Product Overview
The ABB LD MTR-01 3BHB007445P0001 Analog Input Card is designed for industrial automation systems to acquire and process analog signals from sensors and transducers. It provides accurate data conversion, enabling precise monitoring and control in ABB motion and motor control applications.
Key Features
-
High-accuracy analog input card for ABB automation systems
-
Processes signals from sensors and transducers (0–10 V, 4–20 mA)
-
Compact, robust design for reliable industrial operation
-
LED indicators for status and diagnostic feedback
-
Supports multiple analog channels for scalable applications
-
Facilitates integration with ABB motor and motion control systems
Technical Specifications
| Specification | Details |
|---|---|
| Model | LD MTR-01 / 3BHB007445P0001 |
| Type | Analog Input Card |
| Number of Channels | 4 analog inputs |
| Input Signal Range | 0–10 V / 4–20 mA |
| Resolution | 12-bit |
| Accuracy | ±0.1% of full scale |
| Sampling Rate | 1 kHz per channel |
| Supply Voltage | 24 VDC |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –20 °C to +70 °C |
| Indicators | Status LEDs for power and communication |
| Mounting | Standard DIN rail or rack mount |
| Dimensions | 120 × 90 × 45 mm |
| Weight | 0.3 kg |
Frequently Asked Questions (FAQ)
1. What is the main function of the LD MTR-01 analog input card?
It acquires and processes analog signals from sensors for ABB automation systems.
2. Which systems is this card compatible with?
It is compatible with ABB LD MTR series modules and motor control systems.
3. How many analog input channels does it support?
4 analog input channels.
4. What input signal types are supported?
0–10 V voltage signals and 4–20 mA current signals.
5. What is the resolution of the card?
12-bit resolution.
6. What is the operating temperature range?
0 °C to +60 °C.
7. Can it be used for elevator control systems?
Yes, it is suitable for signal acquisition in elevator and door control systems.
8. What are the benefits of using this card?
Accurate analog signal acquisition, reliable operation, easy integration, and reduced system downtime.
