Product Overview
The ABB Bailey NTCF02 is a Termination Unit from the Infi 90 series, designed for reliable signal routing between field devices and control systems. It provides a structured and organized connection interface for I/O modules, improving wiring efficiency and maintainability in industrial automation environments.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Type | Termination Unit |
| Series | Infi 90 |
| Model Number | NTCF02 |
| Function | Field device signal termination |
| Mounting | Panel Mounting |
| Terminal Type | Screw Terminals |
| Compatible Systems | Bailey Infi 90 |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (mm) | 127 x 178 x 178 |
| Weight | 0.2 kg |
Applications
-
Industrial process control systems
-
Power generation plants
-
Oil and gas automation
-
Water treatment facilities
-
Manufacturing automation systems
Key Advantages
-
Provides clear and reliable signal termination
-
Enhances wiring clarity and reduces field errors
-
Simplifies maintenance and module replacement
-
Compatible with Bailey Infi 90 architecture
-
Robust design suitable for industrial environments
Frequently Asked Questions (FAQs)
Q1: What is the primary function of the NTCF02 unit?
A1: It serves as a termination point for field wiring to interface with I/O modules in the Infi 90 control system.
Q2: Is the NTCF02 compatible with all Bailey Infi 90 modules?
A2: Yes, it is designed specifically to work with the Bailey Infi 90 system.
Q3: Can this unit be mounted in standard industrial enclosures?
A3: Yes, it is suitable for panel mounting in industrial environments.
Q4: What type of terminals does the unit use?
A4: It uses screw terminals for secure wiring connections.
Q5: Does NTCF02 require a power supply?
A5: No, it is a passive termination unit and does not require power.
Q6: Is the NTCF02 suitable for hazardous environments?
A6: It is not intrinsically safe but can be used in conjunction with certified enclosures.
Q7: What is the typical application environment for NTCF02?
A7: It is commonly used in process automation across industries like power, oil & gas, and water treatment.
Q8: Can it be used for both analog and digital signals?
A8: Yes, it supports termination for both analog and digital I/O signals.
Q9: How is wiring maintenance handled with NTCF02?
A9: The clear terminal layout allows easy identification and replacement of connections.
Q10: Are there replacement or alternate models for the NTCF02?
A10: Yes, related models like NTCF01 and newer variants may be used depending on system requirements.
Related or Similar Models
| Model | Description | Dimensions (mm) | Weight |
|---|---|---|---|
| NTCF01 | Infi 90 Termination Unit | 127 x 178 x 178 | 0.2 kg |
| NTDI01 | Digital I/O Termination Unit | 127 x 178 x 178 | 0.2 kg |
| NTAI03 | Analog Input Termination Unit | 127 x 178 x 178 | 0.2 kg |
| NTAO01 | Analog Output Termination Unit | 127 x 178 x 178 | 0.2 kg |
| NTCL01 | Logic Termination Unit | 127 x 178 x 178 | 0.2 kg |
| NTDO02 | Digital Output Termination Unit | 127 x 178 x 178 | 0.2 kg |
