Product Introduction
The ABB CINT-01C (68989841) MC Interface Board is a critical component in the ABB automation and control systems portfolio. Designed to facilitate smooth and secure data communication between ABB control systems and Motor Controllers (MCs), this interface board ensures high-speed data exchange with minimal latency. Widely used in industrial automation, energy management, and process control applications, the CINT-01C offers outstanding compatibility with ABB’s proprietary hardware and software platforms, such as the Advant Master and Symphony series.
The board acts as a translator and bridge, enabling efficient interfacing between logic controllers and drive systems. Built with industrial-grade materials and tested to withstand harsh environmental conditions, the CINT-01C ensures long-term reliability and operational efficiency in demanding settings.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Name | CINT-01C |
| Part Number | 68989841 |
| Manufacturer | ABB |
| Product Type | MC Interface Board |
| Application | Communication interface between Control Unit and Motor Controller |
| Communication Type | Serial Communication, ABB-specific protocols |
| Installation | Rack-mounted or slot-based in ABB drive or controller unit |
| Power Supply Requirement | Supplied through host device (typically 5V DC) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Board Dimensions (LxWxH) | 160 × 100 × 25 mm |
| Weight | 0.16 kg |
| Compliance | CE, RoHS, UL |
| Connector Type | ABB-specific multipin connectors |
| Signal Type | Digital and serial signal conversion |
| Diagnostic LEDs | Yes |
Product Applications
The ABB CINT-01C MC Interface Board is widely used across various industrial and infrastructure environments, especially in the following applications:
-
Industrial Automation Systems – Used to connect motor control centers to central processing units for real-time motor operation.
-
Drive Systems – Interfaces with ABB motor drives for performance optimization and diagnostic feedback.
-
Power Plants – Communicates between control cabinets and motor controllers for synchronized operation.
-
Manufacturing Lines – Helps in high-speed data transfer from programmable logic controllers (PLCs) to motor controllers.
-
HVAC Systems – Enables data communication in building automation systems for motors in fans, compressors, and pumps.
-
Process Industries – Integrates with DCS/PLC systems in oil & gas, water treatment, and chemical sectors.
Product Advantages
The ABB CINT-01C offers a range of advantages that make it a preferred choice for industrial communication:
-
High Reliability: Manufactured to ABB’s rigorous quality standards for long-term use in critical systems.
-
Fast Data Transfer: Reduces latency in communication between control units and motor systems.
-
Compact Form Factor: Saves space in control cabinets, ideal for high-density installations.
-
Plug-and-Play Integration: Simplifies system setup and configuration with ABB devices.
-
Robust Environmental Tolerance: Designed for operation in harsh and fluctuating industrial conditions.
-
Low Maintenance: Minimal upkeep required due to solid-state design and high-quality connectors.
-
Diagnostic Capabilities: Built-in LEDs for quick visual system diagnostics.
-
Full ABB Ecosystem Compatibility: Seamlessly integrates with ABB drives, controllers, and automation software.
Frequently Asked Questions (FAQ)
-
What role does the CINT-01C board play in an ABB control system?
It acts as a communication link between the central controller and the motor control units, ensuring accurate data transfer and operational coordination. -
Can this interface board be used in high-vibration industrial environments?
Yes, the CINT-01C is designed for durability and can operate reliably under industrial conditions, including vibration and electrical noise. -
How do I know if the CINT-01C board is working correctly?
The board includes LED indicators that show the status of communication and power. ABB system software can also provide diagnostics. -
What should I do if the board stops communicating with the motor controller?
Check the power supply, cable connections, and system diagnostics. If needed, swap with a known working board to isolate the issue. -
Is special software required to configure the CINT-01C?
No dedicated software is required. Configuration is typically done through the ABB controller system software during setup. -
Can I hot-swap the CINT-01C during system operation?
No, the board should be replaced only when the system is powered down to avoid damage or communication errors. -
What are the signs of a failing or degraded interface board?
Irregular communication, flashing error LEDs, or loss of motor control signals may indicate a board fault. -
Does the board require regular maintenance?
It’s maintenance-free under normal operating conditions, though periodic inspection during scheduled system checks is recommended. -
Are there any compatibility concerns with older ABB drive systems?
The CINT-01C is designed for compatibility with a wide range of ABB motor control systems, but always verify compatibility with your specific hardware revision. -
What certifications does the board hold?
It complies with CE, RoHS, and UL standards.
Related Models from the Same Series or Function
| Model | Description | Dimensions (mm) | Weight |
|---|---|---|---|
| CINT-01B | Earlier version of MC interface board | 160 × 100 × 25 | 145 g |
| CINT-02C | Enhanced variant with broader communication support | 165 × 110 × 30 | 155 g |
| CI853 | Communication Interface Module for S800 I/O | 155 × 100 × 35 | 140 g |
| CI860 | PROFIBUS interface module | 160 × 100 × 35 | 145 g |
| CI801 | Basic communication interface | 150 × 90 × 25 | 130 g |
| CI871 | Dual channel serial communication board | 165 × 105 × 35 | 160 g |
Popular ABB Models Across Automation & Control Lines
| Model | Product Type | Application Area | Dimensions (mm) | Weight |
|---|---|---|---|---|
| AC800M | High-performance process controller | DCS, process automation | 260 × 200 × 50 | 1.2 kg |
| PM864A | CPU module for AC800M | PLC systems | 185 × 105 × 35 | 450 g |
| CI854AK01 | Profibus communication interface | AC 800M communication | 160 × 100 × 25 | 180 g |
| AI810 | Analog input module | S800 I/O series | 150 × 90 × 25 | 135 g |
| DO810 | Digital output module | Distributed control systems | 150 × 90 × 25 | 135 g |
| 07KT98 | Communication processor module | Advant Controller 31 | 200 × 100 × 30 | 180 g |
