Product Introduction
The ABB CI501-PNIO 1SAP220600R0001 Interface Module is a key component in ABB’s industrial automation systems, providing essential communication capabilities between PROFIBUS DP networks and Ethernet-based systems. This module plays a crucial role in facilitating seamless data transfer, ensuring reliable communication between field devices, controllers, and supervisory systems in automated environments.
With its compact and robust design, the CI501-PNIO module is designed to handle demanding industrial applications. It supports high-speed communication, allowing real-time data exchange across industrial systems, and enabling operators to control and monitor processes efficiently. Whether used in manufacturing, energy, water treatment, or chemical processing, this interface module ensures high data integrity and operational reliability.
The CI501-PNIO is engineered to integrate effortlessly into ABB’s AC 800M control systems and 800xA systems, enhancing the scalability and flexibility of the network. Its ability to bridge different communication protocols makes it an ideal solution for modernizing existing control systems while ensuring compatibility with legacy infrastructure.
Product Specifications
| Parameter | Details |
|---|---|
| Product Name | CI501-PNIO Interface Module |
| Product Code | 1SAP220600R0001 |
| Module Type | Communication Interface Module |
| Dimensions (L x W x H) | 62 x 76 x 67.5 mm |
| Weight | 0.136 kg |
| Supply Voltage | 24 VDC |
| Power Consumption | Approx. 2.5 W |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Type | DIN Rail |
| Communication Protocols | PROFIBUS DP, Ethernet/IP, Modbus, TCP/IP |
| Response Time | < 10 ms for real-time communication |
| Redundancy | Yes, supports redundant network configurations |
| Compatibility | ABB AC 800M, ABB 800xA systems |
| Ports | 1 x Ethernet, 1 x PROFIBUS DP |
Product Applications
The ABB CI501-PNIO 1SAP220600R0001 Interface Module serves a variety of essential functions across different industries. Some of its key applications include:
-
Industrial Automation: Used to bridge communication between PROFIBUS DP and Ethernet-based control systems, allowing for seamless data transfer and integration within DCS (Distributed Control Systems).
-
Manufacturing and Production: It is used in manufacturing plants, enabling quick and reliable data transfer between the production lines, PLCs, and central control systems, facilitating real-time monitoring and control.
-
Energy and Utilities: In power plants, the CI501-PNIO ensures smooth communication between supervisory control and field devices, improving system reliability and minimizing downtime. It is also used for SCADA systems in energy distribution.
-
Chemical and Process Control: The interface module is used in chemical processing and oil & gas applications to maintain communication between various plant components and the central control systems.
-
Water and Wastewater Management: The CI501-PNIO supports real-time communication in water treatment facilities to monitor and control pumps, sensors, and valves, helping maintain system efficiency.
-
Building Automation: In smart buildings, the module enables communication between building management systems (BMS) and field devices such as HVAC systems, lighting, and security systems.
Product Advantages
-
High-Speed Data Transfer: With support for Ethernet/IP and PROFIBUS DP, the CI501-PNIO offers fast data communication, ensuring real-time control and monitoring of automated processes.
-
Compact and Efficient Design: The module is compact, measuring just 62 x 76 x 67.5 mm and weighing 0.136 kg, making it easy to install in limited space within control panels.
-
Seamless Integration: Designed to integrate smoothly with ABB’s AC 800M and 800xA systems, the CI501-PNIO module enhances the performance and scalability of industrial control systems.
-
Protocol Flexibility: The module supports multiple communication protocols such as PROFIBUS DP, Modbus, and TCP/IP, providing flexibility for diverse industrial applications.
-
Redundancy for High Availability: With redundancy support, the CI501-PNIO ensures uninterrupted operation, improving the reliability of critical communication networks.
-
Wide Operating Temperature Range: The module operates in environments with temperatures ranging from -25°C to +60°C, making it suitable for harsh industrial conditions.
-
Low Power Consumption: Operating on a 24 VDC power supply with a consumption of only 2.5 W, the module is energy-efficient, making it a cost-effective solution for large-scale systems.
-
Easy Mounting: The module is designed for DIN rail mounting, ensuring easy installation in control cabinets and equipment racks.
Frequently Asked Questions (FAQs)
Q1: What communication protocols does the CI501-PNIO support?
A1: The CI501-PNIO supports PROFIBUS DP, Ethernet/IP, Modbus, and TCP/IP, providing versatility in industrial communication.
Q2: What is the power consumption of the CI501-PNIO?
A2: The CI501-PNIO consumes approximately 2.5 W of power, making it energy-efficient.
Q3: What is the weight of the CI501-PNIO module?
A3: The module weighs 0.136 kg, making it lightweight and easy to handle.
Q4: How is the CI501-PNIO mounted?
A4: The module can be easily mounted on a DIN rail, ensuring secure and simple installation.
Q5: What is the operating temperature range of the CI501-PNIO?
A5: The CI501-PNIO operates in a temperature range of -25°C to +60°C, making it suitable for a wide range of industrial environments.
Q6: Can the CI501-PNIO module be used for real-time communication?
A6: Yes, the module provides real-time communication with a response time of < 10 ms.
Q7: Is the CI501-PNIO compatible with ABB’s AC 800M and 800xA systems?
A7: Yes, the CI501-PNIO is fully compatible with ABB AC 800M and 800xA systems, providing seamless integration into industrial control systems.
Q8: Does the CI501-PNIO module support redundancy?
A8: Yes, the CI501-PNIO supports redundant network configurations, ensuring continuous communication and high availability.
Q9: What is the size of the CI501-PNIO module?
A9: The module has compact dimensions of 62 x 76 x 67.5 mm, making it easy to install in space-limited environments.
Q10: What industries can benefit from using the CI501-PNIO?
A10: The CI501-PNIO is ideal for industries such as manufacturing, energy, water treatment, chemical processing, and building automation.
Related Models from the Same Series
| Model | Description |
|---|---|
| CI502-PNIO | Advanced communication interface module with additional protocols |
| CI503 | High-performance industrial network interface for real-time control |
| CI504 | Compact communication module for modular control systems |
| CI505 | Ethernet-based interface for large industrial networks |
| CI506 | PROFIBUS communication module with extended range |
| CI507 | Modular network interface for distributed automation systems |
Popular ABB Models Across Product Lines
| Model | Description | Parameters |
|---|---|---|
| AI810 | Analog input module, 8 channels | 8 channels, 24 VDC, 16-bit resolution |
| DI810 | Digital input module, 16 channels | 16 channels, 24 VDC, IP20 |
| DO810 | Digital output module, 16 channels | 16 channels, 24 VDC, Max. 0.5 A per channel |
| AC800M PM864A | High-performance CPU for large-scale control | 2 Ethernet ports, 2GB memory, 24 VDC power |
| CI854AK01 | Communication interface for PROFIBUS DP | Supports PROFIBUS DP, 4 communication ports |
| TC810 | Ethernet communication adapter | 10/100 Mbps, Supports Ethernet/IP, 24 VDC |
