Product Introduction
The ABB DSTA171 3BSE018311R1 is a high-performance communication interface module designed for use in ABB’s Advant OCS control systems. As part of ABB’s robust automation suite, this unit provides a critical link between system components and facilitates real-time data communication and signal processing. Its industrial-grade reliability and consistent performance make it an essential component in process control, manufacturing, and heavy industry automation.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | ABB DSTA171 |
| Part Number | 3BSE018311R1 |
| Product Type | Communication Interface Module |
| Series | Advant OCS |
| Communication Protocol | Advant Fieldbus 100 (AF100) |
| Number of Channels | 1 channel |
| Input/Output Type | Serial communication interface |
| Mounting Type | DIN rail or rack mounting |
| Dimensions | 234 x 45 x 99 mm |
| Weight | 0.12 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Power Supply | Supplied via system bus |
| Certifications | CE, RoHS, ISO9001 |
| Compatible Systems | Advant Controller 31, 400 Series, etc. |
Product Application
The DSTA171 module is primarily used in process control systems across industries such as:
-
Oil & Gas: For reliable data transmission between control units and field devices.
-
Power Generation: Enables smooth communication between DCS components.
-
Metals & Mining: Used in rugged environments where stability and fault tolerance are essential.
-
Chemical & Petrochemical: Assists in precise monitoring and control of batch processing.
-
Paper & Pulp: Facilitates data exchange in fully automated production lines.
Product Advantages
-
Industrial Reliability: Designed to withstand harsh industrial environments with superior thermal tolerance and vibration resistance.
-
Seamless Integration: Fully compatible with ABB’s Advant Controller platforms, ensuring ease of deployment.
-
Stable Communication: Uses ABB’s AF100 protocol for efficient and error-free data exchange.
-
Long Product Lifecycle: ABB ensures long-term support and availability for legacy systems.
-
Low Maintenance: Solid-state design minimizes failure points and reduces maintenance downtime.
-
Compact Design: The module’s form factor allows for efficient use of space in control cabinets.
Frequently Asked Questions (FAQ)
Q1: What is the main function of the ABB DSTA171 module?
A1: It acts as a communication interface between control processors and field devices using the AF100 protocol.
Q2: Can DSTA171 be used with ABB AC800M series controllers?
A2: No, the DSTA171 is specifically designed for use in Advant OCS systems and is not compatible with AC800M series.
Q3: Is the DSTA171 hot-swappable?
A3: No, for safety and system integrity, power should be disconnected before replacing or installing the module.
Q4: What is the communication speed supported by DSTA171?
A4: The module supports a communication rate of up to 1 Mbit/s over the AF100 network.
Q5: Does this product require regular firmware updates?
A5: No regular updates are required; it is a stable and finalized hardware product.
Q6: How can I diagnose a failure in the DSTA171 module?
A6: The module includes diagnostic LEDs and supports system event logs via the controller for easy troubleshooting.
Q7: What is the typical service life of the DSTA171?
A7: When operated within specifications, it typically lasts over 15 years in industrial conditions.
Q8: Can the module be installed in a vertical orientation?
A8: Yes, as long as proper airflow is maintained, it can be mounted vertically on DIN rails.
Q9: What are the storage conditions for spare units?
A9: It should be stored in a dry environment between -40°C to +70°C with humidity below 90% non-condensing.
Q10: Is this module compliant with industrial safety standards?
A10: Yes, the DSTA171 complies with CE, RoHS, and ISO9001 standards.
