ABB PP826 3BSE042244R1 Operation Panel Screen
1. Product Overview
The ABB PP826 3BSE042244R1 operation panel is a high-performance Human-Machine Interface (HMI) designed for industrial automation environments. It features a high-resolution touch display and powerful data interaction capabilities, enabling intuitive control and real-time system monitoring. As an integral part of the ABB 800xA system, the PP826 is widely used in manufacturing, energy, petrochemical, water treatment, and other industries.
Engineered for harsh industrial environments, the PP826 offers robust design, multi-interface communication support, and excellent compatibility. Its modular build and panel-mount design make it suitable for both new installations and system upgrades, while its touch screen simplifies complex operations with visualized data and feedback.
2. Key Features
-
High-Resolution Touchscreen: Provides a sharp and interactive GUI for improved operational control.
-
Industrial-Grade Build: Rugged housing with dust and water resistance, ideal for challenging environments.
-
Multiple Communication Interfaces: Includes Ethernet, USB, RS-232, RS-485 for flexible system integration.
-
Panel Mount Design: Space-saving and easy to install in industrial cabinets or control panels.
-
System Compatibility: Fully integrates with ABB 800xA and supports third-party automation platforms.
-
Expandability: Software upgrades and external storage options for data logging and remote access.
3. Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 275 x 168 x 6mm |
| Weight | 1.2 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Model | PP826 3BSE042244R1 |
| Manufacturer | ABB |
| Power Supply | 24 V DC ±10% |
| Mounting | Panel Mount / DIN Rail |
| Protection Rating | IP65 (Front Panel) |
| Operating Temp | -10°C to +60°C |
| Storage Temp | -20°C to +70°C |
| Humidity | 5% – 95% RH (non-condensing) |
3.3 Display & Input Features
| Item | Specification |
|---|---|
| Display Type | TFT Color LCD Touchscreen |
| Screen Size | 7 inches |
| Resolution | 800 x 480 pixels |
| Backlight | LED, ≥ 50,000 hours lifespan |
| Touch Technology | Resistive touch, multi-touch support |
3.4 Communication & Interfaces
| Item | Specification |
|---|---|
| Communication Ports | Ethernet, USB, RS-232, RS-485 |
| Supported Protocols | Modbus TCP/IP, OPC, Profibus, etc. |
| Data Storage | Built-in Flash and expandable SD card |
| System Compatibility | Compatible with ABB 800xA and others |
4. Industry Applications
-
Smart Manufacturing: Used in production lines for monitoring and controlling automation processes.
-
Power & Energy: Ideal for power stations, substations, and energy distribution centers.
-
Petrochemical: Enables safe and efficient monitoring of high-risk environments.
-
Water Treatment: Monitors pumps and filtration systems, enhancing performance and compliance.
-
Building Automation: Serves as an energy management and HVAC control interface in intelligent buildings.
This operation panel provides a reliable and flexible control interface for diverse industrial environments.
