Product Introduction
The ABB 88TK50 GJR2397000R1210 Bus Coupling Module is a vital component in ABB’s industrial automation systems, designed to facilitate efficient data and power distribution across multiple networked devices. This module serves as a critical link between different segments of a communication bus, ensuring smooth and reliable communication between controllers, I/O modules, and other connected devices.
This bus coupling module is part of ABB’s extensive range of automation components, and it plays a pivotal role in establishing a reliable and seamless connection between different bus segments. It is designed for use in both small and large industrial systems, providing the required support for integration with ABB’s controllers, sensors, and actuators.
The 88TK50 is built to handle high-speed data transfer and is essential for systems where synchronization between multiple devices is required. It ensures that the communication backbone of a system remains stable, even in complex configurations with many connected devices.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | ABB 88TK50 GJR2397000R1210 Bus Coupling Module |
| Product Type | Bus Coupling Module |
| Bus System | Compatible with ABB’s automation bus systems |
| Module Type | Coupler for linking two separate bus segments |
| Input Voltage | 24V DC |
| Current Consumption | Approx. 200 mA (at nominal voltage) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -30°C to +70°C |
| Weight | 0.8 kg |
| Dimensions (H x W x D) | 198 x 261 x 40 mm |
| Mounting | DIN rail mountable |
| Data Transmission | High-speed communication for real-time systems |
| Protection Rating | IP20 (Protection against solid objects larger than 12.5 mm) |
| Bus Connector Type | Standard bus interface (compatible with ABB bus systems) |
| Connector Type | Screw terminal for easy wiring connections |
| Compliance | CE certified, RoHS compliant |
Product Applications
The ABB 88TK50 GJR2397000R1210 Bus Coupling Module is ideal for applications that require a robust and efficient method to couple different bus segments in industrial automation systems. It is widely used in various industries, including:
-
Industrial Automation Systems: Used to link various components within automated control systems, ensuring that controllers and I/O modules can communicate seamlessly.
-
Process Control Systems: Facilitates data transmission between various control devices in industries such as chemical processing, power generation, and water treatment.
-
Building Automation: Supports bus systems used in building management, including HVAC systems, lighting control, and security systems.
-
Energy Management: Ensures reliable communication between meters, controllers, and other devices in energy management systems.
-
Manufacturing Lines: Enables connection between different parts of the production line, improving real-time monitoring and control of industrial machines.
-
Machine Automation: Ensures smooth integration and communication between programmable logic controllers (PLCs), sensors, and actuators on production floors.
Product Advantages
-
Enhanced Connectivity: The 88TK50 provides reliable connectivity between different bus segments, ensuring smooth data transfer in complex systems.
-
Robust Design: Built to withstand the harsh conditions typical of industrial environments, the module operates effectively in a wide range of temperatures and environments.
-
Ease of Installation: The module is DIN rail mountable, making installation and maintenance quick and straightforward, which is crucial for reducing downtime.
-
High-Speed Communication: Capable of handling high-speed data communication, making it suitable for real-time industrial control and monitoring applications.
-
Versatile Compatibility: The bus coupling module is designed to work seamlessly with a wide range of ABB automation products, including controllers, sensors, and actuators.
-
Energy Efficient: Designed to minimize power consumption while maintaining high performance, helping reduce energy costs.
-
Space-Saving: The compact design allows for easy integration into control panels and cabinets with limited space.
-
Durable and Reliable: Features a high-quality construction that guarantees longevity and reliability, even in demanding operational environments.
-
Flexible Configuration: Supports both small and large systems, providing flexibility for integration across a variety of industrial applications.
-
Compliance and Safety: CE certified and RoHS compliant, ensuring that it meets global safety and environmental standards.
Frequently Asked Questions (FAQ)
-
What is the main function of the ABB 88TK50 Bus Coupling Module?
The main function of the 88TK50 is to provide seamless communication between different bus segments in industrial automation systems. -
What is the operating temperature range of the module?
The module operates within a temperature range of -20°C to +60°C. -
How is the ABB 88TK50 Bus Coupling Module mounted?
The module is DIN rail mountable, making installation simple and quick. -
What is the weight of the ABB 88TK50 Bus Coupling Module?
The module weighs 0.8 kg. -
What is the input voltage for the ABB 88TK50?
The module operates with an input voltage of 24V DC. -
What kind of connector does the module use?
The module uses screw terminal connectors for easy and secure wiring. -
Is the ABB 88TK50 suitable for outdoor use?
The module is designed for use in industrial environments and is protected to IP20 standard, meaning it should be used indoors or in enclosures with limited access. -
Can the ABB 88TK50 be used with other brands of automation equipment?
While it is designed for compatibility with ABB systems, it can be used in systems with other devices if they support standard communication protocols. -
What industries commonly use this module?
This module is used across a variety of industries including manufacturing, process control, energy management, and building automation. -
What is the dimension of the ABB 88TK50 module?
The module’s dimensions are 198 x 261 x 40 mm.
Related Models (Same Series / Similar Functionality)
| Model Number | Description |
|---|---|
| ABB 88TK51 | Bus Coupling Module with enhanced features for larger systems |
| ABB 88TK52 | Dual bus coupling module for complex control systems |
| ABB 88TK53 | High-speed bus coupler for real-time industrial communication |
| ABB 88TK55 | Modular bus coupling solution for multi-segment communication |
| ABB 88TK60 | Bus coupler with extended communication range |
| ABB 88TK70 | Integrated bus coupling and power distribution module |
Popular ABB Models (Same Brand)
| Model Number | Description |
|---|---|
| ABB 88PS50 | Power supply module for ABB control systems |
| ABB 88DO10 | Digital output module for industrial automation |
| ABB 88AI30 | Analog input module for precise measurements in control systems |
| ABB 88DI20 | Digital input module for robust signal acquisition |
| ABB 88RO20 | Relay output module for switching control circuits |
| ABB 88TC80 | Communication terminal for ABB bus systems |
