Product Introduction
The ABB Bailey NIMP02 Multifunction Controller Terminal Module is an integral component of ABB’s Infi 90 Distributed Control System (DCS), offering advanced interface and control capabilities for various industrial automation applications. Designed to seamlessly integrate into complex control architectures, the NIMP02 module enables connectivity between controllers, I/O modules, and higher-level process systems.
As part of ABB’s highly reliable and field-proven Bailey Infi 90 series, the NIMP02 plays a key role in executing control strategies, processing real-time data, and ensuring effective system communication. It supports flexible programming, modular expansion, and offers a robust platform for continuous process control in industries such as power generation, oil & gas, chemical processing, and metals.
Thanks to its rugged design and proven performance in demanding environments, the NIMP02 Multifunction Controller Terminal Module is widely used in modern industrial control systems and continues to be a preferred solution for both system upgrades and legacy DCS support.
Product Specifications
| Specification | Details |
|---|---|
| Model | NIMP02 |
| Series | ABB Bailey Infi 90 |
| Product Type | Multifunction Controller Terminal Module |
| Function | Provides interface between controller and I/O |
| Communication Protocols | Proprietary Bailey Infi 90 bus; serial interfaces |
| Power Supply | Supplied via system backplane |
| I/O Compatibility | Infi 90 I/O modules |
| Status Indicators | LED diagnostics for module health |
| Mounting Type | DIN rail or rack-mounted |
| Compliance | CE, RoHS compliant |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (HxWxD) | 305 × 102 × 50 mm |
| Weight | 0.8 kg |
Applications
The ABB Bailey NIMP02 Multifunction Controller Terminal Module is suitable for a wide range of applications across various industries:
-
Power Generation
Control and monitoring of turbines, generators, boilers, and auxiliary systems. -
Oil & Gas
Distributed control of upstream, midstream, and downstream equipment including pumps, compressors, and separators. -
Chemical & Petrochemical
Continuous process control for reactors, heat exchangers, and distillation units. -
Metals & Mining
Automation of rolling mills, blast furnaces, and conveyor systems. -
Pulp & Paper
Control of paper machines, dryers, and chemical processing stages. -
Water & Wastewater Treatment
Supervisory control of pumps, valves, chemical dosing systems, and filtration equipment.
Advantages
The NIMP02 Multifunction Controller Terminal Module offers several significant benefits:
-
Reliable Data Interface
Ensures seamless communication between control processors and field I/O devices. -
Robust Design
Built to operate reliably in harsh industrial environments with wide temperature and humidity ranges. -
Flexible Integration
Compatible with both legacy and upgraded ABB Infi 90 systems. -
Modular and Scalable
Supports expansion of I/O points and integration into large-scale DCS architectures. -
Proven Field Performance
Established in numerous mission-critical installations worldwide. -
LED Diagnostics
Provides visual status indicators for quick troubleshooting and maintenance. -
Minimal Downtime
Hot-swappable for simplified maintenance without shutting down the entire system. -
Reduced Total Cost of Ownership
Long lifecycle and compatibility with existing systems lower upgrade costs.
FAQs
-
What is the function of the NIMP02 module?
It serves as an interface between the controller and connected I/O modules in an ABB Infi 90 DCS. -
Is the NIMP02 compatible with legacy Bailey Infi 90 systems?
Yes, it is fully compatible with legacy and upgraded Infi 90 installations. -
Does the module support hot-swapping?
Yes, the NIMP02 can be hot-swapped for maintenance purposes. -
What communication protocols does it use?
It communicates over the proprietary Bailey Infi 90 bus with serial connections to field devices. -
What kind of diagnostics does it provide?
The NIMP02 has LED indicators for monitoring module health and communication status. -
What is the operating temperature range?
0°C to +60°C. -
Is it CE compliant?
Yes, it meets CE and RoHS compliance standards. -
What industries commonly use this module?
Power generation, oil & gas, chemical processing, metals & mining, pulp & paper. -
Can it be integrated with modern ABB control systems?
Yes, it is often used in hybrid DCS configurations combining modern and legacy systems. -
What is the physical size of the module?
It measures 305 × 102 × 50 mmand weighs 0.8 kg.
Related Models (Same Series or Compatible)
| Model | Description | Key Features |
|---|---|---|
| IMMPI01 | Multifunction Processor Interface Module | Communication bridge between processors |
| IMFCS01 | Field Control Station Module | Controls field I/O in distributed architectures |
| IMCIS22 | Communication Interface Module | Serial communication module |
| IMASI03 | Analog Input Module | High-resolution analog input for process data |
| IMDSI12 | Digital Input Module | Digital signal interface |
| IMTDI01 | Termination and Distribution Interface Module | Manages signal routing |
Popular ABB Bailey Models
| Model | Description | Key Features |
|---|---|---|
| NIMP02 | Multifunction Controller Terminal Module | Core interface module for Infi 90 DCS |
| IMMPI01 | Processor Interface Module | Centralized communication hub |
| IMASI23 | High-Speed Analog Input Module | Precision analog data acquisition |
| IMDSO14 | Digital Output Module | Outputs control signals to field devices |
| INICT13A | Network Interface Controller | Links Infi 90 with higher-level systems |
| IMMFP12 | Main Process Controller Module | Executes complex control strategies |
