Product Overview
The ABB Bailey NTCF03 is an Electric to Fiber Optic Termination Unit designed for use in the Infi 90 Distributed Control System (DCS). It provides seamless conversion from electrical signals to fiber optics, enhancing data transmission integrity and extending communication distances in industrial automation systems.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | NTCF03 |
| Function | Electric to Fiber Optic Termination |
| System Compatibility | Infi 90 DCS |
| Input Type | Electrical Signal |
| Output Type | Fiber Optic |
| Installation | Rack-mounted |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (W x H x D) | 127 x 178 x 178 mm |
| Weight | 0.2 kg |
Applications
-
Power generation control systems
-
Oil and gas automation
-
Industrial communication backbones
-
Factory and plant control rooms
-
Long-distance, noise-sensitive signal transmission
Product Advantages
-
Reliable electrical to fiber conversion
-
Enhanced signal integrity over long distances
-
Reduced EMI and RFI interference
-
Compact and lightweight design
-
Seamless integration with Infi 90 systems
-
Simple rack installation for quick deployment
Frequently Asked Questions (FAQ)
Q1: What is the function of the NTCF03 unit?
A1: It converts electrical signals into fiber optic signals for long-distance, interference-free communication.
Q2: Is NTCF03 compatible with all ABB Infi 90 systems?
A2: Yes, it is specifically designed for the ABB Bailey Infi 90 system.
Q3: What is the size of the NTCF03 module?
A3: The unit measures 127 x 178 x 178 mm.
Q4: How much does the NTCF03 weigh?
A4: It weighs 0.2 kg.
Q5: What installation method does it use?
A5: The NTCF03 is rack-mounted for easy integration into control systems.
Q6: Does it support bidirectional communication?
A6: No, it handles one-way conversion from electrical to fiber optic.
Q7: What are the operating conditions for this unit?
A7: It operates in temperatures ranging from 0°C to 60°C.
Q8: Can this unit be used in hazardous environments?
A8: It should be installed in controlled environments; consult ABB for use in hazardous areas.
Q9: What is the benefit of using fiber optics in industrial control?
A9: Fiber optics allow for longer transmission distances and immunity to electrical noise.
Q10: Is the NTCF03 hot-swappable?
A10: No, the system should be powered down before installation or replacement.
