Product Introduction
The ABB NPOW-42C (64113593) is an industrial-grade Power Supply Board designed for high-performance automation and control systems within ABB’s DCS (Distributed Control System) architecture. Built to power critical modules with stable DC output, this power supply board ensures long-term operational reliability in mission-critical environments.
This module is engineered to handle a wide range of industrial conditions, offering redundant capability, high-efficiency voltage regulation, and advanced protection mechanisms. It is particularly well-suited for ABB systems such as Symphony Plus and other process control systems, where uninterrupted power supply is essential.
Its compact form, robust performance, and global compliance make the NPOW-42C a trusted solution for industries ranging from power generation to oil and gas, manufacturing, and chemical processing.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | NPOW-42C |
| Product Code | 64113593 |
| Product Type | Power Supply Board |
| Input Voltage Range | 85–264 VAC or 110–370 VDC |
| Output Voltage | 24 VDC (regulated) |
| Output Power | Up to 120 W |
| Output Current | 5 A maximum |
| Output Channels | Single or dual channel (depends on configuration) |
| Voltage Regulation | ±1% under full load and line conditions |
| Redundancy Support | Yes, compatible with redundant configurations |
| Protection Features | Overvoltage, Overcurrent, Short-circuit, Thermal |
| Cooling Method | Natural convection (fanless design) |
| Mounting Type | PCB mount or integration into ABB carrier |
| Connection Type | Plug-in terminal blocks or PCB edge connectors |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -25°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| MTBF | > 200,000 hours @ 25°C ambient |
| Certifications | CE, UL, CSA, RoHS compliant |
| Dimensions (W x H x D) | 152 x 70 x 100 mm |
| Weight | 0.3 kg |
Product Applications
The ABB NPOW-42C is commonly deployed in environments where reliable power supply to control and processing components is critical. Its primary application areas include:
-
Process Automation: Provides power to controllers, communication modules, and I/O systems in refineries, petrochemical plants, and water treatment facilities.
-
Power Generation and Utilities: Powers turbine control units, switchgear logic, and monitoring systems.
-
Manufacturing: Supports PLCs and DCS modules in production lines, robotic systems, and packaging equipment.
-
Oil & Gas: Used in upstream and downstream automation skids for fault-tolerant power delivery.
-
Mining & Metals: Supplies voltage to equipment in high-vibration, dust-prone areas.
-
Rail & Marine Systems: Ensures rugged power performance in mobile industrial settings.
Product Advantages
-
Redundancy Support: Compatible with dual power input configurations to ensure fault-tolerant operations.
-
Global Input Range: Wide input voltage range makes it suitable for global deployments with varied power sources.
-
High Efficiency and Stability: Offers tightly regulated 24V DC output with minimal ripple and high reliability.
-
Advanced Protection Features: Equipped with overvoltage, overcurrent, and thermal shutdown protections.
-
Low Noise Operation: Fanless cooling reduces mechanical wear and avoids acoustic interference.
-
ABB Integration: Specifically designed for seamless mechanical and electrical integration into ABB DCS platforms.
-
Space-Saving Design: Compact footprint allows it to fit into crowded control cabinets or embedded backplanes.
-
Maintenance-Free Operation: High MTBF means fewer service interruptions and lower total cost of ownership.
-
Environmentally Robust: Operates reliably across a wide range of industrial temperatures and humidity levels.
-
Compliant with Standards: CE, UL, and RoHS certified for global acceptance.
