Product Introduction
The ABB Bailey NFAN01 Fan Assembly is a purpose-built cooling component designed for ABB Bailey INFI 90 and Net 90 Distributed Control Systems (DCS). As an essential part of maintaining proper thermal management inside control system enclosures, the NFAN01 provides forced air circulation to ensure consistent and reliable operation of sensitive electronic modules and processors.
The fan assembly is engineered for optimal airflow, durability, and minimal noise. It helps to dissipate heat buildup from high-density electronic modules—critical in environments where system uptime and equipment reliability are paramount. The NFAN01 fan unit ensures that temperature-sensitive components such as I/O modules, CPUs, and power supplies remain within their operational temperature limits, thereby extending their lifespan and minimizing downtime caused by overheating.
This robust assembly fits seamlessly into ABB Bailey chassis units and supports retrofit or expansion installations as well. With easy installation and compatibility with legacy systems, the NFAN01 ensures continued performance even in older DCS environments.
Product Parameters
| Parameter | Specification |
|---|---|
| Product Code | NFAN01 |
| Product Type | Fan Assembly |
| System Compatibility | ABB Bailey INFI 90 / Net 90 DCS Systems |
| Voltage Rating | 24 VDC |
| Power Consumption | 12 W typical |
| Airflow Capacity | 80 CFM (Cubic Feet per Minute) |
| Noise Level | < 45 dB(A) |
| Bearing Type | Ball Bearing |
| Lifespan | > 50,000 hours (continuous operation) |
| Installation | Direct-fit for ABB Bailey enclosures |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5% to 95% RH non-condensing |
| Vibration Resistance | 1.5 g RMS (5–500 Hz) |
| Certifications | CE, UL, CSA, RoHS Compliant |
| Dimensions (H x W x D) | 150 × 150 × 50 mm |
| Weight | 5.9 kg |
Applications
The NFAN01 Fan Assembly plays an indispensable role in a wide range of industrial environments where ABB Bailey control systems operate. It is commonly used in:
-
Power Generation Facilities: To maintain thermal stability in turbine control and boiler management systems.
-
Oil & Gas Platforms and Refineries: Ensuring proper cooling of process control units and communication modules.
-
Water & Wastewater Treatment Plants: Cooling automation equipment in high humidity or enclosed environments.
-
Chemical Manufacturing Plants: Providing ventilation for hazardous or high-temperature production lines.
-
Metals & Mining Operations: Ensuring optimal air circulation for long-running control modules in rugged conditions.
-
General Industrial Automation: Maintaining reliability of electronics in factory automation and robotic systems.
Advantages
-
Reliable Airflow: 80 CFM capacity keeps critical components cool even under full load conditions.
-
Long Operating Life: Rated for over 50,000 continuous operating hours, reducing maintenance needs.
-
Low Noise Emission: Quiet operation ensures minimal acoustic disturbance in control rooms and workspaces.
-
Ball Bearing Design: Increases durability and performance consistency over time.
-
Optimized for ABB Systems: Designed specifically for INFI 90 and Net 90 chassis, ensuring seamless compatibility.
-
Flexible Installation: Supports easy replacement or retrofit for existing Bailey systems.
-
Certified and Compliant: Fully certified for industrial use with CE, UL, CSA, and RoHS compliance.
-
Minimizes System Downtime: Maintains optimal thermal environment to extend the life of processors and I/O modules.
-
Compact and Lightweight: Small footprint facilitates easy handling during system upgrades or maintenance.
-
Energy Efficient: Low power consumption helps reduce system energy costs.
Frequently Asked Questions (FAQ)
-
What system platforms is the NFAN01 compatible with?
It is compatible with ABB Bailey INFI 90 and Net 90 DCS systems. -
What is the airflow capacity of the NFAN01?
It delivers an airflow of 80 CFM. -
What type of bearings does this fan assembly use?
The NFAN01 uses durable ball bearings for extended service life. -
Is the NFAN01 suitable for continuous operation?
Yes, it is rated for over 50,000 hours of continuous use. -
How noisy is the fan during operation?
The noise level is below 45 dB(A), making it very quiet. -
Can the NFAN01 be retrofitted into older Bailey systems?
Yes, it is designed for both new and legacy system enclosures. -
Is maintenance required frequently for the NFAN01?
Due to its ball-bearing design and high reliability, only periodic checks are typically needed. -
What is the voltage requirement for the NFAN01?
The fan operates at 24 VDC. -
How is the fan assembly mounted?
It is a direct-fit component designed for easy installation in ABB Bailey chassis. -
Does it include over-temperature protection?
The fan itself does not include built-in thermal protection, but it is used in conjunction with system-level temperature monitoring.
