Product Introduction
The ABB CP635 1SAP535100R0001 is a powerful, compact, and industrial-grade Human Machine Interface (HMI) designed for real-time operator control, monitoring, and diagnostics in demanding industrial environments. As part of the CP600 series, it brings a modern touchscreen interface to the field, ensuring intuitive access to automation systems while maintaining robust environmental resistance and compatibility with a wide range of industrial protocols.
This model is equipped with a high-resolution 15-inch TFT LCD display, multi-language support, vector graphics rendering, and wide connectivity, including Ethernet, USB, and serial ports. Designed to meet the needs of manufacturing, energy, infrastructure, and process industries, the CP635 provides reliable visualization for ABB PLCs and other industrial controllers.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Name | ABB CP635 Touch Screen HMI |
| Product Code | 1SAP535100R0001 |
| Display Type | TFT LCD with LED backlight |
| Display Size | 15 inches |
| Resolution | 1024 x 768 pixels (XGA) |
| Touch Technology | Analog resistive touchscreen |
| Processor | ARM Cortex-A8, 1 GHz |
| RAM Memory | 512 MB DDR3 |
| Flash Memory | 4 GB eMMC |
| Communication Ports | 2x Ethernet, 2x USB Host, 1x Serial (RS232/RS485), 1x SD slot |
| Supported Protocols | Modbus, Ethernet/IP, Profinet, OPC UA, MQTT |
| Operating System | Embedded Linux OS |
| Software Compatibility | ABB Panel Builder 600, CoDeSys |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -30°C to +70°C |
| Relative Humidity | 10–90% (non-condensing) |
| Supply Voltage | 24 V DC (18–32 V DC range) |
| Power Consumption | Max. 20 W |
| Protection Class (Front Panel) | IP66 |
| Mounting Method | Panel mount |
| Dimensions (W x H x D) | 280 × 120 × 210 mm |
| Weight | 1.2 kg |
| Certifications | CE, UL, cULus, RoHS, ATEX compliant (front) |
Product Applications
The ABB CP635 HMI is a versatile touchscreen interface designed to meet the high standards of industrial environments. It serves as a vital communication link between machine operators and automation control systems. Application areas include:
-
Factory Automation – Supervising PLCs and SCADA systems across production lines.
-
Food and Beverage Industry – Providing intuitive operation under hygienic standards.
-
Oil & Gas Processing – Ensuring reliable feedback in remote and hazardous locations.
-
Power and Energy Systems – Monitoring grid equipment and power substations.
-
Transportation and Infrastructure – Controlling intelligent traffic and tunnel systems.
-
Water Treatment Facilities – Managing pumps, filtration systems, and process control units.
Product Advantages
-
Large High-Resolution Display: A bright 15-inch XGA touchscreen with LED backlight ensures visibility in all lighting conditions.
-
Wide Connectivity: Supports multiple protocols and I/O ports, simplifying integration with ABB and third-party controllers.
-
Rugged Industrial Design: Designed with IP66-rated front panel and wide temperature tolerance for harsh environments.
-
Powerful Performance: Equipped with a high-speed ARM Cortex processor for smooth user interface rendering and communication.
-
Flexible Mounting & Maintenance: Panel mount-ready with user-friendly cable access and expandable memory through SD card.
-
Modern UI Experience: Compatible with ABB Panel Builder 600 for user-defined visualization with multi-language support.
-
Enhanced Security: Includes role-based access and encrypted data communication to protect against unauthorized access.
-
Scalability: Easily scales up or down depending on the complexity of the application, making it suitable for various system sizes.
Frequently Asked Questions (FAQ)
1. What is the main function of the ABB CP635 touch screen?
It serves as a Human Machine Interface (HMI) for controlling, monitoring, and diagnosing automation processes in real time.
2. Which software is used to configure the CP635?
The HMI is programmed using ABB Panel Builder 600 and can also integrate with CoDeSys for advanced control.
3. Can it operate in outdoor or dusty environments?
Yes, it has an IP66-rated front panel for water and dust protection, suitable for tough industrial environments.
4. Is the CP635 compatible with non-ABB controllers?
Yes, it supports Modbus, Profinet, Ethernet/IP, and other standard protocols to integrate with third-party devices.
5. What is the screen resolution of the CP635?
The screen resolution is 1024 x 768 pixels (XGA).
6. How is data stored or transferred?
It supports USB devices, SD cards, and Ethernet for data logging, program updates, and backups.
7. Is the touchscreen multi-touch?
No, the CP635 uses a resistive single-touch panel, which is suitable for environments requiring glove operation.
8. Can it be powered by standard 24V DC systems?
Yes, it accepts a wide input range of 18–32 V DC, ideal for industrial power supplies.
9. Does the device support remote access or control?
Yes, with appropriate network configuration, it can support remote diagnostics and control via web-based tools or VPN.
10. What kind of processor does the CP635 use?
It is equipped with an ARM Cortex-A8, 1 GHz processor for high-performance HMI operation.
Recommended Related Models (Same Series or Functional Category)
| Model | Display Size | Resolution | Touch Type | Key Difference |
|---|---|---|---|---|
| CP630 | 10.4 inches | 800 x 600 (SVGA) | Resistive | Smaller screen, compact applications |
| CP620 | 7 inches | 800 x 480 (WVGA) | Resistive | Entry-level model, budget-friendly |
| CP665 | 15 inches | 1024 x 768 (XGA) | Capacitive Multi-touch | Enhanced UI, high-end HMI |
| CP620-WEB | 7 inches | 800 x 480 (WVGA) | Resistive | Web-only HMI access |
| CP641 | 12.1 inches | 1024 x 768 (XGA) | Resistive | Mid-size, general-purpose HMI |
| CP651 | 10.4 inches | 800 x 600 (SVGA) | Capacitive Touch | Multi-touch support, modern design |
Popular ABB Models (Across Automation & Control)
| Model | Function | Series | Key Feature |
|---|---|---|---|
| AC500 PM573 | Programmable Logic Controller (PLC) | AC500 | Mid-range CPU with modular expansion |
| AI523 | Analog Input Module (4-channel) | S500 I/O | High-accuracy current/voltage input |
| DO520 | Digital Output Module (16 channels) | S500 I/O | Fast switching for digital actuators |
| CP665 | Advanced Multi-touch HMI | CP600-Pro | Capacitive touchscreen, enhanced graphics |
| CI581-PN | Communication Interface – Profinet | AC500 | Real-time Profinet fieldbus support |
| CM577-ETH | Communication Module – Ethernet | AC500 | Dual Ethernet port for remote access |
