Product Introduction

The ABB Bailey IMASM01 Analog Input Slave Module is a critical component in ABB’s INFI 90 Distributed Control System (DCS). It serves as a slave interface that enables the reliable transmission of analog input signals from field devices to the system’s multifunction processors and controllers. Designed for high-accuracy process control applications, this module is especially useful in industrial environments where precision and stability are crucial.

This module reads analog inputs, converts them to digital signals, and communicates them via the control bus to the associated processing units. It is widely used in systems requiring redundant and distributed architecture, ensuring continuous, uninterrupted monitoring of analog signals such as temperature, pressure, flow, and level.


Product Specifications

Parameter Specification
Product Name IMASM01
Manufacturer ABB Bailey
Product Type Analog Input Slave Module
System Compatibility INFI 90, Symphony, Harmony Series
Input Channels 8 analog inputs
Input Signal Type 4-20 mA, 1-5 VDC, ±10 VDC (configurable)
Resolution 12-bit to 16-bit depending on configuration
Communication Interface INFI-NET / Module Bus
Scanning Rate Configurable; typically 100 ms
Calibration Method Software-assisted, digitally compensated
Isolation Galvanic isolation between field input and system electronics
Redundancy Support Yes, via system-level configuration
Power Supply 5 VDC from system backplane
Mounting Type Rack-mounted (modular slot-based)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity Range 5% to 95% non-condensing
Certifications CE, UL, CSA, RoHS
Dimensions (W × H × D) 178 x 51 x 330 mm
Weight 0.231 kg

Product Applications

The IMASM01 is used across a broad range of process industries where analog signal monitoring and data acquisition are essential. Some typical applications include:

  • Power Plants:
    Continuous monitoring of steam pressure, temperature, and generator output via analog signals.

  • Oil & Gas:
    Data acquisition from flow meters, tank level sensors, and pressure transmitters.

  • Chemical Processing:
    Analog signal monitoring for pH, temperature, and reaction rates in batch or continuous reactors.

  • Water & Wastewater Treatment:
    Input from chlorine sensors, turbidity meters, and flow instruments.

  • Metals & Mining:
    Monitoring of motor current, load cell outputs, and temperature profiles in furnaces.

  • Pharmaceutical Manufacturing:
    Precise monitoring of critical process variables like temperature and pressure in cleanroom environments.


Product Advantages

  1. High Signal Accuracy
    Supports precision analog signal acquisition with high-resolution A/D conversion.

  2. Flexible Input Configuration
    Accepts multiple analog input types (current, voltage) for various sensor compatibility.

  3. Industrial Durability
    Built to operate reliably in harsh industrial environments, with high noise immunity.

  4. Redundant System Integration
    Easily integrates into redundant control architectures, enhancing system reliability.

  5. Quick Diagnostics
    LED indicators and diagnostic functions allow quick fault identification and recovery.

  6. System Interoperability
    Compatible with INFI 90 and Symphony systems, allowing smooth expansion or replacement.

  7. Minimal Downtime
    Modular hot-swap capable design enables maintenance without complete system shutdown.

  8. Field Isolation
    Galvanic isolation protects system components from voltage surges and electrical faults.

  9. Centralized Configuration
    Easily configured via ABB software tools, minimizing commissioning time.

  10. Long Lifecycle Support
    Supported by ABB’s robust lifecycle services, ensuring availability and serviceability for years.


Frequently Asked Questions (FAQ)

  1. Q: What signal types does the IMASM01 support?
    A: It supports 4-20 mA, 1-5 VDC, and ±10 VDC analog input signals.

  2. Q: How many channels does it provide?
    A: The module provides 8 analog input channels.

  3. Q: Is the IMASM01 compatible with Symphony systems?
    A: Yes, it is fully compatible with Symphony and INFI 90 systems.

  4. Q: Does the module support redundancy?
    A: Yes, it can operate in redundant configurations for enhanced reliability.

  5. Q: Can the IMASM01 be hot-swapped?
    A: Yes, under proper conditions, the module can be replaced without shutting down the system.

  6. Q: How is the module calibrated?
    A: Calibration is done digitally through ABB’s configuration software tools.

  7. Q: Is the module optically isolated?
    A: It features galvanic isolation to prevent damage from electrical faults.

  8. Q: What kind of mounting is required?
    A: The module is designed for slot-based installation in ABB’s rack-mounted systems.

  9. Q: What is the resolution of the analog inputs?
    A: The module supports resolutions from 12-bit to 16-bit depending on system settings.

  10. Q: Are firmware upgrades required or available for the IMASM01?
    A: The IMASM01 does not require regular firmware upgrades. Its functionality is defined by system configuration software, and firmware changes are rarely needed unless specified by ABB.


Related Models (Same Series or Functionality)

Model Description System Compatibility Key Function
IMMFP03 Multifunction Processor Module INFI 90 Control logic processing
IMASI03 Analog Input Module INFI 90 Direct analog signal input
IMASO01 Analog Output Module INFI 90 Outputs analog control signals
IMMFC03 Multifunction Controller INFI 90 Execution of control strategies
INICT03A Network Interface Module INFI-NET Communication to host systems
IMCPM02 Communication Processor Module INFI 90 Supervisory communications

Popular ABB Models (Same Brand – High Demand)

Model Product Type Description Product Series
PM864AK01 CPU Module High-performance controller for 800xA systems AC 800M
CI854AK01 Communication Interface PROFIBUS DP interface for AC 800M AC 800M
AI810 Analog Input Module 8-channel, 4-20 mA analog input S800 I/O
DO810 Digital Output Module 16-channel, 24V DC digital output S800 I/O
BRC410 Redundant Control Processor Core controller for Symphony Plus systems Symphony Plus
SD831 Termination Unit Interface terminal base for I/O modules S800 I/O
