Product Overview
The ABB GD C806A 1001, identified by part number 3BHE028761R1001, is a high-performance gate driver module designed for precise control of power semiconductor devices. Engineered to operate reliably in demanding industrial environments, it ensures efficient and stable performance across various applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | GD C806A 1001 |
| Part Number | 3BHE028761R1001 |
| Product Type | Gate Driver Module |
| Origin | Sweden |
| Power Supply Voltage | 24 V DC |
| Input Signal Voltage | 5 V DC |
| Maximum Output Current | 5 A |
| Isolation Voltage | 2500 V DC |
| Operating Temperature | -40°C to +85°C |
| Dimensions (L×W×H) | 120 × 100 × 25 mm |
| Weight | 0.25 kg |
| Warranty | 12 months |
Applications
The ABB GD C806A 1001 gate driver is versatile and suitable for a range of industrial applications:
-
Motor Control Systems: Provides precise control for various motor types, enhancing performance and efficiency.
-
Power Conversion Units: Ensures efficient switching in inverters and converters, optimizing energy usage.
-
Industrial Automation: Integrates seamlessly into automated systems, improving reliability and control.
-
Robotics: Delivers accurate control signals for robotic actuators, enhancing precision and responsiveness.
-
Energy Management Systems: Facilitates effective control in energy distribution and storage systems.
Key Advantages
-
High Reliability: Built to withstand harsh industrial conditions, ensuring long-term operational stability.
-
Efficient Performance: Optimized for low power consumption while maintaining high output capabilities.
-
Compact Design: Its small footprint allows for easy integration into existing systems without significant redesign.
-
Enhanced Safety: High isolation voltage provides robust protection against electrical faults.
-
Ease of Maintenance: Modular design simplifies troubleshooting and component replacement.
Frequently Asked Questions (FAQ)
-
What is the primary function of the ABB GD C806A 1001 gate driver?
It serves to control power semiconductor devices by providing appropriate gate signals, ensuring efficient switching operations in various applications.
-
Can this gate driver be used in high-temperature environments?
Yes, it operates reliably within a temperature range of -40°C to +85°C, suitable for demanding industrial settings.
-
What types of power devices is it compatible with?
It is designed to drive a range of power semiconductor devices, including IGBTs and MOSFETs.
-
Does the module provide electrical isolation?
Yes, it offers an isolation voltage of 2500 V DC, ensuring safety and protecting control circuits from high-power sections.
-
Is the ABB GD C806A 1001 compatible with other ABB systems?
It is designed to integrate seamlessly with various ABB automation and control systems, enhancing system compatibility.
-
What is the typical lead time for this product?
Lead times can vary; it’s advisable to contact authorized ABB distributors for current availability and delivery schedules.
-
Are there any certifications associated with this gate driver?
While specific certifications may vary, ABB products typically comply with international standards for quality and safety.
-
Can the gate driver be used in renewable energy applications?
Yes, its robust design makes it suitable for applications like solar inverters and wind turbine control systems.
-
What maintenance is required for this module?
Regular inspections for signs of wear or damage and ensuring clean operating environments will help maintain optimal performance.
-
What precautions should be taken during the installation of the GD C806A 1001 gate driver?
During installation, it is essential to ensure proper grounding to avoid electrical noise interference. The module should be mounted in a well-ventilated enclosure to maintain optimal thermal conditions.
Related Models
| Model Number | Description |
|---|---|
| GD C806A 1002 | Enhanced version with additional features |
| GD C807A | Similar gate driver with different specifications |
| GD C805A | Compact gate driver for space-constrained applications |
| GD C808A | High-power gate driver for demanding applications |
| GD C809A | Gate driver with extended temperature range |
| GD C810A | Advanced gate driver with integrated diagnostics |
Popular ABB Models
| Model Number | Product Type | Description |
|---|---|---|
| ACS880-01 | AC Drive | Versatile drive for various applications |
| ABB DCS800 | DC Drive | High-performance drive for DC motors |
| ABB PLC AC500 | Programmable Logic Controller | Modular PLC for complex automation tasks |
| ABB SACE Emax 2 | Circuit Breaker | Advanced circuit breaker with smart features |
| ABB IRB 6700 | Industrial Robot | High-payload robot for heavy-duty tasks |
| ABB Ability™ System 800xA | Control System | Integrated control system for process industries |
