Product Introduction
The ABB DSTD 108P 3BSE018333R1 is a highly efficient connection unit designed to provide seamless communication and signal transfer between various components in industrial control systems. This connection unit is essential for applications that require secure and reliable electrical connections, serving as a critical link between field devices and control systems. It is designed for use with ABB’s AC 800M and other industrial automation systems, providing ease of integration, enhanced performance, and reduced installation time.
The DSTD 108P unit facilitates the integration of complex wiring systems into automated control environments. Its durable construction, precise engineering, and compact size make it ideal for use in a variety of industrial sectors, including process automation, energy, and manufacturing.
With its modular design and advanced connectivity features, the ABB DSTD 108P ensures that all electrical signals are efficiently transferred, reducing the risk of wiring errors and increasing the reliability of control systems. It can handle high-density installations with ease, making it a go-to solution for high-performance industrial environments.
Product Parameters
| Parameter | Specification |
|---|---|
| Model | DSTD 108P |
| Product Code | 3BSE018333R1 |
| Dimensions (L x W x H) | 234 x 36 x 99 mm |
| Weight | 0.168 kg |
| Connection Type | Screw Terminals |
| Mounting Method | DIN Rail |
| Rated Voltage | 24 V DC |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Humidity (non-condensing) | 5% to 95% RH |
| Material | Flame-retardant plastic |
| Vibration Resistance | 1g, 5–500 Hz |
| Insulation Resistance | ≥100 MΩ at 500 VDC |
| Certifications | CE, UL, RoHS |
Product Applications
The ABB DSTD 108P 3BSE018333R1 connection unit is designed for various industrial control systems that demand efficient and secure signal connections. Key applications include:
-
Process Automation: In industries like chemical, pharmaceutical, and food processing, the DSTD 108P ensures reliable field device communication with control systems.
-
Power Generation: Suitable for use in power plants, where robust and secure electrical connections are critical for system stability.
-
Oil and Gas: The DSTD 108P plays a key role in automation and monitoring systems in the oil and gas industry, ensuring communication between equipment in harsh environments.
-
Water Treatment: This unit is ideal for use in water treatment facilities where consistent and error-free signal transfer is crucial.
-
Manufacturing: The DSTD 108P is used in manufacturing plants to connect various components of an automated control system, improving overall efficiency.
Its versatility and ruggedness make the DSTD 108P a reliable solution for industrial sectors that demand high performance in complex wiring and control system integration.
Product Advantages
The ABB DSTD 108P offers several key advantages that enhance its utility and make it a preferred choice in various industrial applications:
-
Compact and Space-Efficient: The compact size of the DSTD 108P (234 x 36 x 99 mm) allows for easy integration into space-constrained environments, optimizing control cabinet layouts.
-
Secure and Reliable Connections: The screw terminal design ensures that electrical connections are strong and resistant to vibration, minimizing the risk of loose or faulty connections.
-
High-Temperature Tolerance: With an operating temperature range of -20°C to +60°C, the DSTD 108P can perform in both indoor and outdoor environments, including challenging industrial settings.
-
Easy Installation: The unit can be quickly mounted on a standard DIN rail, reducing installation time and allowing for easy replacement in case of maintenance.
-
Durable Construction: Built from flame-retardant plastic, the DSTD 108P ensures safety and longevity, even in environments with electrical hazards.
-
Wide Compatibility: It is compatible with a range of ABB’s automation and control modules, ensuring flexibility for system integrators and designers.
-
Vibration Resistance: With a vibration resistance of 1g, 5–500 Hz, the DSTD 108P performs reliably in environments subject to mechanical vibrations, such as manufacturing and energy production plants.
-
Environmental Protection: The DSTD 108P is rated for 5% to 95% relative humidity, making it suitable for environments where moisture is a concern, such as water treatment plants.
With these advantages, the DSTD 108P offers a combination of reliability, flexibility, and ease of use that makes it ideal for demanding industrial applications.
Frequently Asked Questions (FAQ)
1. What is the maximum current rating for the ABB DSTD 108P?
The DSTD 108P can handle up to 10 A per terminal, ensuring reliable signal transfer even in high-current applications.
2. What is the voltage rating of the DSTD 108P?
The DSTD 108P is rated for a maximum of 24 V DC, making it suitable for most industrial control systems.
3. How does the DSTD 108P compare to other connection units?
The DSTD 108P offers superior vibration resistance, secure screw terminal connections, and a compact design compared to many other connection units in the same category.
4. Is the DSTD 108P suitable for use in high-vibration environments?
Yes, it is designed to withstand vibrations up to 1g, 5–500 Hz, making it ideal for use in industrial environments subject to mechanical vibrations.
5. Can I use this unit for outdoor installations?
While it can be used in outdoor applications, it should be housed in a protective enclosure to shield it from direct exposure to harsh environmental conditions like rain or extreme sunlight.
6. What types of wires can be used with the DSTD 108P?
The DSTD 108P supports wires between 0.2 mm² and 2.5 mm² (24–12 AWG), making it versatile for different wiring requirements.
7. Does the unit require any special tools for installation?
No special tools are needed; a simple flat-head screwdriver is sufficient to secure the screw terminals.
8. What are the environmental certifications for the DSTD 108P?
The unit is CE, UL, and RoHS certified, ensuring compliance with global safety and environmental standards.
9. What is the insulation resistance of the DSTD 108P?
The insulation resistance is ≥100 MΩ at 500 VDC, providing a high level of electrical safety.
10. How does the DSTD 108P support system integration?
It is designed to work seamlessly with ABB’s AC 800M and other industrial automation systems, offering flexibility and ease of integration into a wide range of control applications.
Related Models from the Same Series
| Model | Description |
|---|---|
| DSTD 107P | Basic terminal unit for smaller-scale applications. |
| DSTD 109P | High-density connection unit for larger systems. |
| DSTD 110P | Enhanced version with additional safety features. |
| DSTD 111P | Advanced model with improved signal integrity. |
| DSTD 112P | Terminal unit with integrated diagnostics. |
| DSTD 113P | Heavy-duty connection unit for industrial settings. |
