Product Introduction
The ABB DSDO 131 (57160001-KX) is a versatile digital output module within ABB’s S800 I/O system, designed to provide efficient and reliable digital signal output to control a wide variety of field devices. With its robust performance and compact design, the DSDO 131 is ideal for applications in industries where precise digital control and real-time responses are crucial.
This module allows for precise control of actuators, relays, solenoids, and other digital devices, ensuring smooth operation of industrial automation systems. The DSDO 131 is specifically engineered to integrate seamlessly with ABB’s S800 I/O systems, offering superior compatibility and scalability within complex automation setups. Whether for use in power generation, manufacturing, chemical processing, or other industrial sectors, this module guarantees reliable performance in diverse operating conditions.
Designed to withstand demanding environments, the DSDO 131 module operates efficiently even in extreme temperatures and humid conditions. It supports various industrial communication protocols, making it an essential component for modern automated systems that require dependable, high-speed digital output for system control and monitoring.
Product Parameters
| Parameter | Specification |
|---|---|
| Product Name | DSDO 131 Digital Output Module |
| Part Number | 57160001-KX |
| System Compatibility | ABB S800 I/O System |
| Communication Protocol | PROFIBUS-DP |
| Power Supply | 24 V DC |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting Type | DIN Rail |
| Dimensions (W x H x D) | 324 x 18 x 225 mm |
| Weight | 0.7 kg |
| Protection Class | IP20 |
| Certifications | CE, UL, RoHS Compliant |
Product Applications
The DSDO 131 digital output module is used across a wide variety of industries that require precise digital control for machinery, actuators, and other field devices. Some key applications include:
-
Power Generation: Used for controlling relays, actuators, and other critical devices in power plants, including thermal, hydroelectric, and renewable energy plants.
-
Oil & Gas: Provides essential control for actuators, valves, and pumps in upstream and downstream oil and gas operations.
-
Chemical Processing: Controls digital devices like pumps, mixers, and valves in chemical plants, ensuring smooth process flow and automation.
-
Water and Wastewater Treatment: Used in systems for controlling valves and other field devices in water filtration, chemical dosing, and monitoring systems.
-
Industrial Automation: Used in manufacturing environments to control production equipment, robots, and packaging lines for efficient operations.
-
Food & Beverage Industry: Controls digital field devices such as conveyors, packaging machines, and other critical process controls to ensure consistent product quality and compliance.
Product Advantages
-
Reliable and Accurate Digital Control: The DSDO 131 ensures high-quality, stable digital output for controlling actuators, relays, and other field devices with precision.
-
Space-Efficient Design: Its compact design (324 x 18 x 225 mm) makes it ideal for installations where space is limited, providing high functionality without occupying much space in control cabinets.
-
Wide Operating Temperature Range: With an operating temperature range of -25°C to +70°C, the module is suitable for use in extreme environments, including both high and low-temperature settings.
-
High Compatibility: The DSDO 131 is fully compatible with ABB’s S800 I/O system, ensuring easy integration into existing systems for extended scalability.
-
Robust Performance: Designed for reliable operation in challenging industrial environments, it performs consistently under a wide range of temperature and humidity conditions (5% to 95% relative humidity).
-
Easy Installation: The module can be easily mounted on a DIN rail, making installation simple and reducing system downtime during setup and maintenance.
-
Long-Term Durability: Built to last with industrial-grade materials, the DSDO 131 guarantees long-term performance and reliability in harsh industrial settings.
Frequently Asked Questions (FAQ)
Q1: What is the main function of the DSDO 131 module?
A1: The DSDO 131 is a digital output module that provides digital control signals to field devices such as actuators, solenoids, and relays, enabling automation systems to control external devices with high accuracy.
Q2: What communication protocol does the DSDO 131 use?
A2: The module uses the PROFIBUS-DP communication protocol for fast and reliable data exchange between field devices and the control system.
Q3: What are the dimensions and weight of the DSDO 131?
A3: The DSDO 131 measures 324 x 18 x 225 mm and weighs 0.7 kg.
Q4: How is the DSDO 131 mounted?
A4: The module is designed for DIN rail mounting, making it easy to install in standard industrial control cabinets.
Q5: What power supply does the DSDO 131 require?
A5: The module requires a 24 V DC power supply to operate effectively.
Q6: What is the operating temperature range of the DSDO 131?
A6: The module can operate within a temperature range of -25°C to +70°C, making it suitable for use in a variety of industrial environments.
Q7: Is the DSDO 131 suitable for high-humidity environments?
A7: Yes, it can operate in environments with a humidity range of 5% to 95%, as long as the humidity is non-condensing.
Q8: Can the DSDO 131 be used in the oil and gas industry?
A8: Yes, the module is ideal for oil & gas applications where reliable control of actuators, valves, and pumps is essential.
Q9: What certifications does the DSDO 131 have?
A9: The DSDO 131 is CE, UL, and RoHS certified, ensuring compliance with international standards for safety and environmental responsibility.
Q10: How does the DSDO 131 benefit industrial automation systems?
A10: The DSDO 131 provides reliable, real-time digital control for industrial automation systems, ensuring smooth and efficient operations in sectors such as manufacturing, water treatment, and chemical processing.
Related Models (Same Series or Interface-Compatible)
| Model | Description | Dimensions (mm) | Weight |
|---|---|---|---|
| DSDO 120 | 8-Channel Digital Output Module | 342 x 22.5 x 238.5 | 0.46 kg |
| DSDO 110 | 4-Channel Digital Output Module | 342 x 22.5 x 238.5 | 0.45 kg |
| DSDO 140 | 16-Channel Digital Output Module | 342 x 22.5 x 238.5 | 0.48 kg |
| DSDO 150 | High-Speed Digital Output Module | 342 x 22.5 x 238.5 | 0.50 kg |
| DSDO 160 | High-Density Digital Output Module | 342 x 22.5 x 238.5 | 0.52 kg |
| DSDO 170 | Digital Output Module for Harsh Environments | 342 x 22.5 x 238.5 | 0.55 kg |
