Product Introduction
The ABB DI581-S 1SAP284000R0001 is a robust Safety Digital Input Module designed for the AC500-S Safety PLC system. This module is part of ABB’s well-known range of high-reliability programmable logic controllers designed specifically for safety-critical applications. It provides digital input capabilities for safety-related systems, ensuring compliance with SIL 3 (Safety Integrity Level) requirements as per IEC 61508 and ISO 13849-1 standards.
The DI581-S module supports up to 8 digital input channels and is engineered with a compact footprint, making it suitable for modular and scalable control solutions. It is ideal for integration in machinery automation, process safety systems, and functional safety solutions across a variety of industrial sectors such as manufacturing, oil & gas, and power generation.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | DI581-S |
| Order Code | 1SAP284000R0001 |
| Product Type | Safety Digital Input Module |
| Number of Input Channels | 8 (Single-channel) or 4 (Dual-channel) |
| Input Type | Digital, PNP |
| Nominal Input Voltage | 24 V DC |
| Voltage Range | 14.4 to 30 V DC |
| Input Delay | Configurable (0.5 ms to 100 ms) |
| Safety Category | SIL 3, PL e, Cat. 4 |
| Diagnostics | Channel-level diagnostics |
| Interface | Module Bus (for AC500-S) |
| LED Indicators | Per channel status, diagnostics |
| Protection | Reverse polarity and short-circuit protection |
| Power Consumption | 1.2 W |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting Type | DIN rail |
| Enclosure Rating | IP20 |
| Dimensions (W x H x D) | 62 × 76 × 67.5 mm |
| Weight | 0.122 kg |
| Compliance Standards | IEC 61131, IEC 61508, ISO 13849-1 |
| Certifications | CE, TÜV, cULus |
