The ABB CP430 T (1SBP260195R1001) is a high-performance HMI (Human-Machine Interface) touch panel, designed for demanding industrial automation applications. Engineered with a sleek and robust build, this control panel provides intuitive operation and real-time data visualization for process control systems. It belongs to ABB’s CP400 series, well-known for its versatility, reliability, and ease of integration with PLCs and other field devices.
This model comes with a 5.7-inch TFT color touchscreen, offering sharp visuals and responsive interaction. With support for multiple communication protocols, including Modbus and OPC, the CP430 T enables seamless integration across complex automation systems.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | CP430 T |
| Part Number | 1SBP260195R1001 |
| Display Size | 5.7 inches (TFT LCD) |
| Display Resolution | 320 x 240 pixels |
| Touchscreen | Resistive touch |
| Processor | ARM RISC processor |
| Memory (RAM/Flash) | 64 MB RAM / 128 MB Flash |
| Communication Ports | 1x RS-232, 1x RS-485, 1x USB Host, 1x Ethernet |
| Supported Protocols | Modbus RTU, Modbus TCP/IP, OPC UA |
| Power Supply | 24V DC |
| Operating Temperature | -10°C to +60°C |
| Mounting Type | Panel Mount |
| Protection Rating | IP66 (front), IP20 (rear) |
| Certifications | CE, UL, cUL, RoHS |
| Dimensions (W x H x D) | 60 x 145 x 195 mm |
| Weight | 0.86 kg |
Applications
The ABB CP430 T control panel is well-suited for a variety of industrial automation scenarios, such as:
-
Manufacturing plants for machinery control
-
Food and beverage processing lines
-
HVAC systems for commercial buildings
-
Water treatment facilities
-
Packaging and logistics automation
-
Renewable energy systems (solar and wind control stations)
-
Building management systems (BMS)
Thanks to its flexible integration and user-friendly interface, it serves both OEMs and end-users seeking compact, yet powerful control solutions.
Product Advantages
-
Compact Design: The 5.7-inch screen offers space-saving installation while providing clear, easy-to-navigate interfaces.
-
Versatile Connectivity: Built-in Ethernet, serial ports, and USB allow for diverse protocol communications.
-
High Protection Grade: With IP66-rated front panel, it withstands dust, water jets, and harsh environments.
-
Easy Integration: Compatible with ABB PLCs and third-party systems via standard communication protocols.
-
Fast Configuration: Supported by ABB’s Panel Builder 600 software for intuitive HMI project development.
-
Reliable Operation: Solid-state design with no moving parts ensures long lifecycle and minimal maintenance.
-
Energy Efficient: Low power consumption makes it suitable for continuous operation.
-
Multi-language Support: Useful in international environments or globally distributed machinery.
-
Cost-effective: Offers excellent value for small to mid-range automation tasks.
Frequently Asked Questions (FAQ)
-
Q: What software is used to program the CP430 T panel?
A: The CP430 T is programmed using ABB Panel Builder 600, which offers drag-and-drop interface design and protocol configuration. -
Q: Does the CP430 T support real-time trend graphing and historical data storage?
A: It supports real-time trending, alarms, and event logging. However, historical data storage is limited to the internal memory and connected USB devices. For long-term storage, data should be exported to external systems. -
Q: Is remote access possible for the CP430 T?
A: Remote monitoring can be achieved when connected to an industrial network, though native remote desktop access may require additional setup. -
Q: Can I use USB devices with the CP430 T?
A: Yes, it has a USB Host port for data backup, logging, or external device communication. -
Q: What is the screen resolution quality like?
A: The panel features a 320 x 240 pixel TFT screen offering vivid colors and clear readability. -
Q: What is the typical lifespan of this control panel?
A: With no moving parts and industrial-grade components, it can last over 50,000 hours under normal operation. -
Q: Is the panel firmware upgradable?
A: Yes, firmware upgrades are supported via USB or Ethernet to ensure feature enhancements or bug fixes. -
Q: Can this panel be used in outdoor installations?
A: It can be used in protected outdoor enclosures; however, direct exposure to weather is not recommended. -
Q: Does the CP430 T support alarms and event logging?
A: Yes, it supports real-time alarms, event logs, and data trends. -
Q: What kind of maintenance does the device require?
A: Very minimal—mainly limited to cleaning the screen and ensuring secure wiring connections.
