Product Introduction
The ABB CI630 (3BSE011000R1) is a high-performance communication interface module designed for ABB’s Advant Controller 110/160 and Advant Open Control System (OCS). It facilitates reliable and efficient data exchange over the Advant Fieldbus 100 (AF100) network, utilizing coaxial connectors and an integrated modem. This module plays a crucial role in ensuring seamless communication between control systems and field devices in industrial automation environments.
Product Specifications
| Specification | Details |
|---|---|
| Model | CI630 |
| Part Number | 3BSE011000R1 |
| Product Type | Communication Interface Module |
| Communication Protocol | Advant Fieldbus 100 (AF100) |
| Connectors | Coaxial |
| Integrated Modem | Yes |
| System Compatibility | Advant Controller 110/160, Advant OCS |
| Power Supply | Supplied by the control system backplane |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting | Rack-mounted |
| RoHS Compliance | Yes |
| Country of Origin | Sweden |
| Dimensions (W × H × D) | 252 x 273 x 40 mm |
| Weight | 1.42 kg |
Applications
The ABB CI630 module is utilized in various industrial automation environments where robust and efficient communication is essential. Key applications include:
-
Power Generation Systems
Facilitates communication between turbines, generators, and control units. -
Oil and Gas Processing Facilities
Ensures reliable data exchange in upstream and downstream processes. -
Water and Wastewater Treatment Plants
Enables seamless integration of sensors and actuators with control systems. -
Chemical and Petrochemical Plants
Supports communication in hazardous environments requiring high reliability. -
Manufacturing and Assembly Lines
Provides real-time data exchange for process control and monitoring. -
Energy Management Systems
Integrates various components for efficient energy distribution and control.
Product Advantages
-
Integrated Modem
Enhances communication capabilities over long distances without additional hardware. -
Robust Design
Built to withstand harsh industrial environments, ensuring long-term reliability. -
Easy Integration
Seamlessly integrates with ABB’s Advant Controller 110/160 and Advant OCS systems. -
Compact Form Factor
Space-saving design allows for efficient use of control cabinet space. -
High Data Integrity
Ensures accurate and reliable data transmission across the network. -
Compliance with Standards
Meets international standards for safety and environmental regulations.
Frequently Asked Questions (FAQ)
-
What is the primary function of the ABB CI630 module?
It serves as a communication interface between control systems and field devices over the AF100 network. -
Which systems are compatible with the CI630 module?
It is compatible with ABB’s Advant Controller 110/160 and Advant Open Control System (OCS). -
Does the CI630 module include an integrated modem?
Yes, it features an integrated modem for enhanced communication capabilities. -
What type of connectors does the CI630 use?
It utilizes coaxial connectors for network communication. -
Is the CI630 module compliant with RoHS regulations?
Yes, it complies with the EU Directive 2011/65/EU (RoHS). -
What are the operating temperature ranges for the CI630?
It operates within a temperature range of 0°C to +55°C. -
How is the CI630 module powered?
It is powered through the control system’s backplane. -
Can the CI630 be mounted in any orientation?
It is designed for rack-mounted installation; orientation should follow manufacturer guidelines. -
What is the weight of the CI630 module?
The module weighs 1.42 kg. -
Where is the CI630 module manufactured?
It is manufactured in Sweden.
Related or Similar Models from the Same Series
| Model | Description | Function |
|---|---|---|
| CI626V1 | AF100 Communication Interface Module | Facilitates communication over AF100 |
| CI627A | Bus Management Module | Manages communication buses |
| CI630K01 | AF100 Interface Kit to Single Line | Provides single-line AF100 connectivity |
| CI671 | Communication Interface Module | Supports various communication protocols |
| CI868A | AC 800M Communication Interface | Interfaces with AC 800M controller systems |
| CI853 | PROFIBUS-DP Module | Enables PROFIBUS communication |
Popular ABB Models
| Model | Product Type | Key Feature | Application Area |
|---|---|---|---|
| PM864 | AC800M CPU Module | High-speed processor for process automation | Distributed control systems (DCS) |
| AI810 | Analog Input Module | 8-channel, 0–20 mA input | Field signal acquisition |
| DO810 | Digital Output Module | 16-channel digital output, 24 V DC | Control of actuators |
| CI854AK01 | PROFIBUS-DP Communication Card | Supports PROFIBUS networks | Industrial communication |
| TU810V1 | Terminal Unit | Simplifies module wiring | Mounting of I/O modules |
| AC800M | Modular Controller | Flexible control system backbone | Large-scale automation systems |
