ABB SCA 6823A,XV C723 AE07 3BHB002953R0107 Current Measuring Instrument

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The ABB SCA 6823A, XV C723 AE07 3BHB002953R0107 Current Measuring Instrument is a high-precision device designed for accurate current monitoring in ABB’s industrial automation and drive systems. This module delivers reliable measurement of both AC and DC currents, providing real-time feedback for control, protection, and monitoring functions in complex electrical systems. It is engineered for high-voltage and high-current environments, offering excellent noise immunity, fast response, and stable performance under demanding industrial conditions.

The SCA 6823A XV C723 AE07 integrates advanced signal processing, precise shunt-based measurement technology, and robust isolation to ensure accurate readings and system protection. It is optimized for integration into ABB’s Distributed Control Systems (DCS), Variable Frequency Drives (VFD), and power conversion units, making it a critical component for energy management and industrial automation applications.

---

Technical Specifications

---

Product Applications

The ABB SCA 6823A, XV C723 AE07 is used in industrial environments where precise current measurement is essential for system control and protection.

Applications include:

• Industrial Drives: Current monitoring for VFDs and servo motors.

• Power Conversion Units: Accurate measurement in DC/AC converters and rectifiers.

• Energy Management: Load monitoring and optimization in industrial power systems.

• Process Automation: Real-time feedback for DCS and PLC control systems.

• Power Distribution: Current sensing for high-voltage switchgear and substations.

• Protection Systems: Overcurrent detection and system fault monitoring.

---

Product Advantages

The ABB SCA 6823A XV C723 AE07 provides precise and reliable current measurement with robust environmental resistance.

Advantages include:

• High Measurement Precision: ±0.2% accuracy ensures reliable feedback and control.

• Wide Current Range: Can monitor both low and high current levels without loss of precision.

• Strong EMC Immunity: Designed to operate in electrically noisy industrial environments.

• High Isolation: Protects control electronics from high voltage spikes and transients.

• Compact, Robust Design: Rugged aluminum housing and PCB coating ensure durability.

• Passive Cooling: Requires no fans, reducing maintenance and system complexity.

• Fast Response: Real-time measurement with response time ≤1 ms.

• Seamless Integration: Compatible with ABB control and drive systems.

• Environmental Reliability: Maintains accuracy in varying temperature and humidity conditions.

• System Protection: Supports overcurrent alerts and fault monitoring functions.

---

FAQ

1. What type of current can the SCA 6823A XV C723 AE07 measure?
   It can measure both AC and DC currents, providing RMS or average readings.

2. How is electrical isolation achieved between measurement and control circuits?
   The module uses galvanic isolation rated at 2.5 kV RMS to ensure safety and signal integrity.

3. What is the typical response time for current changes?
   The response time is less than or equal to 1 millisecond, suitable for real-time control.

4. Can this module interface with ABB DCS systems?
   Yes, it is fully compatible with ABB DCS and PLC systems for integrated monitoring.

5. What is the measurement accuracy of this instrument?
   It provides ±0.2% full-scale measurement accuracy.

6. Does the module support analog and digital outputs?
   Yes, it offers analog voltage outputs and can communicate digital signals via internal bus interfaces.

7. How does the instrument handle industrial electrical noise?
   It incorporates EMI filters, shielded PCB design, and ground isolation to minimize interference.

8. What are the environmental operating conditions for the module?
   Operating temperature is 0–60°C with relative humidity 5–95% non-condensing.

9. Does it provide diagnostic features?
   Yes, the module includes monitoring for operational status and fault detection.

10. Can the module detect overcurrent situations?
    Yes, it supports overcurrent detection and can trigger alerts to the control system.

---
