Product Introduction
The ABB DSCS 140 (Part No. 57520001-EV) is a digital communication interface module designed for use in ABB’s industrial automation and control systems, particularly within the Symphony and INFI 90 distributed control platforms. It provides seamless high-speed communication between control stations, operator stations, and engineering workstations via an Ethernet or serial network.
This module plays a critical role in enabling data exchange between process control units and supervisory systems, making it an essential component in complex control architectures where stability, redundancy, and data integrity are crucial.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | DSCS 140 |
| Part Number | 57520001-EV |
| Manufacturer | ABB |
| Function | Communication Interface Module |
| Network Support | Ethernet / Serial communication |
| Supported Protocols | TCP/IP, INFI-NET, Harmony |
| Compatible Systems | Symphony DCI, INFI 90 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Power Supply | 5 V DC (typically powered by host rack) |
| Mounting Type | DIN rail or chassis-mount (modular rack) |
| Dimensions | 337.5 x 22.5 x 234mm |
| Weight | 0.6 kg |
| Cooling | Passive air-cooled |
| Status Indicators | LEDs for communication & fault status |
| Certification | CE, UL, RoHS compliant |
Product Applications
-
Distributed Control Systems (DCS): The DSCS 140 is primarily used in ABB’s Symphony and INFI 90 series DCS architectures.
-
Power Plants: Facilitates centralized communication in thermal and hydroelectric plants.
-
Chemical and Petrochemical Plants: Interfaces between supervisory systems and process controls.
-
Pulp and Paper Industry: Used for real-time process management and monitoring.
-
Oil & Gas Facilities: Critical in data transmission for hazardous and remote locations.
-
Water Treatment Systems: Used for SCADA communication with field sensors and actuators.
Product Advantages
-
High Communication Reliability: Designed to ensure uninterrupted data transfer in industrial networks.
-
System Compatibility: Fully compatible with existing ABB DCS platforms, allowing easy integration or upgrades.
-
Long-Term Support: Backed by ABB’s extensive lifecycle support for legacy systems.
-
Robust Construction: Built to withstand harsh environmental conditions.
-
Real-Time Data Exchange: Enables low-latency communication between controllers and stations.
-
Diagnostic Indicators: On-board LED status indicators provide quick diagnostics.
10 De-AI Style FAQs (Q&A Format)
Q1: What is the primary function of the DSCS 140 module?
A1: The DSCS 140 is used for digital communication within ABB control systems, enabling data transfer across distributed systems via Ethernet or serial links.
Q2: Is the DSCS 140 compatible with ABB Symphony DCI and INFI 90 systems?
A2: Yes, it is specifically designed to interface with both Symphony DCI and INFI 90 platforms.
Q3: How is the DSCS 140 installed?
A3: It is typically installed in a modular rack using chassis-mounting or on a DIN rail, depending on the system layout.
Q4: Does the module support redundant communication paths?
A4: Yes, the module supports redundant paths to enhance system reliability.
Q5: What type of protocols does the DSCS 140 handle?
A5: It supports TCP/IP, INFI-NET, and ABB’s proprietary Harmony protocols.
Q6: Can it be used in outdoor environments?
A6: It should be housed within a protected control cabinet if used outdoors, as it is not IP-rated for standalone exposure.
Q7: What is the typical operating voltage for this module?
A7: It operates on 5 V DC, usually powered from the host backplane.
Q8: Are there visual indicators for faults or communication status?
A8: Yes, the module includes front-panel LEDs to show real-time status of communication and faults.
Q9: What industries commonly use the DSCS 140?
A9: Power generation, oil and gas, water treatment, and process manufacturing industries.
Q10: Is the DSCS 140 still supported by ABB?
A10: Yes, ABB offers ongoing lifecycle and replacement support for this module.
