The ABB Bailey SPSET01 module is a specialized digital input and time synchronization device designed to enhance the precision and reliability of event recording in industrial control systems. This module integrates Sequential Event Recorder (SOE) digital inputs with accurate time synchronization capabilities, ensuring that event timestamps are precise and consistent across the control network.
Ideal for critical monitoring and control applications, the SPSET01 facilitates the capture of discrete input signals associated with significant operational events, while synchronizing system clocks to maintain unified timing. This enables operators to analyze event sequences with exact timing, improving diagnostics, troubleshooting, and compliance with regulatory standards.
The SPSET01 module is compatible with the ABB Bailey INFI 90 platform, providing seamless integration and robust performance for time-sensitive process control environments.
Technical Specifications
| Specification | Description |
|---|---|
| Model Number | SPSET01 |
| Module Type | SOE Digital Input and Time Synchronization Module |
| Input Type | Digital Inputs (Discrete Inputs) |
| Number of Inputs | 16 |
| Time Synchronization | Supported via network protocol or external reference |
| Power Supply | 24 V DC typical |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 150 × 120 × 50 mm |
| Weight | 0.6 kg |
| Mounting Type | DIN rail or panel mount |
| Communication Interface | ABB Bailey proprietary protocol, Ethernet (optional) |
| Certifications | CE, UL, and other industry standards |
| Response Time | < 100 ms |
| Isolation | Galvanic isolation between inputs and communication |
Industry Applications
-
Power Generation Sequential Event Recording
-
Substation Automation and Protection Systems
-
Oil & Gas Process Monitoring
-
Critical Infrastructure Control Systems
-
Manufacturing Process Event Logging
-
Water and Wastewater Treatment Plants
-
Chemical Plant Safety Systems
-
Telecommunications Network Management
Key Advantages
-
Precise Event Timestamping: Ensures accurate logging of digital input events with synchronized timing.
-
Integration with INFI 90: Seamless compatibility with ABB Bailey control systems simplifies system design.
-
Multiple Digital Inputs: Supports up to 16 discrete inputs for broad monitoring capability.
-
Robust Environmental Tolerance: Operates reliably in a wide temperature and humidity range.
-
Time Synchronization Support: Maintains accurate system-wide timing through network or external references.
-
Galvanic Isolation: Protects signals and communication interfaces from electrical interference.
-
Compact and Easy to Install: Fits in standard control cabinets with DIN rail or panel mounting.
-
Industry Certified: Complies with major international safety and performance standards.
