Product Introduction
The ABB DP620 3BHT300016R1 High Speed Counter module is a vital component within the ABB CI670 automation platform, designed to accurately count high-frequency pulses from sensors and other input devices in real-time. This module is engineered to handle rapid signal inputs with exceptional precision, making it ideal for applications requiring fast and reliable counting operations.
Built with industrial robustness, the DP620 supports multiple counting modes and flexible input configurations. It enables process automation systems to monitor and control machinery performance, production rates, and other critical parameters efficiently.
This module’s ability to process high-speed signals while maintaining accuracy ensures enhanced control system reliability and improved operational efficiency in demanding industrial environments.
Product Specifications
| Parameter | Description |
|---|---|
| Model Number | DP620 3BHT300016R1 |
| Type | High Speed Counter Module |
| Input Channels | Up to 8 channels, configurable |
| Counting Frequency | Up to 1 MHz (depending on input type) |
| Input Types Supported | TTL, HTL, and NAMUR compatible inputs |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 5 W |
| Operating Temperature | -20 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (WxHxD) | 252 x 273 x 40 mm |
| Weight | 1.635 kg |
| Mounting Type | DIN rail or panel mounting |
| Communication Interface | ABB proprietary bus interface |
| Certifications | CE, Industrial EMC standards |
Product Applications
The ABB DP620 High Speed Counter module is widely applied in various industries where precise and rapid counting is essential:
-
Manufacturing Automation: Monitoring production line speed, counting parts, and controlling assembly processes.
-
Packaging Industry: Ensuring accurate counting of packaged units and synchronization with conveyor speeds.
-
Material Handling: Tracking quantities of goods moved via conveyors or automated guided vehicles.
-
Textile Industry: Counting rotations or cycles for quality control and process optimization.
-
Printing Industry: Counting print cycles or sheet feeds for process consistency.
-
Energy Sector: Measuring rotational speed of turbines or generators for performance monitoring.
Product Advantages
-
High Frequency Counting: Supports up to 1 MHz input signals, suitable for fast-moving processes.
-
Multi-Channel Flexibility: Handles multiple inputs simultaneously with configurable settings.
-
Robust and Durable: Designed for harsh industrial environments with broad temperature tolerance.
-
Easy Integration: Compatible with ABB CI670 control systems for seamless automation.
-
Versatile Input Compatibility: Supports a variety of sensor input types including TTL, HTL, and NAMUR.
-
Accurate and Reliable: Provides precise counting for critical process control applications.
-
Diagnostic Features: LED indicators and diagnostic options help in quick fault detection and maintenance.
-
Compact Design: Efficient use of space with standard DIN rail and panel mounting options.
-
Energy Efficient: Low power consumption suitable for large-scale system integration.
Frequently Asked Questions (FAQ)
-
What is the maximum counting frequency supported by the DP620 module?
It supports input frequencies up to 1 MHz, depending on the input type and configuration. -
How many input channels does the DP620 have?
The module supports up to 8 configurable input channels for simultaneous counting tasks. -
Which input signal types are compatible with the DP620?
The module supports TTL, HTL, and NAMUR input signals, making it versatile for different sensor types. -
What power supply voltage does the DP620 require?
It operates on a standard 24 V DC power supply. -
Can the DP620 be mounted on DIN rails?
Yes, it supports both DIN rail and panel mounting to fit various installation requirements. -
What kind of environmental conditions can the DP620 withstand?
It operates within -20 °C to +70 °C and can handle up to 95% relative humidity without condensation. -
Is the DP620 module compatible with other ABB CI670 system components?
Yes, it integrates seamlessly with other modules in the CI670 automation system. -
Does the DP620 provide any diagnostic features?
Yes, it includes LED indicators for power, signal input, and fault detection. -
What measures does the DP620 have for signal error handling?
The module incorporates filtering and error detection to maintain signal integrity during high-speed counting. -
How is the module powered in large automation setups?
Typically, the power is supplied via the CI670 system’s centralized 24 V DC power source, ensuring stable operation.
Recommended Related Models (Same Series / Related ABB CI670 Modules)
| Model Number | Description | Key Feature |
|---|---|---|
| CI670 3BHT300017R1 | Bus Interface Module | High-speed communication bus |
| DP620 3BHT300016R1 | High Speed Counter Module | High-frequency pulse counting |
| CI670 3BHT300019R1 | I/O Interface Module | Analog and digital I/O support |
| CI670 3BHT300020R1 | Processor Module | Central control processing |
| CI670 3BHT300022R1 | Power Supply Module | 24 V DC power supply |
| CI670 3BHT300023R1 | Diagnostic Interface Module | System diagnostics and monitoring |
