ABB AF C094 AE01 HIEE200130R1 ARCnet Control Panel

Company Information
E-mail		sales@xmjzjsgs.com
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview

The ABB AF C094 AE01 HIEE200130R1 is a high-reliability ARCnet Control Panel engineered for use in industrial automation systems that demand deterministic communication and stable network interfaces. As part of ABB’s powerful range of communication modules, it acts as a critical hub in ARCnet-based networks, ensuring seamless, timely data exchange across multiple devices within complex industrial environments.

Designed with industrial durability and communication integrity in mind, this panel integrates easily into existing ABB infrastructures and supports long-term operations in electrically noisy and physically demanding settings. Its support for legacy systems and modern DCS architectures makes it highly adaptable for plant upgrades and expansions.

---

Technical Specifications

---

Applications

The ABB AF C094 AE01 panel plays an essential role in applications where communication stability and real-time coordination are crucial. Common use cases include:

• Power Plants and Utilities – Distributed control networks for generation and distribution.

• Oil & Gas – Remote monitoring and control in offshore and onshore processing units.

• Industrial Manufacturing – Synchronization of PLCs, HMIs, and SCADA across a production floor.

• Water and Wastewater Treatment – Supervisory control of pumps, sensors, and gate valves.

• Transportation Systems – Networked control in railway automation and traffic control.

• Food & Beverage Processing – Real-time production data tracking and line control.

---

Key Advantages

• Robust ARCnet Integration: Provides secure and predictable communication across networked devices with token-passing architecture.

• Compact and Durable: Small footprint with reinforced industrial-grade housing fits into tight control cabinets.

• Universal Compatibility: Works seamlessly with both legacy ABB systems and modern ABB control platforms.

• Diagnostic Transparency: LED indicators provide clear operational and fault status feedback.

• Electromagnetic Immunity: Designed to operate reliably in environments with high EMI levels.

• Low Power Requirement: Operates efficiently with just 10 W at 24 VDC, reducing energy overhead.

• Long Service Life: Built for demanding industrial cycles with minimal maintenance needs.

• Flexible Network Topologies: Supports bus, star, and hybrid configurations for network expansion.

---

Frequently Asked Questions (FAQ)

1. What is the primary function of the AF C094 AE01 panel?
   It acts as an ARCnet communication node, enabling data exchange between control and monitoring devices.

2. Is this unit compatible with older ABB systems?
   Yes, the panel is backward compatible and ideal for system retrofits.

3. What environmental conditions can it withstand?
   It operates from -10°C to +60°C and stores safely down to -25°C and up to +85°C.

4. How is this device mounted?
   It’s designed for secure panel mounting within control enclosures.

5. What type of ARCnet connectors are included?
   The panel includes both BNC and RJ-45 connectors for flexible cabling.

6. Does it support network diagnostics?
   Yes, built-in LEDs indicate power, link, and network activity.

7. Is the housing resistant to industrial hazards?
   Yes, it features reinforced ABS and metal shielding for durability and EMI resistance.

8. Can it operate in outdoor or humid environments?
   It can operate in humid environments if housed in an appropriate enclosure, but it is not IP-rated.

9. How often does it require maintenance?
   Minimal; routine visual inspections of network connections and LEDs are sufficient.

10. Can I use this with SCADA and DCS simultaneously?
    Yes, it can bridge SCADA terminals and DCS controllers over ARCnet networks.

---
