Product Overview
The ABB DSTD 150A 57160001-UH is a specialized I/O interface module designed for integration within ABB’s high-performance control systems. Widely utilized in process automation and industrial control applications, this module plays a key role in ensuring accurate signal transmission, reliability, and system integrity. Built with robust materials and engineered to endure harsh industrial conditions, it provides long-term operational stability. This module is part of ABB’s Symphony series and is typically found in power generation plants, refineries, chemical facilities, and other complex automation infrastructures.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | DSTD 150A |
| Part Number | 57160001-UH |
| Type | I/O Interface Module |
| Series | Symphony / INFI 90 |
| Input Type | Digital / Analog (depending on setup) |
| Mounting | DIN Rail or Rack Mount |
| Operating Voltage | 24 VDC (nominal) |
| Power Consumption | 2 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 255 ×25 ×90 mm |
| Weight | 0.135 kg |
| Interface | Serial/Parallel (via system configuration) |
| Compliance | CE, RoHS, ISO 9001 |
Product Applications
The DSTD 150A module is designed to operate within ABB’s Symphony/INFI 90 control system platform, delivering consistent performance in various industrial sectors:
-
Power Generation: Used in thermal and hydro power plants for turbine and boiler control.
-
Petrochemical Industry: Enables real-time control in refineries and processing units.
-
Water Treatment Plants: Assists in automation for clean water and wastewater systems.
-
Steel Manufacturing: Interfaces with automation systems for furnace and rolling mill controls.
-
Chemical Processing: Ensures accurate data acquisition and control feedback loops.
Product Advantages
-
Robust Industrial Design: Built to withstand vibration, humidity, and extreme temperature ranges.
-
High System Compatibility: Seamlessly integrates with Symphony and INFI 90 systems.
-
Minimal Downtime: Proven stability and high MTBF (Mean Time Between Failures).
-
Modular Architecture: Easy to install, remove, or replace without disturbing system operations.
-
Field Proven Reliability: Installed in thousands of plants worldwide with excellent performance records.
-
Ease of Maintenance: Clear labeling and accessible diagnostics simplify troubleshooting.
Installation Instructions
-
Power Off: Ensure the system power is fully disconnected before module installation.
-
Mounting: Secure the DSTD 150A into the specified slot or DIN rail location using standard guides.
-
Wiring: Connect input/output cables to the designated terminal blocks per wiring diagram.
-
System Integration: Configure the system software to recognize the module using ABB’s configuration tools.
-
Power On & Test: Reconnect power and conduct module tests to ensure proper data communication and functionality.
Note: Always refer to the ABB DSTD 150A installation manual and follow site-specific safety standards.
Frequently Asked Questions (FAQ)
Q1: What type of signals does the DSTD 150A handle?
A1: The module supports both digital and analog signal inputs depending on system configuration.
Q2: Is this module hot-swappable?
A2: No, it should only be replaced or installed when the system is powered down.
Q3: What systems is it compatible with?
A3: Primarily ABB Symphony and INFI 90 control systems.
Q4: What is the average lifespan of the DSTD 150A module?
A4: With proper conditions, it exceeds 5 years of stable performance.
Q5: Can this module be used in hazardous environments?
A5: Yes, provided it is installed within certified enclosures and follows ABB’s hazardous location guidelines.
Q6: Does ABB provide firmware updates for this module?
A6: This module typically operates on hardware configuration. Firmware updates are rare but may apply in certain systems.
Q7: Is technical support available for legacy systems using this module?
A7: Yes, ABB maintains legacy support for DSTD 150A through their service network.
Q8: What happens if the module fails during operation?
A8: The system will log a diagnostic alert. Replacement is straightforward with minimal disruption.
Q9: Are spare parts for this module still available?
A9: Yes, ABB and authorized distributors stock original and refurbished units.
Q10: Can this module be refurbished?
A10: Yes, many certified ABB partners offer refurbishment services for this model.
