Product Overview
The ABB PM564-TP-ETH (1SAP120900R0071) is a high-performance PLC (Programmable Logic Controller) from the AC500-eCo series, designed to deliver advanced control capabilities for small to medium automation tasks. This controller integrates a powerful CPU, multiple onboard digital inputs and transistor outputs, as well as built-in Ethernet and serial communication ports.
With its compact footprint and versatile communication features, the PM564-TP-ETH is ideal for applications requiring speed, reliability, and remote connectivity. Supporting IEC 61131-3 compliant programming, the controller provides engineers with a familiar and flexible environment for building control logic.
Thanks to its integrated Ethernet port, the PM564-TP-ETH offers convenient networking and easy integration with SCADA, HMI, or cloud platforms, making it a solid choice for modern industrial automation systems.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Name | PM564-TP-ETH |
| Order Code | 1SAP120900R0071 |
| Product Series | AC500-eCo |
| Processor | 32-bit RISC processor |
| Program Memory | 128 KB |
| Data Memory (RAM) | 16 KB |
| Retain Memory | 8 KB |
| Digital Inputs (DI) | 12 channels |
| Digital Outputs (DO) | 8 channels (transistor type, sourcing) |
| Analog I/O | Not included (available via expansion) |
| Communication Ports | 1x RS-485 (Modbus RTU), 1x Ethernet, 1x USB (for programming) |
| Supported Protocols | Modbus RTU, Modbus TCP |
| Programming Language | IEC 61131-3 (LD, ST, FBD, IL, SFC) |
| Programming Software | ABB PS501 Control Builder |
| Power Supply | 24 VDC (±20%) |
| Power Consumption | < 4.5 W |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (W x H x D) | 74 x 135 x 82 mm |
| Weight | 0.29 kg |
| Certifications | CE, UL, cUL, RoHS compliant |
Applications
The ABB PM564-TP-ETH is well-suited for a wide range of automation projects, particularly those demanding Ethernet connectivity and fast switching capabilities. It is commonly used in:
-
Machine Control Systems – Excellent for controlling CNCs, material feeders, and manufacturing robots.
-
Building Automation – Ideal for HVAC, lighting, access control, and smart energy management.
-
Packaging Industry – Efficient for sequencing, timing, and output control in packing lines.
-
Remote Monitoring Stations – Ethernet connectivity enables SCADA/HMI access across locations.
-
Water/Wastewater Management – Suitable for valve control, pump sequencing, and flow monitoring.
-
Renewable Energy Systems – Used in solar farms and wind installations for automation and reporting.
Its compact design and built-in communication options make it a practical and scalable solution for OEMs and system integrators alike.
Key Advantages
-
Integrated Ethernet and Serial Communication
Offers both RS-485 and Ethernet ports to support versatile industrial network topologies. -
Fast Switching Outputs
Transistor outputs are ideal for applications needing quick on/off response, such as motor or valve control. -
Modular Scalability
Supports expansion modules, allowing the PLC to grow with project requirements. -
Standards-Compliant Programming
Fully IEC 61131-3 compliant, enabling structured and maintainable logic development. -
Space-Efficient Installation
DIN-rail mounting and compact housing allow for easy integration into small panels. -
Energy-Efficient Operation
Consumes less than 5W, reducing load on power supplies and enabling sustainable automation.
Frequently Asked Questions (FAQ)
-
Does the PM564-TP-ETH support both Modbus RTU and TCP protocols?
Yes, it supports Modbus RTU through RS-485 and Modbus TCP through the integrated Ethernet port. -
Can this PLC be used with ABB’s CP600 series HMI?
Absolutely. The PM564-TP-ETH works seamlessly with CP600 HMIs over Modbus TCP or serial links. -
How are the transistor outputs configured?
The 8 digital outputs are sourcing-type transistors, suited for driving relays, solenoids, or low-voltage devices. -
Is it possible to create PID control loops on this PLC?
Yes. The PS501 software supports function blocks for PID control, timing, counting, and math operations. -
Does it come with analog inputs or outputs?
No analog I/Os are included onboard, but you can add analog I/O modules via expansion slots. -
Is the device suitable for continuous operation in industrial settings?
Yes. It’s designed for 24/7 operation under industrial conditions with minimal maintenance. -
Can this PLC be connected to a SCADA system remotely?
Yes. The Ethernet port allows remote monitoring and control via SCADA platforms that support Modbus TCP. -
Does the USB port support data logging or storage?
No, the USB port is intended for programming and diagnostics, not data storage. -
How does it perform in noisy electrical environments?
The PM564-TP-ETH is equipped with industrial-grade EMC protection and complies with CE/UL standards. -
What is the procedure for firmware updates?
Firmware updates can be applied using ABB’s PS501 Control Builder via USB or Ethernet. Always back up your project before updating.
Related Models (Same Series or Functionally Similar)
| Model | Description | Digital I/O | Comms |
|---|---|---|---|
| PM554-RP | Entry-level PLC with relay outputs | 8 DI / 6 DO (relay) | RS-485, USB |
| PM552-ETH | Compact PLC with Ethernet and relay outputs | 8 DI / 6 DO | Ethernet, RS-485 |
| PM556-T-ETH | Transistor output version with Ethernet | 12 DI / 8 DO | Ethernet, RS-485 |
| PM564-RP | Relay output variant of PM564 | 12 DI / 8 DO (relay) | RS-485, USB |
| PM573-ETH | Higher-end PLC with increased memory | 16 DI / 12 DO | Ethernet, USB |
| PM571-RP | Compact PLC with relay outputs | 8 DI / 6 DO | RS-485, USB |
Popular ABB PLC Models
| Model | Description | Series | Special Features |
|---|---|---|---|
| AC500 PM591-ETH | Mid-range CPU with high processing power | AC500 | Ethernet, PROFINET support |
| AC500 PM592-ETH | Advanced controller with large memory | AC500 | Ideal for large applications |
| CI501-PN | PROFINET communication interface module | AC500 | PROFINET Device |
| CP600-ECO | Economical HMI for use with AC500 series | CP600 | Ethernet/USB interfaces |
| AI810 Analog Input | 8-channel analog input module | S800 I/O | 0-20mA / 4-20mA range |
| DO820 Digital Output | 16-channel digital output module | S800 I/O | 24 VDC output, sourcing type |
