The ABB Bailey NRDI01 L700710D1 Terminal Module is a high-reliability interface module designed for use in industrial control systems, specifically within the ABB Bailey INFI 90 and Symphony DCS platforms. This terminal module serves as the physical connection point for field wiring, ensuring safe, organized, and efficient integration of process signals into the control system.
Engineered to meet the rigorous demands of critical process industries, the NRDI01 L700710D1 provides robust connections for input and output signals, contributing to system reliability and streamlined maintenance. Its modular design allows for quick installation and easy replacement, making it a preferred choice for modern and legacy ABB control systems.
Key Features
-
Designed for ABB Bailey INFI 90 and Symphony control systems
-
Provides reliable and organized terminal connections for field wiring
-
Supports secure signal transmission between field devices and control modules
-
Durable industrial-grade construction for harsh environments
-
Compact, modular design for easy panel installation
-
Ensures high signal integrity and minimizes wiring errors
-
Facilitates efficient commissioning and maintenance
-
Compatible with existing ABB Bailey DCS infrastructure
-
Clear labeling and terminal identification for ease of use
-
Suitable for both analog and discrete signal interfaces
Technical Specifications
Specification | Details |
---|---|
Product Type | Terminal Module |
Brand | ABB |
Series | Bailey INFI 90 / Symphony |
Model Number | NRDI01 L700710D1 |
Function | Terminal block for field device connections |
Compatible Systems | ABB Bailey INFI 90, Symphony DCS |
Supported Signal Types | Analog and discrete signals |
Terminal Type | Screw-clamp connections |
Terminal Identification | Clearly labeled terminals for easy wiring |
Installation | DIN-rail or panel-mounted |
Housing Material | Industrial-grade plastic or metal casing |
Operating Temperature | 0°C to 60°C (32°F to 140°F) |
Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
Humidity | 5% to 95% non-condensing |
Shock Resistance | IEC 60068-2-27 compliant |
Vibration Resistance | IEC 60068-2-6 compliant |
Certifications | CE, UL, CSA |
Dimensions | 220 × 110 × 35 mm |
Weight | 0.5 kg |
Industry Applications
The ABB NRDI01 L700710D1 Terminal Module is commonly deployed across industries where secure, reliable, and efficient field signal connections are critical:
-
Oil & Gas Industry: Field signal termination for process control, safety systems, and monitoring
-
Power Generation: Terminal interface for turbine control, substations, and auxiliary systems
-
Chemical and Petrochemical Plants: Safe and organized wiring of process instrumentation
-
Water and Wastewater Treatment: Field signal connections for pumps, valves, and monitoring systems
-
Mining and Metals: Industrial-grade signal termination in harsh operating conditions
-
General Industrial Automation: Integration of sensors, actuators, and process control signals
Product Advantages
-
High Reliability: Ensures secure and stable connections between field devices and control systems
-
Efficient Installation: Modular and compact design simplifies panel assembly and maintenance
-
Robust Construction: Withstands industrial environments with temperature, vibration, and shock resistance
-
Signal Integrity: Maintains high-quality signal transmission with minimal interference
-
Clear Identification: Labeled terminals reduce wiring errors and enhance commissioning efficiency
-
Compatibility with ABB Systems: Seamlessly integrates with ABB Bailey INFI 90 and Symphony platforms
-
Versatile Signal Handling: Suitable for both analog and discrete field signals
-
Minimal Downtime: Easy replacement supports quick maintenance during system operation
-
Long Service Life: Built with durable materials to ensure longevity in industrial applications
-
Global Standards Compliance: Meets international quality and safety certifications
