?
Yes, it is rated for 5% to 95% non-condensing humidity and industrial temperature ranges.
5. What are the mounting options?
It is designed for DIN rail mounting, standard in industrial control panels.
6. What is the power requirement for this module?
It requires a 24 V DC power supply with ±10% tolerance.
7. How is the module connected to other devices?
The module uses standard industrial connectors designed for quick and secure wiring within control panels.
8. Does the module have any indicators for operation status?
Yes, LED indicators show power and communication status for easy monitoring.
9. How does the module handle interference or signal loss?
It features robust design and shielding to minimize communication errors and maintain signal integrity.
10. What certifications does the ABB 87TSO11-E hold?
It complies with CE, UL, and RoHS standards.
Related Models from the Same Series
| Model | Description | Key Feature |
|---|---|---|
| 87TSO12-E | Coupler Module with diagnostics | Enhanced monitoring capability |
| 87TSO13-E | High-speed Coupler Module | Supports faster data rates |
| 87TSO14-E | Redundant Coupler Module | Provides network redundancy |
| 87TSO15-E | Wireless Coupler Module | Supports wireless communication |
| 87TSO16-E | Coupler Module with extended temperature range | For extreme environments |
| 87TSO17-E | Coupler Module with integrated power supply | Simplifies installation |
Popular ABB Models in the Automation Series
| Model | Type | Application | Key Feature |
|---|---|---|---|
| 70AB02a-E | Digital Output Module | Industrial control | 8 digital output channels |
| 70AB20a-E | Digital Input Module | Monitoring and control | 16 digital inputs |
| 70AB15a-E | Analog Input Module | Process measurement | 8 analog inputs |
| 70AB12a-E | Analog Output Module | Control output | 4 analog outputs |
| 70AB25a-E | Relay Output Module | High current switching | 8 relay outputs |
| 70AB30a-E | Communication Module | Network connectivity | Ethernet and fieldbus support |
