Product Overview
The ABB GV C750 AE0101 3BHB005171R0101 IGBT Module is a high-performance insulated gate bipolar transistor (IGBT) module designed for industrial power conversion applications. It provides reliable switching, high efficiency, and robust operation in variable-speed drives, power inverters, and other industrial automation systems.
Key Features
-
High-performance IGBT module for industrial power electronics
-
Designed for variable-speed drives, inverters, and converters
-
Compact and robust construction for reliable operation
-
Low switching losses and high efficiency
-
High current and voltage handling capabilities
-
Suitable for demanding industrial environments
-
Facilitates maintenance and system integration
Technical Specifications
| Specification | Details |
|---|---|
| Model | GV C750 AE0101 / 3BHB005171R0101 |
| Type | IGBT Module |
| Maximum Collector-Emitter Voltage | 1200 V |
| Maximum Collector Current | 350 A |
| Switching Frequency | Up to 5 kHz (depending on application) |
| Gate Drive Voltage | 15 V typical |
| Operating Temperature | –40 °C to +150 °C |
| Storage Temperature | –40 °C to +125 °C |
| Mounting | Standard module mounting (screw terminals) |
| Dimensions | 250 x 200 x 80 mm |
| Weight | 0.45 kg |
Frequently Asked Questions (FAQ)
1. What is the main function of the GV C750 AE0101 module?
It serves as an IGBT module for high-efficiency power switching in industrial applications.
2. Which applications is this module suitable for?
Variable-speed drives, power inverters, converters, and industrial automation systems.
3. What is the maximum collector-emitter voltage?
1200 V.
4. What is the maximum collector current?
350 A.
5. What is the typical switching frequency?
Up to 5 kHz, depending on application.
6. What is the operating temperature range?
–40 °C to +150 °C.
7. Is it suitable for renewable energy applications?
Yes, it can be used in solar inverters and wind turbines.
8. What are the benefits of using this module?
High efficiency, reliable high-power switching, reduced maintenance, and robust industrial performance.
