ABB CS513 3BSE000435R1 Communication Module

Company Information
E-mail		sales@xmjzjsgs.com
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview

The ABB CS513 3BSE000435R1 is a communication module used within the ABB Advant Controller 400 Series, specifically designed to facilitate high-performance communication between process controllers and peripheral devices. It enables the integration of various fieldbus systems and I/O networks into ABB’s DCS environments such as Advant Master or System 800xA. Engineered with robust architecture and support for industrial protocols, the CS513 plays a critical role in distributed control system (DCS) networking by enhancing communication reliability and system scalability.

---

Key Features

• Seamless integration with ABB Advant Controller 410 and 450 systems

• Supports multiple communication protocols such as MODBUS, Advant Fieldbus 100 (AF100)

• High data throughput for real-time process communication

• Compact module form factor for space-saving control cabinets

• Plug-and-play capability with automated system configuration

• Diagnostic LEDs for communication and operational status

• Industrial-grade design for high EMI/EMC resistance and environmental endurance

---

Technical Specifications

---

Industry Applications

The ABB CS513 is widely used in process automation systems across industries where high-performance distributed control is critical:

• Oil & Gas – Pipeline automation, compressor station control

• Power Generation – Turbine and auxiliary systems communication

• Pulp & Paper – Real-time data networking between PLCs and I/O racks

• Chemical Processing – Integration of control networks and fieldbus sensors

• Water & Wastewater – Communication infrastructure for distributed monitoring

• Pharmaceuticals – Data acquisition and remote equipment networking

---

Product Advantages

• Protocol Versatility – Supports multiple industrial communication standards

• Integration-Ready – Designed for use in ABB’s proven control system architectures

• Space-Saving Design – Compact footprint for easy rack integration

• Long Lifecycle – Stable supply and service from ABB with long-term availability

• Diagnostic Capabilities – LED feedback simplifies troubleshooting and maintenance

• Proven Reliability – Industrial-grade design ensures continuous, uninterrupted operation

---

Frequently Asked Questions (FAQ)

1. What is the main function of the CS513 module?
   It provides communication capabilities between controllers and field devices over industrial protocols.

2. Which control systems support the CS513 module?
   It is compatible with ABB Advant Controller 410/450 systems and integrates into System 800xA.

3. Does it support MODBUS communication?
   Yes, it supports MODBUS and Advant Fieldbus 100 (AF100).

4. How is the CS513 powered?
   It is powered via the controller backplane, no separate external power supply is needed.

5. Can the CS513 be hot-swapped?
   No, the system must be powered down before removing or inserting the module.

6. What type of diagnostic indicators are available?
   LED indicators display power, communication, and fault status.

7. Is this module suitable for outdoor installations?
   No, it should be installed in a protected, indoor control cabinet.

8. Is CS513 backward compatible with older systems?
   Yes, it supports legacy Advant systems while integrating with modern ABB platforms.

9. Can this module be used in redundant configurations?
   Redundancy is supported when integrated with redundant controller architectures.

10. What is the typical lifecycle of the CS513 module?
    ABB provides long-term support, typically over 10+ years for industrial-grade modules.

---
