The ABB CM579-ETHCAT (Order Code: 1SAP170902R0001) is a high-performance EtherCAT communication module designed to integrate seamlessly with ABB’s AC500 PLC family. This module functions as an EtherCAT Master, enabling ultra-fast, deterministic, and synchronized communication between the AC500 central processing unit and a wide array of EtherCAT-enabled slave devices such as I/O systems, drives, sensors, actuators, and motion control components.

EtherCAT (Ethernet for Control Automation Technology) is a real-time Ethernet fieldbus technology well-regarded for its speed, low latency, and precise synchronization. The CM579-ETHCAT leverages these capabilities, making it ideal for applications that require real-time control and tight coordination of distributed devices.

Built for industrial-grade environments, this module delivers not just performance, but also reliability, flexibility, and scalability—essential characteristics for modern automation systems across industries like manufacturing, robotics, packaging, and process control.

---

Product Specifications

---

Product Applications

The CM579-ETHCAT module is engineered to provide precise and real-time control in systems that demand synchronization and high-speed communication. Its versatility allows it to be used in a wide variety of industries and applications:

• Robotics and Motion Control – Ensures accurate positioning and motion synchronization

• High-Speed Packaging Lines – Ideal for controlling servo drives, I/O, and actuators in coordination

• Machine Tool Automation – Facilitates precise spindle and axis control

• Process Automation – Enables distributed control over remote field devices in chemical and pharmaceutical industries

• Material Handling Systems – Supports complex, high-performance conveyor and transport systems

• Automotive Assembly – Integrates sensors and actuators for efficient assembly line operations

Its EtherCAT protocol support ensures minimal communication delay and deterministic behavior, which are critical for these time-sensitive applications.

---

Product Advantages

• Ultra-Fast Performance: EtherCAT’s real-time capabilities allow cycle times as low as <1 ms.

• Highly Scalable: Capable of controlling thousands of slave devices with high data throughput.

• Compact Form Factor: Slim 30 mm width enables installation in space-constrained control cabinets.

• Flexible Network Topology: Supports line, tree, and daisy-chain configurations.

• Integrated Dual-Port Switch: No external switches required for daisy-chained devices.

• Seamless PLC Integration: Designed specifically for the ABB AC500 series, ensuring plug-and-play functionality.

• Robust Environmental Tolerance: Operates in harsh conditions typical of industrial sites.

• Low Power Draw: Efficient design reduces energy consumption and heat generation.

• User-Friendly Configuration: Supported by ABB’s Automation Builder engineering tool.

• Standards-Compliant: Fully EtherCAT-conformant, allowing use with third-party devices.

---

Frequently Asked Questions (FAQ)

1. What is the function of the ABB CM579-ETHCAT module?
   It serves as an EtherCAT master communication module for ABB AC500 PLCs.

2. What kind of devices can be connected to it?
   Any EtherCAT-compatible slave devices including drives, I/O modules, sensors, and actuators.

3. Is it compatible with third-party EtherCAT devices?
   Yes, the module is EtherCAT-conformant and interoperable with all certified EtherCAT slaves.

4. How do I configure the module?
   Configuration is performed using ABB’s Automation Builder software.

5. Can I use this module with an AC500-eCo PLC?
   The module is designed for AC500 PLCs; compatibility with AC500-eCo should be confirmed per system requirements.

6. Does the module support daisy-chaining?
   Yes, thanks to its dual Ethernet ports and integrated switch.

7. What is the maximum cable length between EtherCAT nodes?
   Typically 100 meters per segment, using standard Cat5e/Cat6 Ethernet cables.

8. How is the module powered?
   It is powered directly via the PLC backplane (5 V DC).

9. Is hot-plugging supported in EtherCAT networks?
   No, EtherCAT does not support hot-plugging; the network must be configured before power-on.

10. Does the module support diagnostic features?
    Yes, diagnostic data and error messages are accessible via Automation Builder and through system status LEDs.

---
