Product Introduction
The ABB DSAO 130 57120001-FG is an advanced analog output module designed for integration with ABB’s Distributed Control Systems (DCS). This module is specifically engineered to provide high-precision analog output signals for a wide variety of industrial applications. The DSAO 130 ensures smooth and accurate control of field devices such as actuators, motors, and valves by converting digital control commands into reliable analog signals.
With the ability to support various output types, including current and voltage signals, the DSAO 130 serves as a critical component in automation systems. It is well-suited for industries where precise analog control is essential for operations, including manufacturing, energy management, and process control. The compact design, high accuracy, and excellent protection features make this module an ideal choice for demanding industrial environments.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | ABB DSAO 130 57120001-FG |
| Input Type | Analog Output |
| Dimensions | 324 x 18 x 225 mm |
| Weight | 0.45 kg |
| Signal Range | ±10 V, 0-20 mA, 4-20 mA |
| Signal Resolution | 16 bits |
| Output Channels | 8 Channels |
| Output Accuracy | ±0.1% of full scale |
| Sampling Rate | 50 samples per second |
| Power Supply | 24V DC ±20% |
| Operating Temperature | -20°C to 60°C |
| Mounting Type | DIN rail mounting |
| Protection | Over-voltage, Overcurrent |
Product Applications
The ABB DSAO 130 module is designed for a broad range of industrial applications where accurate analog signal output is required. Some of the key applications include:
-
Process Control Systems: Used to control process variables such as temperature, pressure, and flow in industries like chemical processing, pharmaceuticals, and food production.
-
Energy Management: Provides precise control signals for managing energy consumption in industrial settings, helping to optimize efficiency and reduce waste.
-
Automation Systems in Manufacturing: Controls various devices such as machines, conveyors, and actuators in automated production lines to ensure consistent operation.
-
Power Generation: Used to provide output signals for controlling power plant systems, including turbines, boilers, and generators.
-
HVAC Control: Provides control signals to HVAC systems for adjusting heating, cooling, and ventilation in commercial and industrial buildings.
-
Water and Wastewater Treatment: Controls actuators and valves in water treatment plants to maintain water quality by regulating flow and chemical dosing systems.
Product Advantages
-
High Precision and Accuracy: The DSAO 130 delivers an output accuracy of ±0.1% of full scale, making it ideal for applications requiring exact signal control.
-
Multiple Output Channels: With 8 output channels, the DSAO 130 can control multiple devices simultaneously, enhancing system flexibility and reducing the need for additional modules.
-
Flexible Signal Types: It supports various output signal types, including ±10V, 0-20 mA, and 4-20 mA, providing adaptability for different field devices.
-
Fast Sampling Rate: The module supports up to 50 samples per second, ensuring fast data processing and timely control adjustments in real-time applications.
-
Compact and Lightweight Design: The module is compact (324 x 18 x 225 mm) and weighs just 0.45 kg, allowing for easy integration into control panels with limited space.
-
Protection Features: The DSAO 130 includes over-voltage and overcurrent protection, ensuring the module’s durability and safeguarding the entire system from electrical faults.
-
Easy Installation: The module is designed for DIN rail mounting, which simplifies the installation process and makes it easy to integrate into existing systems.
FAQ
1. What types of output signals can the DSAO 130 module provide?
The DSAO 130 can provide several output signals, including ±10V, 0-20mA, and 4-20mA, offering flexibility for a range of applications.
2. How many output channels does the DSAO 130 support?
The module supports up to 8 output channels, allowing for the simultaneous control of multiple devices.
3. What is the accuracy of the output signals from the DSAO 130?
The DSAO 130 provides an output accuracy of ±0.1% of full scale, ensuring precise and reliable control in critical applications.
4. What is the sampling rate of the DSAO 130?
The DSAO 130 supports a sampling rate of 50 samples per second, providing quick and responsive output in real-time systems.
5. What power supply does the DSAO 130 require?
The module operates on a 24V DC power supply with a ±20% tolerance.
6. Can the DSAO 130 be used in extreme temperature environments?
Yes, the DSAO 130 is designed to operate within a temperature range of -20°C to 60°C, making it suitable for a wide range of industrial settings.
7. How is the DSAO 130 mounted?
The DSAO 130 can be mounted directly onto a DIN rail, making installation easy and efficient.
8. What protection features are built into the DSAO 130?
The module includes built-in over-voltage and overcurrent protection, ensuring safety and durability during operation.
9. What industries use the ABB DSAO 130 module?
The DSAO 130 is used in industries such as process control, energy management, manufacturing automation, power generation, HVAC, and water treatment.
10. Can the DSAO 130 control multiple devices at once?
Yes, with 8 output channels, the DSAO 130 can control multiple devices simultaneously, making it ideal for complex automation systems.
Recommended Models
| Model Number | Description |
|---|---|
| DSAO 120 | DS Analog Output Module, 8 Channels |
| DSAO 121 | High-Resolution Analog Output Module |
| DSAO 122 | Multi-Output Analog Module |
| DSAO 130 | Universal Analog Output Module |
| DSAO 150 | High-Speed Analog Output Module |
| DSAO 200 | Compact Analog Output Module |
Popular ABB Models
| Model Number | Description |
|---|---|
| DSAI 301 | DS Analog Input Module |
| DSAI 302 | High-Speed Analog Input Module |
| DSAI 303 | Voltage & Current Analog Input Module |
| DSAO 100 | Basic Analog Output Module |
| DSAO 130 | Universal Analog Output Module |
| DSAI 100 | Digital Input & Output Module |
