Product Introduction
The ABB Bailey IMFAI02 Fast Analog Input Module is a high-speed analog input module designed for industrial automation and control applications. As part of the Bailey Infi 90 Distributed Control System (DCS), this module provides rapid and accurate analog signal acquisition, making it ideal for time-sensitive applications that require real-time data processing.
The IMFAI02 module is engineered to handle high-speed analog inputs with low latency and high resolution, ensuring that critical process parameters are monitored with precision. With galvanic isolation and robust noise immunity, the module prevents electrical interference, thereby enhancing system reliability and accuracy.
This module is particularly suitable for applications where rapid data acquisition and processing are essential, such as power generation, chemical processing, water treatment, and oil & gas industries. It integrates seamlessly into existing ABB Bailey control systems, offering a flexible and scalable solution for industrial automation.
Product Specifications
| Specification | Details |
|---|---|
| Model | IMFAI02 |
| Manufacturer | ABB Bailey |
| Type | Fast Analog Input Module |
| Input Channels | 8 |
| Input Signal Type | 4-20mA, 1-5V, ±10V |
| Signal Resolution | 16-bit |
| Sampling Rate | 1ms per channel |
| Isolation Voltage | 1500V AC |
| Input Impedance | ≥ 250Ω (for 4-20mA) |
| Accuracy | ±0.05% of full scale |
| Operating Voltage | 24V DC |
| Power Consumption | 4.2W (typical) |
| Communication Protocol | Infi 90 System Bus |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% non-condensing |
| Dimensions (L × W × H) | 317.5 × 88.9 × 241.3 mm |
| Weight | 0.01 kg |
| Mounting | DIN Rail / Rack Mountable |
Product Applications
The ABB Bailey IMFAI02 module is widely used in industrial automation for high-speed data acquisition and process control. Typical applications include:
- Power Plants – Monitoring and controlling real-time parameters such as temperature, pressure, and voltage fluctuations.
- Chemical Processing – Ensuring precise and rapid measurement of fluid levels, pH levels, and chemical compositions.
- Water & Wastewater Treatment – Collecting fast analog data for flow rate monitoring, chemical dosing, and filtration control.
- Oil & Gas – Used in refineries and offshore platforms for real-time monitoring of pressure and temperature.
- Manufacturing & Production Lines – Ensuring optimal process efficiency through high-speed sensor readings.
Product Advantages
- High-Speed Data Acquisition – 1ms per channel sampling rate ensures real-time monitoring and response.
- High Precision & Resolution – 16-bit resolution ensures accurate measurement and minimal signal distortion.
- Galvanic Isolation – Protects against electrical noise, reducing signal interference and increasing reliability.
- Robust Design – Built for industrial environments with high durability and resistance to harsh conditions.
- Seamless Integration – Fully compatible with ABB Bailey Infi 90 DCS, allowing for easy system expansion.
- Low Latency Processing – Designed for fast response applications where real-time data analysis is critical.
- Wide Input Range – Supports multiple signal types (4-20mA, 1-5V, ±10V) for flexible use in different industries.
- Efficient Power Consumption – Operates with low power requirements, optimizing energy efficiency.
Latest News Headlines on ABB Bailey IMFAI02
- “ABB Enhances Process Automation with IMFAI02 Fast Analog Input Module”
- “ABB Bailey IMFAI02: Advancing High-Speed Data Acquisition in Industrial Applications”
- “Power Plants Benefit from ABB Bailey’s New High-Precision Input Module”
- “ABB Bailey Expands Infi 90 DCS Portfolio with IMFAI02 for Faster Real-Time Monitoring”
- “IMFAI02 Module Proves Essential in Chemical Processing for Rapid Sensor Integration”
Frequently Asked Questions (FAQ)
-
What is the main function of the ABB Bailey IMFAI02 module?
The IMFAI02 is a high-speed analog input module designed for fast and accurate data acquisition in industrial automation systems. -
How many input channels does the IMFAI02 have?
It supports 8 input channels for monitoring analog signals. -
What is the signal resolution of the IMFAI02?
The module offers 16-bit resolution, ensuring high precision. -
What industries commonly use the IMFAI02 module?
It is widely used in power plants, chemical processing, water treatment, and oil & gas industries. -
What is the sampling rate of this module?
The IMFAI02 has a 1ms per channel sampling rate for fast data acquisition. -
Does this module provide electrical isolation?
Yes, it offers 1500V AC galvanic isolation to prevent electrical interference. -
What communication protocol does the IMFAI02 use?
It operates on the ABB Bailey Infi 90 System Bus. -
What are the dimensions of the IMFAI02 module?
The module measures 317.5 × 88.9 × 241.3 mm. -
Is the module compatible with other ABB Bailey DCS systems?
Yes, it integrates seamlessly with Infi 90 DCS. -
What is the weight of the IMFAI02?
It weighs 0.01 kg.
