Product Overview
The ABB AO561 1TNE968902R1201 is an advanced analog output module designed for precision control and seamless integration into ABB’s automation systems. It provides reliable signal conversion for industrial process control, ensuring smooth and accurate operation in a variety of applications. The module is engineered to deliver high performance in demanding industrial environments, making it a vital component for automation, manufacturing, and process industries.
Technical Specifications
Below is a detailed specification table for the ABB AO561 Analog Output Module:
| Specification | Details |
|---|---|
| Model Number | AO561 1TNE968902R1201 |
| Number of Channels | 8 |
| Output Type | Analog |
| Signal Range | 0-20 mA, 4-20 mA |
| Resolution | 12-bit |
| Accuracy | ±0.1% full scale |
| Update Time | < 10 ms |
| Output Load | 500 Ω max |
| Power Supply | 24 VDC |
| Galvanic Isolation | Yes |
| Communication | ABB control system compatible |
| Mounting Type | DIN Rail |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 135 x 74 x 34 mm |
| Weight | 0.118 kg |
Features
-
High-Precision Analog Signal Output: Supports 0-20 mA and 4-20 mA signal ranges for accurate control.
-
Fast Response Time: Low latency (<10 ms update time) ensures rapid reaction in automation systems.
-
Robust Industrial Design: Built for harsh environments with wide temperature range support.
-
Galvanic Isolation: Ensures signal integrity and prevents ground loop issues.
-
Seamless ABB Integration: Fully compatible with ABB control systems and PLC platforms.
-
Energy-Efficient Performance: Optimized for low power consumption.
Applications
The ABB AO561 Analog Output Module is widely used in industrial automation and process control applications, including:
-
Process Industries: Chemical, oil & gas, and pharmaceutical manufacturing.
-
Factory Automation: Controlling actuators, valves, and proportional control devices.
-
Power Plants: Precise regulation of output signals in energy generation and distribution.
-
Building Automation: Integration into HVAC and environmental control systems.
-
Machine Control: Used in robotics, CNC machines, and motion control applications.
Advantages
-
Reliable Performance: High accuracy and stable signal output ensure consistent operation.
-
Versatile Compatibility: Works with multiple industrial control systems.
-
Scalability: Can be expanded with additional modules to accommodate growing system demands.
-
Durability: Engineered to withstand extreme temperatures and industrial conditions.
-
Reduced Downtime: Fast response and diagnostic capabilities help minimize operational interruptions.
