Product Introduction
The ABB GV C714 A101 IGCT Module is a high-performance Integrated Gate Commutated Thyristor module engineered for industrial-scale power conversion and control systems. This module is specifically designed for high-current, high-voltage applications, providing precise switching control for power devices in medium- and high-voltage power electronics.
The module’s design enables fast, reliable gate turn-off and turn-on, minimizing switching losses while ensuring stable operation in demanding industrial environments. It integrates advanced thermal management features, robust electrical insulation, and high surge current capability, making it suitable for heavy-duty applications such as steel production, rolling mills, large motor drives, and energy conversion systems.
ABB’s GV C714 A101 IGCT Module is part of the GV series, ensuring seamless integration with ABB control and protection systems, providing real-time monitoring and fault protection to safeguard both the module and connected equipment.
Product Parameters
| Parameter | Specification |
|---|---|
| Series | GV C714 A101 |
| Part Number | 3BHE024415R0101 |
| Module Type | IGCT (Integrated Gate Commutated Thyristor) |
| Maximum Current | 3000 A |
| Maximum Voltage | 4.5 kV |
| Gate Trigger Voltage | 20 V DC |
| Gate Trigger Current | 100 A |
| Isolation | Galvanic isolation to case and gate control |
| Thermal Resistance | 0.025 K/W |
| Operating Temperature Range | -40°C to +85°C |
| Mounting Type | Flanged or bolted to heat sink |
| Dimensions (L × W × H) | 180 × 150 × 65 mm |
| Weight | 1.2 kg |
| Package | Press-pack design |
| Surge Current Capability | Up to 30 kA (non-repetitive) |
| Diagnostics/Monitoring | Gate status, fault detection compatible |
| Cooling Method | Direct water or forced air cooling |
Product Applications
The ABB GV C714 A101 IGCT Module is widely used in industrial, power, and energy applications where reliable high-power switching is critical:
-
Industrial Drives: Provides switching for high-power motor drives in steel mills, cement plants, and heavy machinery.
-
High-Voltage Power Converters: Integrated in medium- and high-voltage converters, ensuring smooth energy transfer with minimal losses.
-
Energy Generation and Conversion: Used in renewable energy systems, including wind turbines and energy storage solutions, for high-efficiency power control.
-
Traction Systems: Supports railway and urban transport traction systems, controlling high currents in traction inverters.
-
Testing and Laboratory Environments: Allows precise controlled switching for high-current experiments and system characterization.
-
Industrial Automation: Works alongside ABB gate driver and control boards for accurate and safe IGCT operation in complex automation systems.
Product Advantages
The GV C714 A101 module provides multiple advantages for high-power industrial applications:
-
High Current Capability: Supports continuous currents up to 3000 A, and short-term surge currents up to 30 kA.
-
Fast Switching: Optimized for rapid turn-on and turn-off, minimizing switching losses and heat generation.
-
Integrated Protection: Provides robust protection against overcurrent, misfire, and voltage spikes, increasing operational safety.
-
Flexible Integration: Compatible with ABB GV series gate drivers and control systems, ensuring modular scalability.
-
Thermal Management: Press-pack design and optional cooling methods reduce thermal stress, improving reliability.
-
Industrial Reliability: Designed to operate in harsh environments, resistant to vibration, dust, and EMI interference.
-
Diagnostics and Monitoring: Supports real-time fault detection, enabling preventive maintenance and minimizing downtime.
-
High Surge Handling: Capable of handling non-repetitive high surge currents, ensuring safety in transient conditions.
Frequently Asked Questions (FAQ)
-
What is the primary function of the GV C714 A101 IGCT Module?
It serves as a high-power switching device that controls large currents in industrial converters and motor drives, ensuring precise gate turn-on and turn-off. -
Which types of power systems is this module designed for?
This module is intended for medium- to high-voltage systems, including industrial motor drives, power conversion units, and energy storage applications. -
What is the maximum continuous current this module can handle?
The GV C714 A101 can continuously handle up to 3000 A, with non-repetitive surge currents up to 30 kA. -
What gate control requirements does this module have?
The module requires a gate trigger voltage of 20 V DC and a trigger current of 100 A, compatible with ABB GV series gate drivers. -
Can this module operate in harsh industrial environments?
Yes, it is designed for high vibration, dust, and EMI environments, with an operating temperature range of -40°C to +85°C. -
What cooling methods are supported by this module?
The module supports direct water cooling or forced air cooling to maintain thermal stability under high power operation. -
Is this module compatible with ABB control boards?
Yes, it can be integrated with ABB GV C714 and related control/driver boards, ensuring accurate gate control and fault monitoring. -
What protection features does this module include?
Protection includes overcurrent, misfire detection, and voltage spike mitigation, safeguarding both the module and connected circuits. -
Can this module be used in energy storage or renewable energy systems?
Yes, it is suitable for renewable energy applications, including wind turbines, solar inverters, and battery storage converters. -
What is the module’s physical configuration?
The GV C714 A101 uses a press-pack design with galvanic isolation and flanged mounting, providing robust mechanical and electrical stability.
Related / Same Series Models
| Model Number | Function | Voltage | Current Capability |
|---|---|---|---|
| GV C710 A101 | IGCT Module | 4.5 kV | 2000 A |
| GV C712 A102 | High-Power IGCT Module | 4.5 kV | 2500 A |
| GV C713 A101 | IGCT Press-Pack Module | 4.5 kV | 2800 A |
| GV C715 A101 | IGCT Module | 4.5 kV | 3200 A |
| GV C716 A101 | Industrial IGCT Module | 4.5 kV | 3500 A |
| GV C717 A102 | High-Current IGCT Module | 4.5 kV | 4000 A |
Popular ABB IGCT Modules
| Model Number | Function | Voltage | Current Capability |
|---|---|---|---|
| GV C704 A101 | IGCT Module | 4 kV | 2000 A |
| GV C705 A101 | Press-Pack IGCT Module | 4 kV | 2200 A |
| GV C710 A101 | IGCT Module | 4.5 kV | 2000 A |
| GV C712 A102 | IGCT Module | 4.5 kV | 2500 A |
| GV C713 A101 | IGCT Module | 4.5 kV | 2800 A |
| GV C715 A101 | High-Power IGCT Module | 4.5 kV | 3200 A |
