Product Overview
The ABB GDB021BE05 HIEE300766R0005 Green Board 2 is a high-reliability PCB module designed for use in ABB’s Symphony and INFI 90 Distributed Control Systems (DCS). This green board performs vital signal interface, processing, and control tasks within the system’s modular control architecture.
Engineered for rugged industrial environments, the GDB021BE05 offers stable operation, seamless integration, and long-term performance in critical process automation applications. It features a plug-in design, simplifying both installation and field maintenance.
Key Features
-
Robust green PCB design for industrial use
-
Full compatibility with ABB Symphony and INFI 90 systems
-
Designed for signal processing, control logic, or interfacing
-
Plug-in module design for quick replacement and reduced downtime
-
Factory-tested for quality, durability, and performance
-
Part Number: HIEE300766R0005
Technical Specifications
Item | Specification |
---|---|
Model Number | GDB021BE05 |
Part Number | HIEE300766R0005 |
Module Type | Green PCB Interface/Logic Board |
System Compatibility | ABB Symphony, INFI 90 DCS |
Functional Role | Signal interface and processing |
Mounting Type | Plug-in board |
PCB Material | FR4-grade fiberglass, multilayer with green solder mask |
Operating Voltage | As per DCS system specification |
Operating Temperature | 0°C to +60°C |
Storage Temperature | –40°C to +85°C |
Dimensions | 260 × 120 × 25 mm |
Weight | 0.5 kg |
Industry Applications
-
Thermal and hydroelectric power plants
-
Oil and gas processing facilities
-
Chemical and petrochemical industries
-
Pulp and paper automation systems
-
Heavy industrial manufacturing using ABB DCS platforms
Product Advantages
-
Proven Compatibility: Integrates seamlessly with ABB DCS hardware
-
Industrial-Grade Reliability: Performs reliably in demanding environments
-
Minimal Downtime: Plug-in design allows fast installation or replacement
-
Field-Tested Quality: Known for durability and longevity
-
Compact and Efficient: Slim profile for effective rack or cabinet use
Frequently Asked Questions (FAQ)
-
Which ABB systems support the GDB021BE05?
It is compatible with Symphony and INFI 90 Distributed Control Systems. -
What is the function of this green board?
It performs signal interfacing, control, or processing functions based on configuration. -
Is this board hot-swappable?
It may support hot-swapping depending on the DCS rack and power condition; refer to system manuals. -
What is the size of this module?
Approximately 260 mm × 120 mm × 25 mm. -
What is the module’s weight?
Around 0.5 kg. -
Is this still in production by ABB?
It may be legacy hardware; availability can vary between OEM stock and third-party vendors. -
Can refurbished versions be used reliably?
Yes, provided they are tested and sourced from reputable suppliers. -
Does this require calibration or configuration?
It may require system configuration depending on role in the DCS. -
What environmental conditions does it tolerate?
Operates in 0°C to 60°C and stores in –40°C to +85°C environments. -
What is the ABB ordering code?
HIEE300766R0005.
