Product Introduction:
The ABB PM 802F 3BDH000002R1 is a state-of-the-art CPU processor unit designed for industrial automation and control systems. As part of ABB’s renowned series of programmable logic controllers (PLCs), this CPU unit provides high performance, reliability, and efficiency for a wide range of applications.
This CPU processor is optimized for demanding control environments, where precise control and high-speed data processing are required. With advanced processing capabilities and a robust design, the PM 802F is ideal for complex automation tasks, including process control, machine control, and other real-time industrial applications. Its scalable architecture ensures that it can meet the requirements of both small and large automation systems, offering flexibility and future-proofing for system expansions.
The ABB PM 802F is also highly versatile, supporting multiple communication protocols and I/O modules, enabling seamless integration with other ABB products. It is designed to operate in harsh environments, offering high resilience against temperature fluctuations and electrical noise, ensuring uninterrupted performance in critical applications.
Product Parameters:
| Parameter | Value |
|---|---|
| Model Number | PM 802F 3BDH000002R1 |
| Dimensions (W × H × D) | 120 × 100 × 50 mm |
| Weight | 0.5 kg |
| Processor Type | 32-bit ARM-based Processor |
| Power Supply | 24 V DC ± 20% |
| Current Consumption | Approx. 150 mA |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Interfaces | Ethernet, Serial, Fieldbus (optional) |
| Mounting Type | DIN Rail |
| Protection Rating | IP20 |
Product Applications:
The ABB PM 802F 3BDH000002R1 CPU Processor Unit is designed for a broad spectrum of industrial applications, where high-performance processing and reliable operation are crucial. Key applications include:
-
Industrial Automation: The unit is widely used in manufacturing environments to control production lines, machinery, and equipment. Its high processing power ensures quick response times for real-time operations.
-
Process Control: In chemical, oil, gas, and power generation industries, the PM 802F ensures accurate and reliable control of critical processes, enabling smooth operation and safety.
-
Machine Control: The CPU unit can be used in machine automation for tasks such as motion control, robotics, and precision machine tools, where accuracy and responsiveness are key.
-
Building Automation: The PM 802F is effective in managing building control systems, including HVAC, lighting, and energy management systems, providing real-time data processing and control.
-
SCADA Systems: In supervisory control and data acquisition systems, the PM 802F enables efficient data collection, transmission, and monitoring from field devices to central control systems.
-
Energy Management Systems: The unit supports advanced energy management applications, integrating with sensors and meters to monitor and optimize energy usage.
Product Advantages:
-
High Processing Power: The 32-bit ARM-based processor offers fast and efficient data processing, ensuring high-speed control and responsiveness.
-
Compact and Lightweight: With dimensions of 120 × 100 × 50 mm and a weight of only 0.5 kg, the PM 802F is easy to integrate into existing control systems, even in environments with limited space.
-
Flexible Communication Options: The unit supports Ethernet, serial communication, and optional fieldbus interfaces, ensuring seamless integration with a wide range of industrial devices and systems.
-
Reliable Performance: Designed for harsh industrial environments, the PM 802F operates in temperatures ranging from -20°C to +60°C and is resistant to electrical noise and vibration, ensuring long-term reliability.
-
Energy Efficient: With low power consumption (approximately 150 mA), the PM 802F helps reduce operational energy costs, making it a cost-effective solution for continuous operation.
-
Scalable and Future-Proof: The flexible architecture of the unit allows for easy scalability, enabling users to expand their systems as needed without significant upgrades.
-
DIN Rail Mounting: The PM 802F is designed for easy installation on DIN rails, which simplifies system integration and maintenance.
-
Wide Range of Applications: From machine control to energy management, this processor unit is versatile, offering solutions across a wide array of industrial sectors.
-
Enhanced Connectivity: The Ethernet and serial communication options allow for easy connection to other ABB automation components, facilitating data sharing and remote monitoring.
-
Robust Protection: With an IP20 protection rating, the PM 802F is protected from dust and physical contact, enhancing its durability in industrial settings.
FAQ:
-
What is the primary function of the ABB PM 802F CPU processor unit?
-
The PM 802F serves as the central processing unit for controlling industrial automation systems, providing high-speed data processing and communication.
-
-
What are the key communication interfaces supported by the PM 802F?
-
The PM 802F supports Ethernet, serial communication, and optional fieldbus interfaces, enabling flexible integration with various devices.
-
-
What is the power supply requirement for the PM 802F?
-
The unit requires a 24 V DC power supply with a ±20% tolerance.
-
-
What is the operating temperature range for the PM 802F?
-
The PM 802F operates within a temperature range of -20°C to +60°C, making it suitable for various industrial environments.
-
-
What is the weight and size of the PM 802F CPU?
-
The PM 802F has dimensions of 120 × 100 × 50 mm and weighs 0.5 kg, which makes it compact and easy to install in space-constrained environments.
-
-
Can the PM 802F be used in outdoor environments?
-
The PM 802F is designed for indoor use and is best suited for controlled environments with regulated temperatures.
-
-
Is the PM 802F compatible with other ABB automation systems?
-
Yes, the PM 802F is fully compatible with other ABB PLCs and automation components, ensuring seamless system integration.
-
-
What is the protection rating of the PM 802F?
-
The PM 802F has an IP20 protection rating, providing basic protection against dust and physical contact.
-
-
How is the PM 802F mounted?
-
The unit is designed for DIN rail mounting, which simplifies installation in control panels and cabinets.
-
-
What are the current consumption requirements for the PM 802F?
-
The unit consumes approximately 150 mA of current during operation.
-
Model Recommendations (Same Series or Related Modules):
| Model | Description |
|---|---|
| PM 801F | A smaller version of the PM 802F, designed for compact control systems. |
| PM 804F | A high-performance model offering enhanced processing power and more communication options. |
| PM 803F | Features additional I/O channels for large-scale applications. |
| PM 805F | Offers advanced diagnostic and communication features for real-time monitoring. |
| PM 806F | Designed for critical control systems requiring high availability and redundancy. |
| PM 807F | Features a high-speed processor for time-sensitive control applications. |
Popular ABB Models:
| Model | Description |
|---|---|
| DSTC 454L | High-precision temperature controller with LCD display |
| DSTC120 | Compact temperature controller for industrial applications |
| DSTC130 | Temperature controller with multi-channel input capability |
| DSTC140 | Enhanced temperature controller featuring alarm output functions |
| DSTC150 | Programmable temperature controller with PID control |
| DSTC160 | Advanced temperature controller with communication interface |
