Product Introduction
The ABB PM810V1 3BSE008580R1 is a high-performance processor module used in ABB’s AC 800M series of control systems. Engineered for demanding automation environments, this module serves as the core controller in distributed control systems (DCS), offering excellent reliability, processing speed, and flexibility. Its robust design ensures smooth operation in industrial environments where precision and uninterrupted performance are critical.
Built upon the proven ABB Advant Master DCS platform, the PM810V1 plays a crucial role in process control by managing communication between field devices, control applications, and human-machine interfaces (HMIs). This processor module supports various communication protocols and is scalable for complex automation architectures.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | ABB PM810V1 Processor Module |
| Order Code | 3BSE008580R1 |
| Product Type | CPU Module / Processor Unit |
| System Compatibility | AC 800M, 800xA |
| Processor Type | RISC processor |
| Processor Speed | 100 MHz |
| Memory | 16 MB Flash, 8 MB DRAM |
| Battery Backup | Yes (real-time clock and memory retention) |
| Communication Ports | Ethernet (RJ45), Serial (RS-232), S800 I/O Bus |
| Supported Protocols | TCP/IP, Modbus, OPC, PROFIBUS |
| Redundancy Support | Yes |
| Real-Time Clock | Yes |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Certifications | CE, UL, cUL, RoHS |
| Dimensions (H x W x D) | 144 x 144 x 28 mm |
| Weight | 0.35 kg |
Product Applications
The PM810V1 module is designed for a wide range of industrial automation and process control applications, including:
-
Chemical and Petrochemical Plants
-
Power Generation and Distribution Systems
-
Water and Wastewater Treatment Facilities
-
Pulp and Paper Manufacturing
-
Oil and Gas Processing Plants
-
Pharmaceutical Manufacturing
-
Metallurgical and Mining Industries
Its real-time processing capabilities and robust communication features make it ideal for both continuous and batch processes.
Product Advantages
-
High Reliability:
Designed to operate in harsh industrial environments with stable and uninterrupted performance. -
Flexible Communication Options:
Supports multiple protocols and interfaces for integration with different control layers and field devices. -
Redundancy Features:
Offers fault-tolerant operation with CPU redundancy support, increasing system availability. -
Efficient Performance:
Optimized for fast response times and deterministic control, ensuring accurate real-time data processing. -
Ease of Integration:
Seamlessly integrates into ABB’s 800xA system architecture, enhancing scalability and operational efficiency. -
Long-Term Support:
Backed by ABB’s global service and support network for maintenance, upgrades, and spare parts.
Frequently Asked Questions (FAQ)
1. What control systems is the PM810V1 compatible with?
It is compatible with ABB’s AC 800M and 800xA DCS platforms.
2. Can this module be used in redundant configurations?
Yes, the PM810V1 supports CPU redundancy for critical applications.
3. Is the module suitable for high-temperature environments?
It operates within a range of 0°C to +55°C, suitable for most industrial settings.
4. Does it support remote diagnostics?
Yes, it provides remote diagnostics via Ethernet and control software.
5. What type of memory is available in this module?
It includes 16 MB of Flash and 8 MB of DRAM memory.
6. How does it communicate with field devices?
Through Ethernet, RS-232 serial ports, and ABB S800 I/O bus.
7. What certifications does this product have?
It is CE marked and UL/cUL listed, compliant with international standards.
8. Is the firmware upgradable?
Yes, firmware updates can be performed using ABB’s configuration tools.
9. Can the module be hot-swapped?
No, power should be turned off before replacement to avoid damage.
10. What industries benefit most from this module?
Industries such as oil & gas, power, water treatment, and manufacturing benefit from its capabilities.
Related Models from the Same Series
| Model | Part Number | Description |
|---|---|---|
| PM851K01 | 3BSE018168R1 | CPU module with onboard Ethernet |
| PM856K01 | 3BSE018173R1 | High-speed processor module for AC 800M |
| PM860K01 | 3BSE018100R1 | Redundant-capable processor with RTC |
| PM864AK01 | 3BSE018161R1 | Advanced CPU with 64 MB memory |
| PM865K01 | 3BSE031151R1 | Redundant CPU module with Ethernet & RTC |
| PM867K01 | 3BSE043660R1 | High-performance CPU for complex DCS setups |
Popular Models from the Same Brand (ABB)
| Model | Part Number | Description |
|---|---|---|
| CI854AK01 | 3BSE030220R1 | Communication Interface for PROFIBUS DP |
| CI860K01 | 3BSE032444R1 | Communication Interface for IEC61850 |
| AI810 | 3BSE008516R1 | 8-channel analog input module |
| DI820 | 3BSE008512R1 | 16-channel digital input module |
| DO820 | 3BSE008514R1 | 16-channel digital output module |
| CI871K01 | 3BSE056767R1 | PROFINET communication interface |
