Product Introduction
The ABB Bailey IMMFP03 is a robust, field-proven Multifunction Processor Module used within ABB’s renowned INFI 90 Distributed Control System (DCS). Designed to manage complex control logic, I/O data processing, and real-time operations, the IMMFP03 is a vital component in industrial automation environments that require high reliability, precision, and scalability.
It serves as the brain of a control loop or control strategy within the INFI 90 system, capable of handling regulatory control, sequencing, alarming, and data acquisition. IMMFP03 is engineered for mission-critical operations in sectors like power generation, oil & gas, petrochemicals, and manufacturing, where reliability is non-negotiable.
Its flexible configuration, rugged industrial design, and compatibility with ABB’s Symphony Harmony systems make it a go-to choice for both new installations and system upgrades.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Name | IMMFP03 |
| Manufacturer | ABB Bailey |
| Product Type | Multifunction Processor Module |
| System Compatibility | INFI 90, Symphony, Harmony Series |
| Functionality | Process control, I/O management, logic execution |
| Processor Type | High-performance 16/32-bit industrial microprocessor |
| Memory Capacity | RAM and EPROM for logic and firmware storage |
| Communication | INFI-NET, Module Bus |
| Supported I/O | Analog and digital (via I/O modules) |
| Redundancy Support | Yes, supports redundant configurations |
| Programming Tools | Composer, WinCAD, Control Builder |
| Power Supply | 5 VDC (via backplane) |
| Typical Control Loop Execution | <10 ms |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity Range | 5%–95% non-condensing |
| Mounting | Rack-mounted, slot-based installation |
| Dimensions (W x H x D) | 35.56 x 177.80 x 298.45 mm |
| Weight | 0.84 kg |
| Certifications | CE, UL, CSA, RoHS compliant |
Product Applications
The IMMFP03 module is widely adopted in industries where deterministic control and system stability are critical. Key application areas include:
-
Power Generation
Manages steam turbine operations, boiler controls, and feedwater systems. -
Petrochemical Processing
Coordinates distillation columns, compressor skids, and safety interlocks. -
Water Treatment Plants
Controls filtration sequences, dosing systems, and pressure regulation. -
Manufacturing Automation
Handles line automation, machine logic, and material handling systems. -
Oil & Gas Refining
Implements control logic for drilling, refining, and transportation systems. -
Pulp & Paper
Supervises paper machine control, drying lines, and chemical additives.
Product Advantages
-
Integrated Control Platform
Combines logic, sequencing, alarming, and regulatory control into a single module. -
Proven Field Reliability
Extensively deployed in demanding industrial environments with long-term operational success. -
Redundancy-Ready Architecture
Ensures high availability through dual-redundant deployment options. -
Fast Execution Cycles
Handles rapid loop processing and high-speed control logic execution. -
Industrial-Grade Build
Withstands extreme temperature, electrical noise, and vibration conditions. -
Full INFI 90 Compatibility
Seamless integration into existing ABB DCS frameworks without retrofitting. -
Software Configurable
Easily programmed using ABB engineering tools like Composer and WinCAD. -
Modular Scalability
Expandable to match plant requirements through additional modules. -
Backward Compatibility
Suitable for replacing or augmenting older IMMFP02 or IMMFP01 modules. -
Long Lifecycle Support
Supported by ABB’s long-term service and parts programs.
Frequently Asked Questions (FAQ)
-
Q: What systems is the IMMFP03 compatible with?
A: It is designed for use in ABB’s INFI 90, Symphony, and Harmony systems. -
Q: Can the IMMFP03 be installed in redundant configurations?
A: Yes, it supports redundant processor pairing for increased reliability. -
Q: What kind of control functions can IMMFP03 handle?
A: It can manage continuous control, batch control, sequencing, and alarming. -
Q: Is IMMFP03 programmable on-site?
A: Yes, using ABB tools like Composer or WinCAD on engineering workstations. -
Q: How is the IMMFP03 powered?
A: It receives power from the INFI 90 system backplane (5 VDC). -
Q: What communication protocols does it support?
A: It communicates via INFI-NET and Module Bus. -
Q: Does the IMMFP03 have built-in I/O terminals?
A: No, I/O is managed through separate I/O modules and carriers. -
Q: How does IMMFP03 differ from IMMFC03?
A: IMMFP03 focuses on general multifunction processing; IMMFC03 may have tailored firmware for specific applications. -
Q: Is IMMFP03 still supported by ABB?
A: Yes, ABB provides ongoing support, spare parts, and integration services. -
Q: What is the operating life of IMMFP03 in the field?
A: When used properly, it can last over 10 years in continuous operation.
Related Models (Same Series or Functionality)
| Model | Description | System Compatibility | Primary Function |
|---|---|---|---|
| IMMFP01 | Early version multifunction processor | INFI 90 | Logic & control execution |
| IMMFP02 | Predecessor to IMMFP03 | INFI 90 | Mid-generation processor |
| IMMFC03 | Multifunction Controller Module | INFI 90 | Real-time control |
| IMMFC04 | Enhanced Multifunction Controller | INFI 90 | Advanced process control |
| INICT03A | Network Interface Module | INFI-NET | Communication between PC and DCS |
| INNIS21 | Network Interface Slave Module | Symphony/INFI 90 | INFI-NET Data exchange |
Popular ABB Modules (Same Brand – High Demand)**
| Model | Product Type | Description | Series |
|---|---|---|---|
| PM864AK01 | CPU Module | High-performance controller with Ethernet | AC 800M |
| CI854AK01 | Communication Interface | PROFIBUS DP Module | AC 800M |
| AI810 | Analog Input Module | 8-channel analog input 0–20 mA | S800 I/O |
| DO820 | Digital Output Module | 16-channel 24V DC output | S800 I/O |
| BRC410SP | Redundant Controller | Advanced controller for Symphony Plus | Symphony Plus |
| SD822 | Termination Unit | Terminal block for S800 I/O modules | S800 I/O |
