Product Introduction
The ABB DSBB110A 57330001-Y is a highly efficient main shielding module designed to protect electrical systems from electromagnetic interference (EMI) and radio frequency interference (RFI). This module is a critical component in ensuring that sensitive electrical equipment operates free from external electrical noise and disruptions. It is particularly important in industries where high-frequency signals can cause operational failures or inaccuracies in automated processes.
The DSBB110A features advanced shielding technology, providing both physical and electrical protection to various control systems and industrial machinery. It serves as an essential element in protecting sensitive circuits, ensuring the long-term reliability and optimal performance of industrial automation systems. With its compact design and robust functionality, it is well-suited for integration into a wide range of applications across diverse industries.
Product Parameters
| Parameter | Specification |
|---|---|
| Model | DSBB110A |
| Part Number | 57330001-Y |
| Dimensions | 215 × 160 × 30 mm |
| Weight | 0.28 kg |
| Frequency Range | 50 Hz to 60 Hz |
| Shielding Effectiveness | ≥ 40 dB |
| Input Voltage | 24 VDC |
| Output Voltage | 24 VDC |
| Mounting Type | DIN Rail Mount |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to +70°C |
| Application Environment | Industrial Control Systems |
Product Applications
The ABB DSBB110A Main Shielding Module is used in a variety of industrial environments where electrical noise and electromagnetic interference (EMI) could disrupt system performance. Some key applications include:
-
Industrial Automation Systems
The DSBB110A is used to shield control circuits, PLCs, and other industrial automation systems from external EMI, ensuring stable operation and preventing malfunction due to noise. -
Manufacturing
In manufacturing environments, especially in automated lines or robotics, the module protects systems from interference that could otherwise lead to errors or downtime. -
Power Distribution Systems
Used in power distribution panels to maintain clean and stable signals in environments with heavy electrical equipment. -
Process Control Systems
The module ensures reliable data transmission in process control systems where precise and uninterrupted communication is critical. -
Renewable Energy Systems
In wind turbine and solar energy systems, it prevents electrical interference that may otherwise affect power conversion efficiency or system stability. -
Telecommunication
Prevents EMI from affecting communication equipment, improving signal integrity in telecommunication networks.
Product Advantages
-
Superior Shielding Effectiveness
The DSBB110A offers shielding effectiveness of ≥ 40 dB, ensuring excellent protection against EMI and RFI, which helps maintain stable operation of sensitive electrical equipment. -
Compact and Lightweight Design
With dimensions of 215 × 160 × 30 mm and a weight of only 0.28 kg, it is easy to integrate into existing systems without occupying significant space. -
Wide Frequency Range
The module operates effectively across a frequency range of 50 Hz to 60 Hz, making it versatile for different industrial and automation applications. -
Durable Protection Rating
With an IP20 protection rating, the module is resistant to dust and solid objects larger than 12 mm, making it suitable for standard industrial environments. -
Efficient Power Handling
The module is capable of working with 24 VDC input and output, ensuring reliable power management and optimal energy usage. -
Wide Operating Temperature Range
The DSBB110A can operate in a wide temperature range from -20°C to +70°C, making it suitable for diverse industrial environments, including both hot and cold climates. -
Easy Installation
It can be mounted on a DIN rail, allowing for quick and secure installation in control panels or other industrial equipment setups. -
Improved System Longevity
By reducing EMI and RFI, the DSBB110A protects sensitive equipment, reducing wear and tear and extending the service life of systems. -
Low Maintenance Requirements
With no moving parts and a robust design, the DSBB110A requires minimal maintenance, reducing operational downtime and maintenance costs. -
Versatile Use
The module is highly adaptable, making it suitable for a wide range of industries, including manufacturing, automation, power systems, and telecommunications.
