The ABB Bailey NKCL01-50 INFI-Net Cable is a precision-engineered communication cable designed specifically for ABB’s INFI-Net control network, which serves as the critical backbone of Bailey INFI 90 and Harmony Distributed Control Systems (DCS).
The NKCL01-50 model — with its 50 feet standard length — is ideally suited for medium-length interconnections between controllers, modules, and network components in industrial automation environments. Its dual-shielded construction ensures that data integrity is maintained even in environments with high electromagnetic interference (EMI) or mechanical vibration.
This cable delivers the consistent, noise-free transmission needed for high-speed, real-time process control. Whether deployed in existing ABB installations or as part of a new system rollout, the NKCL01-50 is widely trusted across industries for its reliability, durability, and ABB-certified performance.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Name | ABB Bailey NKCL01-50 INFI-Net Cable |
| Model Number | NKCL01-50 |
| Cable Type | Twisted pair, dual-shielded |
| Application | INFI-Net network communication cable |
| Cable Length | 50 feet |
| Conductor Material | Tinned copper |
| Insulation Material | High-temperature PVC or XLPE |
| Outer Jacket | Flame-retardant PVC |
| Shielding | Foil + braided shield |
| Maximum Data Rate | 2 Mbps (as per INFI-Net specification) |
| Operating Voltage | ≤ 300V |
| Nominal Impedance | 120 Ohms |
| Capacitance | Approx. 30 pF/ft |
| Operating Temperature Range | -20°C to +70°C (-4°F to 158°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to 185°F) |
| Minimum Bend Radius | 5x cable diameter |
| EMI/RFI Immunity | High (per IEC and CE standards) |
| Weight | 3 kg |
| Flame Rating | UL VW-1, CSA FT1 |
| Certifications | CE, UL, CSA compliant |
Applications
-
ABB Bailey INFI-Net communication backbone
-
Controller-to-controller communication in INFI 90 and Harmony DCS
-
I/O module-to-controller communication
-
Medium-run network segments in distributed control systems
-
Process control networks in Oil & Gas refining and petrochemicals
-
Power generation plant control systems (thermal, hydro, nuclear)
-
Industrial water treatment and wastewater plants
-
Chemical, pharmaceutical, and food & beverage automation systems
-
Pulp & Paper production networks
-
Metals, mining, and materials processing plants
Product Advantages
-
Ideal Medium-Length Option: 50-foot length provides flexibility for inter-rack and inter-cabinet connections.
-
Superior EMI/RFI Protection: Dual shielding (foil and braid) ensures signal integrity in electrically noisy environments.
-
ABB-Certified for INFI-Net: Fully tested and approved for use with ABB INFI 90 / Harmony DCS networks.
-
Industrial Durability: Withstands mechanical stress, vibration, and environmental extremes.
-
Stable High-Speed Transmission: Maintains low capacitance and correct impedance for INFI-Net’s 2 Mbps network performance.
-
Compact Design: Slim 10 mm diameter allows easy routing through control panels and conduits.
-
Flame Retardant: PVC jacket rated UL VW-1 and CSA FT1 for increased safety.
-
Long Service Life: Engineered for long-term use, with low maintenance needs.
-
Compatible with Existing Infrastructure: Seamlessly integrates into new or legacy INFI-Net systems.
-
Part of ABB Lifecycle Program: Fully supported in ABB’s modernization and lifecycle extension services.
Frequently Asked Questions (FAQ)
-
What is the primary purpose of the NKCL01-50 cable?
It provides reliable communication between controllers and modules on the ABB INFI-Net network. -
What is the standard length of this model?
The NKCL01-50 is 50 feet long. -
What network data rate does this cable support?
It supports the INFI-Net standard 2 Mbps network speed. -
Does the cable have EMI shielding?
Yes, it features foil and braided shielding for excellent EMI/RFI immunity. -
What is the nominal impedance of the NKCL01-50?
120 Ohms nominal, optimized for INFI-Net systems. -
Can I use this cable in retrofitted systems?
Yes, it is ideal for both new installations and upgrades of existing ABB Bailey DCS networks. -
Is the cable flexible for routing in control panels?
Yes, with a 10 mm diameter and bend radius of 5x cable diameter, it is very install-friendly. -
Is the cable approved by ABB?
Yes, it is fully ABB-certified and used worldwide in ABB INFI 90 and Harmony systems. -
Is this cable compliant with international standards?
Yes, it meets CE, UL, and CSA standards. -
What industries typically use this cable?
It is widely used in oil & gas, power, water treatment, chemicals, pulp & paper, metals & mining, and other heavy industries.
Related Models (Same Series or Product Line)
| Model Number | Description |
|---|---|
| NKCL01 | INFI-Net Cable (custom lengths, standard run) |
| NKCL01-100 | INFI-Net Cable (100 feet length) |
| NKCL02 | High-flex INFI-Net Cable |
| NKAS01-10 | Analog Module TU Cable (10 ft) |
| NKAS01-20 | Analog Module TU Cable (20 ft) |
| NIOP02 | I/O Power Panel |
Popular ABB Models (Same Brand)
| Model Number | Description |
|---|---|
| PM864AK01 | AC 800M Controller |
| CI855K01 | Industrial Ethernet Module |
| AI835A | Analog Input Module |
| PM861AK01 | AC 800M Controller |
| 07KT98C | Advant Controller |
| 07DC92 | Digital Output Module |
