Product Introduction
The ABB AINT-12C (Part No. 64715810) is a high-performance MC (Master Communication) Interface Board designed for robust industrial communication in critical automation systems. As part of ABB’s renowned Advant Controller 400 series, this module serves as a reliable bridge between the controller and peripheral devices, ensuring stable and synchronized data transmission in distributed control systems.
This board is engineered with industrial-grade components that guarantee long-term stability, even in harsh operating environments. The AINT-12C facilitates seamless integration with ABB’s control systems and supports multiple communication protocols, making it a versatile and dependable solution for a wide range of industrial applications.
Product Specifications
| Parameter | Description |
|---|---|
| Product Name | ABB AINT-12C MC Interface Board |
| Part Number | 64715810 |
| System Compatibility | Advant Controller 400, ABB Masterpiece DCS |
| Communication Type | Master Communication (MC) Interface |
| Supported Protocols | Proprietary ABB MC bus protocols |
| Backplane Type | DIN rail mountable, standard ABB slot interface |
| Connector Type | Multi-pin interface connector |
| Operating Voltage | 24V DC |
| Power Consumption | Approx. 4W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% – 95% RH, non-condensing |
| Cooling Method | Passive air cooling |
| Installation Method | Plug-in module with backplane interface |
| Dimensions (H x W x D) | 130 × 30 × 190 mm |
| Weight | 0.26 kg |
| Standards Compliance | CE, RoHS, UL certified |
| Firmware Upgradeable | Yes, via controller interface |
| LED Indicators | Yes – Status and Fault indication |
| Material Type | PCB with industrial coating |
Product Applications
The ABB AINT-12C board is widely used in the following industrial scenarios:
-
Distributed Control Systems (DCS): Facilitates communication between main controllers and subsystems in chemical plants, oil & gas refineries, and power stations.
-
Manufacturing Automation: Acts as a bridge for high-speed data exchange between PLCs and supervisory control systems.
-
Energy & Utilities: Used in energy monitoring and control applications, ensuring consistent data relay in power distribution.
-
Metals and Mining: Provides rugged communication support in mining process control systems.
-
Pulp and Paper: Interfaces between various processing stages, synchronizing operational data.
Product Advantages
-
High Reliability: Industrial-grade components ensure stable long-term operation in demanding environments.
-
Seamless Integration: Fully compatible with ABB’s Advant and Masterpiece platforms, reducing integration time.
-
Fast Communication: Supports ABB’s high-speed MC protocol for low-latency data transmission.
-
Compact Design: Small footprint allows installation in dense control cabinets.
-
Field-Proven: Time-tested in thousands of installations globally with minimal failure rates.
-
Firmware Upgradable: Extends lifecycle and ensures compatibility with evolving systems.
-
LED Diagnostics: Quick fault identification via onboard status LEDs.
Frequently Asked Questions (FAQ)
-
What systems is the ABB AINT-12C compatible with?
It is primarily designed for the ABB Advant Controller 400 and Masterpiece DCS systems. -
Can this board be used in non-ABB systems?
While it’s optimized for ABB systems, integration into other systems may require custom interfacing or protocol conversion. -
Is the firmware on the AINT-12C upgradable?
Yes, the module supports firmware upgrades via its controller interface. -
What is the typical installation method?
The board is designed for slot-based installation into a DIN-rail mounted ABB rack system. -
Does it require active cooling?
No, it uses passive air cooling for thermal management. -
Are status LEDs available for diagnostics?
Yes, it includes onboard LEDs for operational and fault indication. -
What is the average lifespan of the AINT-12C board?
With proper operating conditions, it exceeds 10 years of active service life. -
Is the board RoHS and CE compliant?
Yes, the board adheres to international compliance standards, including CE and RoHS. -
Can the board operate in high-humidity environments?
Yes, up to 95% relative humidity in non-condensing conditions. -
How do I know if the board is functioning properly?
Normal operation is indicated by green status LEDs; faults are indicated with red.
