Product Overview
The ABB Bailey IMSER02 Sequence of Events Recorder Module is a specialized module designed to capture and record the sequence of events in industrial automation systems. It plays a critical role in monitoring and diagnosing system behavior by logging precise timestamps of control events, alarms, and status changes in real-time. This is crucial in industries where process integrity, fault detection, and system analysis are essential, such as power plants, chemical processing, and oil & gas.
The IMSER02 module provides advanced event logging capabilities that allow operators and engineers to track critical sequences and timelines, making it a vital tool for troubleshooting, preventive maintenance, and ensuring system reliability. It integrates seamlessly into ABB’s INFI 90 and Symphony DCS systems, offering extensive compatibility and ensuring that it works efficiently in complex control environments.
Key Features
-
Real-time Event Logging: Captures precise sequences of events, including control system alarms, status changes, and state transitions.
-
High-Speed Timestamps: Provides highly accurate timestamps down to milliseconds, ensuring the reliability of event data.
-
Non-Volatile Storage: The event log is stored in non-volatile memory, ensuring data retention even in case of power failure.
-
Flexible Configuration: Users can configure which events and alarms to record, enabling tailored logging for specific applications.
-
High Capacity: Capable of logging thousands of events, providing sufficient data storage for long-term monitoring.
-
Easy Integration: Fully compatible with ABB INFI 90 and Symphony DCS systems, allowing for easy integration with existing control networks.
-
Event Triggering: Supports automatic event triggering based on predefined conditions such as process thresholds or operational states.
-
Diagnostic Functionality: Provides valuable diagnostic information for system health and performance tracking.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IMSER02 |
| Function | Sequence of Events Recorder Module |
| Event Logging Capacity | Up to 10,000 events (depending on configuration and event type) |
| Timestamp Accuracy | Millisecond accuracy (1 ms) |
| Storage Type | Non-volatile memory (flash) |
| Event Triggering | Configurable event triggers based on conditions |
| Communication Interface | Compatible with INFI 90 and Symphony DCS via system backplane |
| Operating Temperature | -20°C to +60°C (-4°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Power Supply | 24 VDC (nominal) |
| Power Consumption | Approx. 7 W |
| Dimensions | 260 x 25 x 180 mm |
| Weight | 0.84 kg |
| Mounting | Panel-mounted via standard backplane slot |
| Compliance | CE, UL, RoHS |
Industry Applications
The ABB Bailey IMSER02 Sequence of Events Recorder Module is critical in various sectors where event tracking and real-time monitoring are necessary for the operation and safety of industrial systems:
-
Power Generation: Used to log critical events such as turbine trips, generator failures, and switchgear operations.
-
Oil & Gas: Captures sequences of process alarms, wellhead shutdowns, and emergency shutdown events.
-
Chemical Processing: Essential for recording chemical reactor trips, safety interlocks, and system responses.
-
Water Treatment: Tracks changes in valve positions, pump operations, and water quality alarms.
-
Manufacturing: Records machine status changes, production line events, and equipment failure sequences.
-
Automated Control Systems: Used in SCADA systems to track operational events for system analysis.
Product Advantages
-
Real-Time Event Tracking: The IMSER02 ensures that every event, alarm, or status change is logged in real-time with millisecond accuracy.
-
Critical Data Retention: The use of non-volatile memory guarantees data integrity, even in the event of power interruptions.
-
Improved Troubleshooting: The event logs provide invaluable diagnostic data that can be used to quickly identify issues and resolve them, reducing downtime.
-
Customizable Logging: Users have the flexibility to define which events are recorded, allowing for tailored data collection specific to the system’s needs.
-
Seamless System Integration: With its compatibility with ABB INFI 90 and Symphony DCS systems, the IMSER02 can be easily integrated into existing infrastructure.
-
Scalable and Expandable: As your system grows, the IMSER02 module can be expanded or customized to fit the evolving requirements of your operation.
Frequently Asked Questions (FAQ)
-
Q: What is the primary function of the IMSER02 module?
A: The IMSER02 module records the sequence of events in real-time, logging system status changes, alarms, and critical operational data for analysis. -
Q: How accurate are the timestamps provided by the IMSER02?
A: The module provides timestamps with millisecond accuracy (1 ms), ensuring precise tracking of events. -
Q: What is the storage capacity of the IMSER02?
A: The IMSER02 can store up to 10,000 events (depending on the configuration and event type). -
Q: Is the IMSER02 compatible with other control systems?
A: Yes, it is fully compatible with INFI 90 and Symphony DCS control systems, making integration straightforward. -
Q: Can users configure the events to be logged?
A: Yes, the IMSER02 allows users to configure specific events, alarms, and statuses to be logged based on system needs. -
Q: What happens if there is a power failure?
A: The IMSER02 uses non-volatile memory to retain the logged events, ensuring that no data is lost in case of a power failure. -
Q: How is the IMSER02 mounted?
A: The module is panel-mounted via a standard backplane slot for easy installation and maintenance. -
Q: What are the key industries that use the IMSER02?
A: It is widely used in industries like power generation, oil & gas, chemical processing, and water treatment. -
Q: Is the IMSER02 a field-replaceable module?
A: Yes, the module is designed for easy replacement without affecting the overall system. -
Q: Can I customize the event logging frequency?
A: Yes, users can customize the frequency and conditions under which events are logged, tailoring the module to their specific operational needs.
Related or Similar ABB Bailey Modules
| Model | Description |
|---|---|
| IMRDO01 | Digital Output Module with event monitoring capabilities |
| IMRDI01 | Digital Input Module with sequence event recording |
| IMMFC03 | Multi-Function Controller with enhanced event logging |
| IMCPM02 | Communication Port Module for real-time event reporting |
| IMASI23 | Analog Input Module for precise event monitoring |
| IMAOI12 | Analog Output Module integrated with sequence events |
Popular ABB Modules (Same Brand)
| Model | Description |
|---|---|
| AI810 | High-Accuracy Analog Input Module |
| DO820 | Digital Output Module for high-density output systems |
| CI860 | Communication Interface for distributed control systems |
| PM860 | High-performance CPU for process automation |
| AC800M | Modular Process Controller for high-end automation |
| DO820 | Digital Output Module with extended diagnostic support |
