Product Overview
The ABB RMIO-01C 64538012 is a versatile and intelligent control board developed as part of ABB’s drive system accessories. It acts as a Regulator and I/O board primarily used in ACS800 drive series. The RMIO-01C is responsible for managing drive control logic, signal interfaces, and communication with field devices. It includes essential analog and digital I/O channels, integrates control functionalities, and handles feedback and reference signals.
This module is critical in ensuring precision control of motor operations, protection features, and system integration. The RMIO-01C simplifies both system configuration and maintenance by consolidating the drive’s regulatory and interfacing roles into a single intelligent board.
Designed to be compact and rugged, this board operates in demanding environments, offering reliable performance for applications ranging from heavy-duty machinery to water processing systems.
Product Parameters
| Parameter | Specification |
|---|---|
| Model | RMIO-01C |
| Brand | ABB |
| Product Type | Regulator and I/O Control Board |
| Function | Motor control logic, analog/digital I/O |
| Compatibility | ABB ACS800 drives |
| I/O Channels | 6 analog (input/output), 10 digital I/O |
| Feedback Support | Yes (speed, torque, voltage) |
| Fieldbus Ready | Yes (via extension modules) |
| Installation Type | Internal slot in drive unit |
| Operating Temperature | -10°C to +50°C |
| Cooling Method | Passive |
| EMC Compliance | IEC 61800-3 |
| Protection Class | IP20 |
| Dimensions | 50 x 120 x 290 mm |
| Weight | 0.21 kg |
Product Applications
The RMIO-01C plays a vital role in a variety of industrial automation and process control setups, including:
-
Industrial Automation
Used in precision motor control for conveyor belts, robotic arms, and machining tools. -
Pumps and Fans
Ensures accurate regulation of motor speed and pressure in HVAC and water treatment applications. -
Cranes and Lifts
Provides reliable signal handling for hoisting systems and elevators. -
Mining and Metal Processing
Deployed in drives that operate crushers, mills, and material conveyors. -
Oil & Gas Facilities
Integrated with drives managing compressor and pump stations. -
Marine and Offshore
Used in propulsion and auxiliary motor systems under harsh marine conditions.
Product Advantages
-
Integrated Control and I/O
Combines motor control logic and signal interfaces in one compact unit. -
High Signal Precision
Offers reliable analog and digital signal processing for sensitive operations. -
Fieldbus Compatibility
Ready for integration with PROFIBUS, Modbus, CANopen, and more through expansion. -
Compact Size
Ideal for space-limited cabinets and panels without sacrificing functionality. -
Drive-Specific Optimization
Optimized for seamless operation with ACS800 series and related ABB drives. -
Reduced System Complexity
Reduces the need for external PLCs or signal converters in simple automation tasks. -
Quick Setup and Commissioning
Works with ABB DriveWindow for fast configuration and diagnostics. -
Energy Efficiency Support
Helps implement energy-saving control strategies through precise feedback management.
Frequently Asked Questions (FAQ)
Q1: What ABB drives are compatible with the RMIO-01C?
A1: It is mainly used with ABB ACS800 drives and compatible variants in low-voltage drive systems.
Q2: Does RMIO-01C support both analog and digital I/O?
A2: Yes, it supports multiple analog inputs/outputs and digital I/O channels.
Q3: Can it be replaced without removing the entire drive?
A3: The RMIO-01C can be accessed and replaced via the drive’s internal control slot.
Q4: Does it support fieldbus communication?
A4: Yes, but it requires a separate extension module for each specific protocol.
Q5: What diagnostic functions does it offer?
A5: It monitors I/O signal status, drive faults, and environmental conditions for troubleshooting.
Q6: Is this control board programmable?
A6: Configuration is done via ABB’s DriveWindow software rather than direct code programming.
Q7: What protection features are included?
A7: It supports overvoltage, overcurrent, and thermal protection as part of the drive system.
Q8: Can it operate in harsh environments?
A8: Yes, within the recommended temperature and protection standards, especially in IP20 enclosures.
Q9: Does the RMIO-01C store parameters?
A9: It holds configuration parameters related to I/O and control logic, typically backed by drive memory.
Q10: How do I update or configure the RMIO-01C?
A10: Use ABB DriveWindow PC tool with proper connectivity and authorized access credentials.
Recommended Related Models (Same Series or Functional Family)
| Model | Description | Dimensions (mm) | Weight |
|---|---|---|---|
| RMIO-02C | Basic I/O board for standard drives | 50 x 120 x 290 | 0.21 kg |
| RMIO-03C | Extended analog I/O version | 50 x 120 x 290 | 0.22 kg |
| RMIO-04C | Compact control and I/O board | 50 x 110 x 280 | 0.20 kg |
| RMIO-12C | Optimized for regenerative applications | 52 x 120 x 290 | 0.23 kg |
| RMIO-13C | For multi-motor drive coordination | 50 x 125 x 295 | 0.22 kg |
| RMIO-15C | Enhanced signal isolation version | 50 x 120 x 290 | 0.21 kg |
Popular ABB Models (Same Brand)
| Model | Description | Function | Weight | Dimensions |
|---|---|---|---|---|
| AI801 | Analog input module (8 ch) | Data acquisition | 0.2 kg | 120 x 90 x 45 mm |
| PM864AK01 | AC 800M controller CPU module | System control | 0.4 kg | 140 x 120 x 50 mm |
| CI854AK01 | PROFIBUS DP adapter module | Communication | 0.2 kg | 90 x 40 x 100 mm |
| PXAE 111 | AC800F system controller unit | Central processing | 4.9 kg | 380 x 235 x 110 mm |
| DO810 | Digital output module (16 channels) | Output signal handling | 0.22 kg | 120 x 90 x 45 mm |
| SD821 | Redundant communication module | System backup interface | 0.28 kg | 130 x 65 x 40 mm |
