Product Introduction
The ABB Bailey IMMPI01 Multifunction Processor Interface is a key communication module in the INFI 90 process control system. Designed as a central link between the multifunction processor (MFP) and the rest of the control system, it ensures reliable, real-time data communication and synchronization within distributed industrial automation networks.
Built with ABB’s renowned reliability and integration flexibility, the IMMPI01 serves as the interface between the MFP and the INFI 90 system buses, supporting communication, control commands, time synchronization, and diagnostic feedback. The module acts as the central coordinator that enables various process logic elements to function cohesively, making it an indispensable part of large-scale control strategies.
Whether deployed in power generation, chemical plants, refining operations, or water treatment facilities, the IMMPI01’s role is critical for system integrity and data consistency.
Product Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB (Bailey Controls) |
| Product Family | INFI 90 System |
| Model Number | IMMPI01 |
| Product Type | Multifunction Processor Interface Module |
| Communication Type | Serial data interface to MFP |
| Interface Protocols | INFI-NET and Plant Loop compatible |
| Compatibility | Supports connection with IMMFP01/IMMFP02 multifunction processors |
| Status Indicators | LED indicators for diagnostics and communication status |
| Redundancy | Supports redundant configurations for fault tolerance |
| Backplane Connection | Plugs into standard INFI 90 mounting hardware |
| Power Consumption | < 5 Watts |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity Range | 5% to 95% non-condensing |
| Cooling Method | Passive (convection-cooled) |
| Dimensions (H x W x D) | 178 x 51 x 330 mm |
| Weight | 0.5 kg |
| Mounting | Card slot in INFI 90 system mounting chassis |
| Certification | CE, CSA, UL (region-dependent) |
Product Applications
The ABB Bailey IMMPI01 is used in a wide array of industrial automation systems where robust, real-time data exchange and processor-level synchronization are vital. Its primary applications include:
-
Power Generation Plants
Interfacing MFP units for control of turbines, boilers, and auxiliary systems. -
Oil & Gas Refineries
Coordination of distributed logic processors across complex refining operations. -
Chemical & Petrochemical Plants
Ensuring synchronized data flow between process control units and system-wide monitoring. -
Water and Wastewater Treatment
Monitoring and managing distributed pump stations, sensors, and treatment modules. -
Manufacturing Process Automation
Enabling real-time logic sharing in batch and continuous process controls. -
Paper and Pulp Industries
Facilitating communication between multifunction processors in high-speed production lines.
Product Advantages
-
Centralized Processor Interface
Acts as a backbone for communication between MFP and the INFI 90 system, ensuring data integrity. -
Robust and Reliable
Designed to operate in demanding industrial environments with high uptime expectations. -
Supports Redundancy
Enables fault-tolerant operation through support for dual-module configurations. -
Easy Integration
Seamlessly connects to ABB’s established control infrastructure using standard backplanes. -
Low Power Consumption
Efficient operation with minimal energy usage reduces system power load. -
Diagnostics and Monitoring
Onboard LEDs offer at-a-glance status for fault isolation and maintenance efficiency. -
Modular Design
Compact and hot-swappable design simplifies installation and maintenance. -
Time-Sensitive Communication
Handles real-time data transmission critical for synchronization across distributed processes.
Frequently Asked Questions (FAQs)
-
What is the main function of the IMMPI01 module?
It provides the interface between the Multifunction Processor (MFP) and the rest of the INFI 90 system, managing communications and control coordination. -
Can IMMPI01 be used in redundant systems?
Yes, it supports redundant configurations to ensure fault-tolerant and uninterrupted operations. -
Which processors are compatible with IMMPI01?
It is designed for use with the IMMFP01 and IMMFP02 multifunction processors. -
How does the IMMPI01 connect to the system?
It plugs into a dedicated slot within the INFI 90 chassis and communicates via internal bus systems. -
Is the IMMPI01 hot-swappable?
No, power must be turned off before replacing the module to ensure system integrity. -
Does it provide any diagnostic features?
Yes, LED indicators on the front panel offer real-time diagnostics and status updates. -
What is the power consumption of the module?
Less than 5 watts, making it energy-efficient. -
In what temperature range can the IMMPI01 operate?
It is rated for 0°C to 60°C operating temperature. -
What kind of communication protocols does it support?
It is compatible with INFI-NET and Plant Loop communication systems. -
Where is the IMMPI01 typically installed?
In ABB INFI 90 system racks within DCS (Distributed Control System) environments.
Related or Same Series Models
| Model Number | Description | Function | Compatibility |
|---|---|---|---|
| IMMFP01 | Multifunction Processor Module | Central logic processing | IMMPI01, INFI 90 |
| IMMFP02 | Enhanced Multifunction Processor | Improved memory and speed | IMMPI01, INFI 90 |
| INNIS21 | Network Interface Slave Module | INFI-NET communication interface | INFI 90 |
| INICT13A | INFI-NET to Plant Loop Interface Module | Network communication bridge | INFI 90 |
| INNPM11 | Network Processing Module | Communication management | Used with IMMPI01 |
| INNPM22 | Redundant Network Processing Module | Advanced networking | Redundant INFI 90 networks |
